Image preview - the first page of the document
>> Download 51AKM006 documenatation <<
Text preview - extract from the document
51AKB006
9 10 11 12 13 14 15 16 17 18 19
8
7 20 21 22 23
6
1/a 5
4
3
2
Portable air conditioners
Climatizzatori portatili
2
30
24 25 26 27 29
28
32
31
33
34
38 39 40 41 42 43 44 45 46 47 48 49 50 51
35 36 37
1/b
Climatizzatori portatili
51AKB006
Portable air conditioners
Codice / Code
Z007270 Z007368 Z007423 Z007442 Z007541 Z007543
G30 G20 G20 G20 G20 G20
Modelli / models
Pos. Descrizione / Description Codice 51AKB 51AKB 51AKB 51AKB 51AKB 51AKB
Part No. 006 006 006 006G 006G 006G
1/a Assieme pann. comandi e quadro elett. C022808Y10 1 1 1 1
1/b Control panel and control box assy B031791Y20 1 1
2 Maniglia / Handle D019230X01 1 1 1 1 1 1
Mascherina comandi C021744X01 1 1 1 1
3
Controls panel C021744X16 1 1
Manopola termostato B030287X01 1 1 1 1 1 1
4
Thermostat knob
Scheda lampade B030283X01 1 1 1 1
5
Lamps card B031265X02 1 1
Manopola commutatore B030213X01 1 1 1 1 1 1
6
Selector switch knob
Termostato / Thermostat 0170309X01 1 1 1 1
7
0170309X02 1 1
Commutatore 0352505X01 1 1 1 1
8
Selector switch 0352505X02 1 1
Sportello resistenza D019290X01 1 1 1 1
9
Electric heater door D019290X02 1 1
Assieme capillare C023038Y01 1 1 1
10
Capillary assembly C023038Y02 1 1 1
Griglia di mandata aria D019289X01 1 1 1 1 1 1
11
Air discharge grille
Assieme deflettore C022795Y01 1 1 1 1
12
Baffle assembly C022795Y11 1 1
Assieme convogliatore aria C022881Y01 1 1 1 1 1 1
13
Air conveyor assembly
14 Schienale / Rear panel D019313Y01 1 1 1 1 1 1
15 Bocchetta / Outlet vent E000188X01 1 1 1 1 1 1
Assieme tubo flessibile C022846Y01 1 1 1 1 1 1
16
Flexible tube assembly
Ventosa C021846X01 1 1 1 1 1 1
17
Fastening strap with suction cup
Assieme frizione B030453Y01 1 1 1 1 1 1
18
Clutch assembly
Assieme vaschetta raccolta condensa C022745Y01 1 1 1 1 1 1
19
Drain pan assembly
Supporto galleggiante vaschetta C022746X01 1 1 1 1 1 1
20
Floating support pan
Coperchio vaschetta D019255X01 1 1 1 1 1 1
21
Tank cover
Galleggiante A054303X01 1 1 1 1 1 1
22
Floating
23 Vaschetta / Tank D019215X01 1 1 1 1 1 1
Vaschetta motorino smaltim. cond. D019222X01 1 1 1 1 1 1
24
Condensate discharge motor pan
3
Climatizzatori portatili
51AKB006
Portable air conditioners
Codice / Code
Z007270 Z007368 Z007423 Z007442 Z007541 Z007543
G30 G20 G20 G20 G20 G20
Modelli / models
Pos. Descrizione / Description Codice 51AKB 51AKB 51AKB 51AKB 51AKB 51AKB
Part No. 006 006 006 006G 006G 006G
Supporto motorino smaltim. cond. C022749X01 1 1 1 1 1 1
25
Condensate discharge motor support
Disco smaltimento condensa B030673X01 1 1 1
26
Condensate discharge disk B029145X01 1 1 1
Motorino smaltimento condensa 0352304X01 1 1 1 1
27
Condensate discharge motor 0352001X06 1 1
Termostato antibrinamento A053937X02 1 1 1 1
28
Antifreeze thermostat A053937X03 1 1
Compressore 0370609X12 1
Compressor 0370609X11 1
29
0370618X26 1
0370618X27 1 1
0370609X13 1
Klixon B029209X01 1 1 1
30
Klixon 0370618X80 1 1 1
Gommino antivibrante A053855X01 2 2 2 2 2 2
31
Grommet, motor mounting
Frontale anteriore E000186X01 1 1 1 1 1 1
32
Front panel
Clip tubo scarico condensa A043813X13 1 1 1 1 1 1
33
Clip, mounter condensate drain pipe
Clip tubo scarico in vaschetta A043813X12 1 1 1 1 2 2
34
Clip, mounterr tank drain pipe
Tappo tubo scarico condensa B030214X01 1 1 1 1 1 1
35
Condensate drain pipe plug
Tubo scarico condensa A054427X01 1 1 1 1 1 1
36
Condensate drain pipe
Tubo di scarico in vaschetta A054427X02 1 1 1 1 1 1
37
Discharge tube in the pan
Cavo di alimentazione 0350117X11 1 1 1 1 1 1
38
Service cord
Condensatore compressore 15◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
