Image preview - the first page of the document



>> Download RT8206A Datasheet documenatation <<

Text preview - extract from the document

                                                                                               RT8206A/B

High-Efficiency, Main Power Supply Controllers
for Notebook Computers
General Description                                            Features
The RT8206A/B dual step-down, switch-mode power-                 Wide Input Voltage Range 6V to 25V
supply (SMPS) controller generates logic-supply voltages         Dual Fixed 5V/3.3V Outputs or Adjustable from 2V
in battery-powered systems. The RT8206A/B includes two           to 5.5V, 1.5% Accuracy
pulse-width modulation (PWM) controllers fixed at 5V/            Secondary Feedback Input Maintains Charge Pump
3.3V or adjustable from 2V to 5.5V. An optional external         Voltage (RT8206A)
charge pump can be monitored through SECFB                       Independent Enable and Power Good
(RT8206A). This device also features a linear regulator          5V Fixed LDO Output : 70mA
providing a fixed 5V output. The linear regulator provides       2V Reference Voltage
