Image preview - the first page of the document



>> Download GS1085L(F)_Rev 1.0 documenatation <<

Text preview - extract from the document

3A Low Dropout Voltage Regulator
Product Description                                     Features
The GS1085L is a low drop voltage regulator able to         Three Terminal Adjustable or Fixed Output
provide up to 3A output current. The dropout voltage        Voltages 1.5V, 1.8V, 2.5V, 3.3V and 5V
of the device is guaranteed at a maximum 1.3V at            Guaranteed Output Current up to 3A
the maximum output current, decreasing at lower             Typical Dropout 1.3V (at 3A)
loads.                                                      Output Tolerance:
