Image preview - the first page of the document
>> Download azur_640t_v2 documenatation <<
Text preview - extract from the document
azur 640T V2.0
DAB/FM Tuner
User's manual
Downloaded from www.Manualslib.com manuals search engine
CONTENTS
Introduction .................................................................................................3
Safety precautions ......................................................................................4
Important safety instructions .....................................................................5
Rear panel connections..............................................................................6
Front panel controls ....................................................................................8
Remote control..........................................................................................10
Operating instructions ..............................................................................11
Custom installation use............................................................................13
Troubleshooting.........................................................................................13
Technical specifications ...........................................................................14
Limited warranty .......................................................................................15
2 Azur DAB/FM tuner
Downloaded from www.Manualslib.com manuals search engine
640T V2.0 DAB/FM tuner
INTRODUCTION
Thank you for purchasing this Cambridge Audio Azur range DAB/FM Thanks for taking the time to read this manual, we do recommend you
tuner. These version 2 models are part of our commitment to the on- keep it for future reference.
going development of the Azur range. We hope that you will appreciate
the results and enjoy many years of listening pleasure from them.
About the 640T V2.0 Matthew Bramble
Technical Director
The 640T V2.0 tuner can receive both DAB and FM broadcasts and was
developed to offer high performance for both the digital and analogue
bands. This V2.0 model now features the same WM8740 D/A converter
as used in our highly acclaimed 540C V2.0 and 640C V2.0 models. A
full range of presets are available in both FM and DAB modes.
To allow seamless integration with multi-room entertainment systems, a
Control Bus input and output have been fitted, as has an IR emitter
input. All this proprietary engineering is housed within our low
resonance, acoustically damped chassis. An Azur Navigator remote
control is also provided, giving full remote control of your tuner in an
attractive and easy to use handset.
Your V2.0 tuner can only be as good as the system it is connected to.
Please do not compromise on your amplifier, speakers or cabling.
Naturally we particularly recommend amplification from the Cambridge
Audio Azur range, which have been designed to the same exacting
standards as our tuners, connected to suitably revealing loudspeakers.
Your dealer can also supply excellent quality Cambridge Audio
interconnects to ensure your system realises its full potential. The use of
an external FM aerial is strongly recommended to get the best from your
640T V2.0.
Azur DAB/FM tuner 3
Downloaded from www.Manualslib.com manuals search engine
SAFETY PRECAUTIONS
Checking the Power Supply Rating The crossed-out wheeled bin is the European Union symbol for
indicating separate collection for electrical and electronic
For your own safety please read the following instructions carefully before attempting equipment. This product contains electrical and electronic
to connect this unit to the mains. equipment which should be reused, recycled or recovered and
should not be disposed of with unsorted regular waste. Please
Check that the rear of your unit indicates the correct supply voltage. If your mains
return the unit or contact the authorised dealer from whom you
supply voltage is different, consult your dealer.
purchased this product for more information.
This unit is designed to operate only on the supply voltage and type that is
indicated on the rear panel of the unit. Connecting to other power sources may Plug Fitting Instructions (UK Only)
damage the unit. The cord supplied with this appliance is factory fitted with a 13 amp mains plug
This equipment must be switched off when not in use and must not be used unless fitted with a 3 amp fuse inside. If it is necessary to change the fuse, it is important
correctly earthed. To reduce the risk of electric shock, do not remove the unit's that a 3 amp one is used. If the plug needs to be changed because it is not suitable
cover (or back). There are no user serviceable parts inside. Refer servicing to for your socket, or becomes damaged, it should be cut off and an appropriate plug
qualified service personnel. If the power cord is fitted with a moulded mains plug fitted following the wiring instructions below. The plug must then be disposed of
the unit must not be used if the plastic fuse carrier is not in place. Should you lose safely, as insertion into a 13 amp socket is likely to cause an electrical hazard.
the fuse carrier the correct part must be reordered from your Cambridge Audio Should it be necessary to fit a 3-pin BS mains plug to the power cord the wires
dealer. should be fitted as shown in this diagram. The colours of the wires in the mains
lead of this appliance may not correspond with the coloured markings identifying
The lightning flash with the arrowhead symbol within an equilateral the terminals in your plug. Connect them as follows:
triangle is intended to alert the user to the presence of un-insulated
`dangerous voltage' within the product's enclosure that may be of The wire which is coloured BLUE must be
sufficient magnitude to constitute a risk of electric shock to connected to the terminal which is marked
persons. with the letter `N' or coloured BLACK.
