Image preview - the first page of the document



>> Download 6-10lp5 documenatation <<

Text preview - extract from the document

                                                                                               HARDWARE
                                                                                               DETAIL



SPECIFICATIONS
Model .........................................6-10 LP5
Frequency range ........................6 to 10 MHz continuous
Typical gain ................................5 dBd
Front to back, Typical ................15 dB typ.
Beamwidth ..................................70 deg. E and 85deg. in H plane
Feed impedance.........................50 Ohms unbalanced into 4:1 Balun
VSWR.........................................2.0:1 max. 1.5: typ.
Input Connector ..........................SO-239 std. N type available
Power Handling ..........................3 kW standard, Higher available
Boom length and diameter .........30 Ft x 3" x .125 wall
Maximum element length ...........55 Ft.
Turning radius ............................32 Ft.
Wind Area / Survival ...................13 Sq. Ft. / 100 MPH
Weight / ShipWt. .......................86 Pounds / 105 pounds
Price ...........................................$ 1,289.00
FEATURES
   The 6-10LP5 log periodic is a rugged, versatile performer designed for years of trouble free service. For
the amateur radio operator it covers the 7 and 10 MHz amateur bands with high efficiency and no traps!
Machined aluminum element-to-boom clamps and solid fiberglass rod center insulators are just a few of the
unique structural features in this remarkable antenna. Linear loading of the two longest elements reduces
element length and turning radius, putting less demand on the rotator and tower structure. Larger element
sections are sleeved for additional strength.
   For continuous extended coverage, the 6-10lp5 is designed to team up with our popular 10-30LP8 log
periodic. This combination efficiently and economically covers a frequency range of 6 to 30 MHz, keeping
you competitive on every frequency on every band instantaneously.
   The 6-10LP5HD is proving valuable in a variety of Maritime, Government, Commercial, MARS, Scientific
and Amateur applications. Installed at 65 feet or higher, this five element antenna is a world wide performer.
Solid electrical and structural design will maintain communications when other antennas have long since
faded into the noise.
