Image preview - the first page of the document
hfe_classe_audio_cp-50_60_schematics


>> Download hfe_classe_audio_cp-50_60_schematics documenatation <<

Text preview - extract from the document
              CP-50/CP-60 GAIN REDUCTION

To change the gain to 8.5 dB:

1- Replace R101, R301 from RN60D5761 (old value) to RN60D2002 (new
   value).

2- Replace R102, R202, R302, R402 from RN60D5621 (old value) to
   RN60D2002 (new value).

   See supplied diagram