The exclamation point within an equilateral triangle is intended to The wire which is coloured BROWN must be
alert the user to the presence of important operating and connected to the terminal which is marked
maintenance instructions in the service literature relevant to this with the letter `L' or coloured RED.
appliance. The wire which is coloured GREEN/YELLOW
This product complies with European Low Voltage (73/23/EEC) must be connected to the terminal which is
and Electromagnetic Compatibility (89/336/EEC) Directives marked with the letter `E' or coloured GREEN.
when used and installed according to this instruction manual. For If your model does not have an earth wire, then disregard this instruction.
continued compliance only Cambridge Audio accessories should
be used with this product and servicing must be referred to If a 13amp (BS 1363) plug is used, a 3amp fuse must be fitted, or if any other type
qualified service personnel. of plug is used a 3amp or 5amp fuse must be fitted, either in the plug or adaptor,
or on the distribution board.
4 Azur DAB/FM tuner
Downloaded from www.Manualslib.com manuals search engine
640T V2.0 DAB/FM tuner
IMPORTANT SAFETY INSTRUCTIONS
Please take a moment to read these notes before installing your Azur tuner, they will enable you Ensure that small objects do not fall through any ventilation grille. If this happens, switch off
to get the best performance and prolong the life of the product. We advise you follow all immediately, disconnect from the mains supply and contact your dealer for advice.
instructions, heed all warnings and keep the instructions for future reference.
Refer all servicing to qualified service personnel. Servicing is required when the unit has been
Only use the specified attachments/accessories with this unit. damaged in any way, such as a damaged power-supply cord or plug, liquid has been spilled or
objects have fallen into the unit, the unit has been exposed to rain or moisture, does not operate
This unit must be installed on a sturdy, level surface. Do not place in a sealed area such as a normally, or has been dropped.
bookcase or in a cabinet. Any space open at the back (such as a dedicated equipment rack) is
fine however. If you have checked the Troubleshooting section in this manual with no improvement, do not
attempt to repair, disassemble or reconstruct the unit. A serious electric shock could result if this
When a cart is used, use caution when moving the cart to avoid injury from tip-over. precautionary measure is ignored.
The unit requires ventilation. Do not situate it on a rug or other soft surface and do
not obstruct any air inlets or outlet grilles. Do not install near any heat sources such
as radiators, heat registers, stoves, or other apparatus (including amplifiers) that Approvals
produce heat.
This unit conforms to ANSI/UL STD 60065, 7th Edition 2003 Rev 2006/03/20.
Since the power transformers generate a magnetic hum-field of moderate strength, a turntable Certified to CAN/CSA STD C22.2 No. 60065-03.
should not be located nearby. Do not plug your unit directly into a power amplifier unless it has
a variable output level.
3098092
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE
two blades with one wider than the other. A grounding type plug has two blades and a third CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS
grounding prong. The wide blade or the third prong are provided for your safety. If the provided COULD VOID THE USER AUTHORITY TO OPERATE THE EQUIPMENT.
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
This equipment has been tested and found to comply with the limits for a Class B digital device,
Do not route the power cable so that it can be walked upon or damaged by other items near it. pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
The unit must be installed in manner that makes disconnection of the mains plug from the against harmful interference in a residential installation. This equipment generates, uses and
mains socket outlet (or appliance connector from the rear of the unit) possible. can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
When using for the first time it is advisable that it is left on, playing music, for at least 36 hours guarantee that interference will not occur in a particular installation.
prior to critical listening. For subsequent use, a warm up period of 10-15 minutes is
recommended for maximum enjoyment. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
To turn the unit off completely switch off on the rear panel. If you do not intend to use this unit interference by one or more of the following measures:
for a long period of time, unplug it from the mains socket. Unplug this unit during lightning
storms. - Re-orient or relocate the receiving antenna.
WARNING - To reduce the risk of fire or electric shock, do not expose this unit to rain or moisture. - Increase the separation between the equipment and receiver.
This unit must not be exposed to dripping or splashing water or other liquids. No objects filled
with liquid, such as vases, shall be placed on the unit. In the event of spillage, switch off - Connect the equipment into an outlet on a circuit different from that to which the receiver is
immediately, disconnect from the mains supply and contact your dealer for advice. connected.
To clean the unit, wipe its case with a dry, lint-free cloth. Do not use any cleaning fluids - Consult the dealer or an experienced radio/TV technician for help.
containing alcohol, ammonia or abrasives. Do not spray an aerosol at or near the unit.
Azur DAB/FM tuner 5
Downloaded from www.Manualslib.com manuals search engine
REAR PANEL CONNECTIONS
Manufactured in an
ISO9002 approved facility 5 Designed in London, England
Line Output F-Type
50 Ohms
Caution On Power Off Control Bus IR Emitter Digital Outputs azur 640T DAB/FM Tuner V2.0 Input
Risk of electric shock. Aerial
Left
Do not open.
In Out In Left
Avis
Risque de choc electrique.
1 6 7 Power Rating: 230V AC ~ 50Hz
8
Ne pas ouvrir. Max Power Consumption: 15W
Achtung
