Image preview - the first page of the document



>> Download 80m2 documenatation <<

Text preview - extract from the document

SPECIFICATIONS
                 Model Number                     80M2
                 Frequency Range                  3.5-3.575 and 3.75-3.85 MHz
                                                  Remote Switchable @ 24 VDC
                 Gain over dipole                  FS=4.0 dBd @90'=8.4 @110"=9.0 @ 130'=9.6 dBD
                 Front to Back                    15 - 20 dB Typ.
                 Power Handling                   3 KW, cont. standard
                 Feed Imp. / Conn type            50 Ohms/ SO-239 ('N' opt.)
                 VSWR / Bandwidth                 1.2:1 typ. / 2:1 @ edges
                 Balun                            1:1 Coaxial
                 Boom Length / Dia.               30 ft / 4" O.D.
                 Element length                   85 ft. Linear Loaded
                 Element diameter                 3", 2, 1-3/4, 1-1/2, 1-1/4, 1, & 3/4" tips
                 Recommended height               7+0 to 180 ft .
                 Turning radius                   46'
                 Mast Size                        2 in. nom. or specify
                 Wind Area / Survival             19 sq. ft. / 100 mph
                 Weight / Ship wt.                200 lbs / 250 lbs -Truck
                 Price                            $ 2,600.00


FEATURES
   The 80M2 is a real performer, both mechanically and electrically. Element halves start with 3" diameter
tubing and taper through 2", 1-3/4", 1-1/2", 1-1/4", and 1" sections to the 3/4" tips. The 3" and 2" sections
are separated by a polyethylene insulator to allow for the linear loading (#10 copperweld). A solid 2" O.D.
Fiberglass rod, sleeved to the 3" elements, serves as the center insulator.
   The linear loading terminates above the boom and out of the element plane to reduce inductive
cancellation, provide element support, and minimize excessive element droop. In fact, the 80M2 looks
better than some 40 meter models. The 1:1 balun and phone / CW power switching relays are housed in
heavy wall ABS cannisters at the center of each element. Relay requires 12 VDC supply.
   On the air, you'll find little competition for the 80M2.

        7560 N. Del Mar Ave, Fresno CA 93711 (209) 432-8873 FAX (209) 432-3059
