Image preview - the first page of the document
>> Download 1274382 documenatation <<
Text preview - extract from the document
184PIN DDR266 Unbuffered DIMM TS128MLD64V6E 1GB With 64Mx4 CL2.5 Description Placement The TS128MLD64V6E is a 128Mx64bits Double Data Rate SDRAM high density for DDR266. The TS128MLD64V6E consists of 32pcs CMOS 64Mx4 bits Double Data Rate SDRAMs in 66 pin TSOP-II 400mil packages and a 2048 bits serial EEPROM on a 184-pin printed circuit board. The TS128MLD64V6E is a Dual In-Line Memory Module and is intended for mounting into 184-pin edge connector sockets. Synchronous design allows precise cycle control with the use of system clock. Data I/O transactions are possible A on both edges of DQS. Range of operation frequencies, programmable latencies allow the same device to be useful for a variety of high bandwidth, high performance memory system applications. B Features
