Image preview - the first page of the document
7-10-3-1


>> Download 7-10-3-1 documenatation <<

Text preview - extract from the document
SPECIFICATIONS
Model                                        7-10-30LP8 'SKIP LOG'
Frequency range                              10 to 30 MHz continous and a separate
                                             frequency tunable from 6.6 to 8.6 MHz
Typical gain                                 6 dBd 10-30 MHz and 3 dBd @ 7 MHz
Typical Front to back ratio                  15 dB 10-30 MHz and 6 dB @ 7 MHz
Beamwidth                                    65 deg. E and 75 deg. in H plane
Feed impedance                               50 Ohms unbalanced into 4:1 Balun
Maximum VSWR                                 1.8:1
Input Connector                              SO-239 standard. N type available
Power Handling                               3 kW standard, Higher available
Boom length and diameter                     29 Ft X 3" X .125 wall
Maximum element length                       46 Ft.
Turning radius                               28 Ft.
Wind Area / Survival                         13 Sq. Ft. / 100 MPH (125 MPH avail.)
Weight / Ship Wt.                            86 lbs / 100 lbs
Price                                        $ 1,289.00
FEATURES
        This special "skip frequency" hybrid log periodic is a rugged versatile performer
designed for years of trouble free service. For the amateur radio operator it covers SEVEN
Amateur Bands with high efficiency and no traps! Machined aluminum element to boom clamps
and solid fiberglass rod center insulators are just a few of the unique structural features in this
remarkable antenna. The 7-10-30LP8 is a single, economical antenna system that matches up
with todays modern solid state equipment and keeps you competitive on every frequency on
every band instantaneously. Low windload and less weight put less demands on the rotator and
tower structures.
        Maritime, Government, Commercial, MARS, Scientific and Amateur users are finding the
7-10-30LP8 reliably fills a variety of communication requirements. When properly installed at 65
feet or higher this eight element antenna is a world wide, world-class performer. Solid electrical
and structural design will maintain communications when other antennas have long since faded
into the noise.
