Image preview - the first page of the document
>> Download hfe_cambridge_audio_azur_840c_service documenatation <<
Text preview - extract from the document
840C
Issue Date: 07th February 2007
SERVICE MANUAL
SPECIFICATIONS:
D/A Converters Dual Analog Devices Total correlated jitter <130pS
AD1955 24 bit DAC's
Crosstalk @1kHz <-130dB
Digital Filter Analog Devices Black Fin Crosstalk @20kHz <-114dB
ADSP-BF532 32 bit DSP
Performing ATFTM Output impedance <50 ohms
Up sampling to 24 bit 384 kHz
Digital input word
widths supported 16-24 bit
Analog Filter 2 Pole Fully Differential
Linear Phase Bessel Filter Digital output word
widths supported 16, 20, 24 bit
Frequency Response 20Hz ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
