Image preview - the first page of the document



>> Download MAXIMUMSF-10SingleLNB[1] documenatation <<

Text preview - extract from the document

                                                                                                                                   Maximum LNBs


5393                                                                                                                              MAXIMUM SF-10 Single LNB

 PRODUCT VISUAL                                                                                            TECHNICAL SPECIFICATIONS

                                                                                                           Input frequency range
                                                                                                             Low band: 10.7 ~ 11.7 GHz
                                                                                                             High band: 11.7 ~ 12.75 GHz
                                                                                                           Output frequency range
                                                                                                            Low band: 950 ~ 1950 MHz
                                                                                                            High band: 1100 ~ 2150 MHz
                                                                                                           L.O. Frequency
                                                                                                             Low band: 9.75 GHz
                                                                                                             High band: 10.6 GHz
                                                                                                           L.O. Frequency stability
                                                                                                             25
