Image preview - the first page of the document
LD1117 - LOW DROP FIXED AND ADJUSTABLE POSITIVE VOLTAGE REGULATORS


>> Download LD1117 - LOW DROP FIXED AND ADJUSTABLE POSITIVE VOLTAGE REGULATORS documenatation <<

Text preview - extract from the document
                                                                            LD1117 series

                Low drop fixed and adjustable positive voltage regulators

Feature summary
   Low dropout voltage (1V TYP.)
   2.85V Device performances are suitable for
   SCSI-2 active termination
   Output current up to 800 mA
                                                                                           DPAK
   Fixed output voltage of: 1.2V, 1.8V, 2.5V,
                                                                  TO-220
   2.85V, 3.0V, 3.3V, 5.0V
   Adjustable version availability (Vrel=1.25V)
   Internal current and thermal limit
   Available in
