Image preview - the first page of the document
>> Download 79xx documenatation <<Text preview - extract from the document L7900
SERIES
NEGATIVE VOLTAGE REGULATORS
s OUTPUT CURRENT UP TO 1.5A
s OUTPUT VOLTAGES OF -5; -5.2; -6; -8; -9;
-12; -15; -18; -20; -22; -24V
s THERMAL OVERLOAD PROTECTION
s SHORT CIRCUIT PROTECTION
s OUTPUT TRANSITION SOA PROTECTION
DESCRIPTION
TO-220 TO-220FP
The L7900 series of three-terminal negative
regulators is available in TO-220, TO-220FP,
TO-3 and D2PAK packages and several fixed
output voltages, making it useful in a wide range of
applications. These regulators can provide local
on-card regulation, eliminating the distribution
problems associated with single point regulation;
furthermore, having the same voltage option as
the L7800 positive standard series, they are
particularly suited for split power supplies. In
D2PAK TO-3
addition, the -5.2V is also available for ECL
system. If adequate heat sinking is provided, they
can deliver over 1.5A output current.
Although designed primarily as fixed voltage
regulators, these devices can be used with
external components to obtain adjustable voltages
and currents.
SCHEMATIC DIAGRAM
February 2003 1/16
L7900 SERIES
ABSOLUTE MAXIMUM RATINGS
Symbol Parameter
