Image preview - the first page of the document
>> Download 53094 documenatation <<
Text preview - extract from the document
PC123XNNSZ0F Series
DIP 4pin Reinforced Insulation Type
PC123XNNSZ0F Photocoupler
Series
Description Agency approvals/Compliance
PC123XNNSZ0F Series contains an IRED optically 1. Recognized by UL1577 (Double protection isolation),
coupled to a phototransistor. file No. E64380 (as model No. PC123)
It is packaged in a 4-pin DIP, available in wide-lead 2. Approved by BSI, BS-EN60065, file No. 7087, BS-
spacing option and SMT gullwing lead-form option. EN60950 file No. 7409, (as model No. PC123)
Input-output isolation voltage(rms) is 5kV. 3. Approved by SEMKO, EN60065, EN60950, (as mod-
CTR is 50% to 400% at input current of 5mA el No. PC123)
4. Approved by DEMKO, EN60065, EN60950, (as mod-
el No. PC123)
Features
5. Approved by NEMKO, EN60065, EN60950, (as mod-
1. 4-pin DIP package
el No. PC123)
2. Double transfer mold package (Ideal for Flow Solder-
6. Approved by FIMKO, EN60065, EN60950, (as model
ing)
No. PC123)
3. Current transfer ratio (CTR : MIN. 50% at IF=5 mA,
7. Recognized by CSA file No. CA95323, (as model No.
VCE=5V)
PC123)
4. Several CTR ranks available
8. Approved by VDE, DIN EN60747-5-2() (as an op-
5. Reinforced insulation type (Isolation distance : MIN. tion), file No. 40008087 (as model No. PC123)
0.4mm) 9. Package resin : UL flammability grade (94V - 0)
6. Long creepage distance type (wide lead-form type
only : MIN. 8mm) () DIN EN60747-5-2 : successor standard of DIN VDE0884.
7. High isolation voltage between input and output
(Viso(rms) : 5kV) Applications
8. Lead-free and RoHS directive compliant
1. I/O isolation for MCUs (Micro Controller Units)
2. Noise suppression in switching circuits
3. Signal transmission between circuits of different po-
tentials and impedances
4. Over voltage detection
Notice The content of data sheet is subject to change without prior notice.
In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP
devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.
Sheet No.: D2-A09501EN
1 Date Sep. 1. 2006
