Image preview - the first page of the document
AO4932 - Asymmetric Dual N-Channel Enhancement Mode Field Effect Transistor


>> Download AO4932 - Asymmetric Dual N-Channel Enhancement Mode Field Effect Transistor documenatation <<

Text preview - extract from the document
  AO4932
  Asymmetric Dual N-Channel Enhancement Mode Field Effect Transistor
 SRFET        TM

 General Description                                           Features
    The AO4932 uses advanced trench technology to              FET1                   FET2
 provide excellent R DS(ON) and low gate charge. The two       VDS (V) = 30V     V DS(V) = 30V
 MOSFETs make a compact and efficient switch and               ID = 9A             I D=9A      (V GS = 10V)
 synchronous rectifier combination for use in DC-DC            RDS(ON) < 15.8m   <15.8m        (VGS = 10V)
 converters. A monolithically integrated Schottky diode in     RDS(ON) < 19.6m    <23m         (V GS = 4.5V)
 parallel with the synchronous MOSFET to boost
 efficiency further. Standard Product AO4932 is Pb-free
 (meets ROHS & Sony 259 specifications).
                                                                                              UIS TESTED!
                                                                                     Rg,Ciss,Coss,Crss Tested



                                                    SRFETTM
                                                    Soft Recovery MOSFET:
                                                    Integrated Schottky Diode



Absolute Maximum Ratings TA=25
