Image preview - the first page of the document



>> Download hfe_cambridge_audio_azur_351a_service_en documenatation <<

Text preview - extract from the document

                                                                        Issue date: July 2012




                          Service Manual

351A




Specifications

Power Output:                      45 watts (into 8 ohms)
Weight:                            6kg (13.2lbs)
THD (unweighted):                  <0.02% @ 1kHz, 80% of rated power
                                   <0.15% 20Hz - 20kHz, 80% of rated power
Inputs:                            5 x RCA, 1 x USB (type B), 1 x 3.5mm MP3 input
Outputs:                           Speakers A & B, 1 x Rec Out,
