Image preview - the first page of the document



>> Download 22mcp14 documenatation <<

Text preview - extract from the document

SPECIFICATIONS
MODEL NUMBER ............................2M-CP14
FREQUENCY ...................................143-148 MHz
GAIN ................................................10.3 dBd
FRONT TO BACK ............................20 dB
VSWR ..............................................1.3:1 TYPICAL
BEAMWIDTH ...................................52o CIRCULAR
POLARITY .......................................CIRCULAR
FEED IMPEDANCE..........................50 OHMS UNBALANCED
CONNECTOR ..................................'N' FEMALE
POWER HANDLING ........................1.5 KW
BOOM LENGTH / DIAMETER..........10' 6" / 1.0"
NUMBER OF ELEMENTS ................14
MAST SIZE ......................................1-1/2" / 2"
WIND AREA .....................................1.1 SQ. FT.
WEIGHT / SHIPPING WEIGHT .......6 LBS / 8 LBS UPS

FEATURES
The 2MCP14 is a light, medium performance circularly polarized antenna designed to work across
the two meter amateur band. Optimum match and gain are between 144 & 147 MHz for the
satellite band. Computer design techniques help keep spurious side lobes low down for optimum
signal to noise ratios. This antenna features the same CNC machined, O-ring and silicone-gel
sealed, driven element assemblies common to all M2 Yagi antennas. This insures years of trouble
free performance regardless of weather.
A 136R-14C and a 149T-14C model are also available for the ATS satellite users.
