Image preview - the first page of the document
>> Download ics_stk_859 documenatation <<
Text preview - extract from the document
Ordering number:ENN5170
Thick Film Hybrid IC
STK392-110
3-Channel Convergence Correction Circuit
(IC max = 3A)
Overview Package Dimensions
The STK392-110 is a convergence correction circuit IC for unit:mm
video projectors. It incorporates three output amplifiers in 4083
a single package, making possible the construction of CRT
[STK392-110]
horizontal and vertical convergence correction output cir-
cuits for each of the RGB colors using ust two hybrid ICs. 64.0
The output circuit use a class-B configuration, in compari- 55.6 8.5
son with the STK392-010, realizing a more compact pack-
age and lower cost.
3.6
31.0
21.0
Applications
25.8
16.5
