Image preview - the first page of the document



>> Download 432-9w documenatation <<

Text preview - extract from the document

SPECIFICATIONS
MODEL NUMBER........... 32-9WL
USABLE COVERAGE .... 420 TO 440
GAIN ............................... 17.3 dBd
FRONT TO BACK........... 24 dB
BEAMWIDTH ................ E-20, H-22
STACKING DISTANCE... 70" WIDE, 67" HIGH
FEED IMP. / CONN....... 50 OHMS / 'N' FEMALE
VSWR............................. 1.2:1 or better, 425 to 436
POWER HANDLING....... 1 KW
DRIVEN ELEMENT ........ FOLDED DIPOLE, MOD
ELEMENTS / TYPE ........ 28 / 3/16" ALUM. ROD
BOOM LENGTH / DIA..... 21 FT. (252")
MAST REQUIREMENT... 1-1/2" TO 2-1/8" DIA
WIND AREA ................... 1.6 SQ. FT.
WIND SURVIVAL ........... 100 MPH
WEIGHT / SHIP WT. ..... 7.5 LBS, 10 LBS

FEATURES
The 432-9WL is a lot of dynamite in a small package. The patterns speak for themselves. The
antenna has been optimized for use in an array of two or more antennas, but individually, for
its size, it beats anything out there in both pattern and gain !
Mechanically simple, the boom, 1-1/2 inches in the middle, tapers through swaged ends to
1-1/4 and then 1" diameter tips. Polyethylene button insulators with stainless keepers secure
the 3/16" rod elements and of course all our antennas feature the CNC machined and 'O' ring
sealed Driven Element Module ensuring reliability through weather and time!
