Image preview - the first page of the document
Hannspree_Xv_JT02-37E1-000G_[SM]


>> Download Hannspree_Xv_JT02-37E1-000G_[SM] documenatation <<

Text preview - extract from the document
Service Handbook
    By Product




JT02-37E1-000G


                 Version 1.0 2006/11/20
Document Title.   JT02-37E1-000G   Service Handbook            Revision.   VER 1.0 Page No.   1 / 14


                                           Table of Contents
1. Product Disassembly SOP
    1-1      Rear Cover and Stand Disassembly
    1-2      Shielding and IO Cover Disassembly
    1-3      Power Board Disassembly
    1-4      Main Board Disassembly
    1-5      Speakers Disassembly
    1-6      Stand Bracket Disassembly
    1-7      IR Board and Power Button Board Disassembly
    1-8      Function Board Disassembly
    1-9      Front Bezel Disassembly
    1-10     Panel Bracket Disassembly
2. Connection Diagram
3. Appendix




                                                      1
Document Title.   JT02-37E1-000G      Service Handbook                       Revision.   VER 1.0 Page No.   2 / 14


1. Product Disassembly SOP
    1-1    Rear Cover and Stand Disassembly

                                                       Operation Procedure
    1. Loosen 16 screws from Rear Cover (Fig.1).
    2. Loosen 4 screws from Stand, then remove the Stand (Fig.2).
    3. Remove the Rear Cover.




                                                                                           Fig.1




                                                                                           Fig.2




                                                              2
Document Title.   JT02-37E1-000G      Service Handbook                                 Revision.   VER 1.0 Page No.   3 / 14


    1-2    IO Cover and Shielding Disassembly

                                                       Operation Procedure
    1. Loosen 3 screws from IO Cover, then remove the IO Cover (Fig.1).
    2. Loosen 18 screws from Shielding and brackets, then remove the Shielding and brackets (Fig.2).




                                                                                                       Fig.1




                                                                                                         Fig.2




                                                               3
Document Title.   JT02-37E1-000G      Service Handbook                      Revision.   VER 1.0 Page No.   4 / 14


    1-3    Power Board Disassembly

                                                      Operation Procedure
    1. Disconnect all wires from Power Board (Fig.1).
    2. Loosen 6 screws from Power Board then remove it (Fig.1).




                                                                                                           Fig.1




                                                             4
Document Title.   JT02-37E1-000G      Service Handbook                                Revision.   VER 1.0 Page No.   5 / 14


    1-4    Main Board Disassembly

                                                       Operation Procedure
    1. Disconnect all wires from Main Board, loosen 6 screws from Main Board then remove it (Fig.1).




                                                                                                         Fig.1




                                                              5
Document Title.   JT02-37E1-000G       Service Handbook                       Revision.   VER 1.0 Page No.   6 / 14


    1-5     Speakers Disassembly

                                                        Operation Procedure
    1. Loosen 8 screws from left/right speakers, then remove them (Fig.1).




                                                                                                         Fig.1




                                                               6
Document Title.   JT02-37E1-000G      Service Handbook                       Revision.   VER 1.0 Page No.   7 / 14


    1-6    Stand Bracket Disassembly

                                                       Operation Procedure
    1. Loosen 2 screws from Stand Bracket then remove it (Fig.1).




                                                                                                      Fig.1




                                                              7
Document Title.   JT02-37E1-000G     Service Handbook                               Revision.   VER 1.0 Page No.   8 / 14


    1-7    IR Board and Power Button Board Disassembly

                                                     Operation Procedure
    1. Remove all wires from IR Board and Power Button Board.
    2. Loosen 4 screws from IR Board and Power Button Board, then remove them (Fig.1).




                                                                                                             Fig.1




                                                            8
Document Title.   JT02-37E1-000G      Service Handbook                         Revision.   VER 1.0 Page No.   9 / 14


    1-8    Function Board Disassembly

                                                        Operation Procedure
    1. Loosen 2 screws from keypad module, loosen 1 screw from wire (Fig.1).
    2. Disconnect the wire, loosen 2 screws from Function Board (Fig.2).




                                                                                                    Fig.1




                                                                                                   Fig.2




                                                             9
Document Title.   JT02-37E1-000G      Service Handbook                            Revision.   VER 1.0 Page No.   10 / 14


    1-9    Front Bezel Disassembly

                                                      Operation Procedure
    1. Loosen 6 screws from Panel Bracket, then remove the Front Bezel (Fig.1).




                                                                                                                 Fig.1




                                                              10
Document Title.   JT02-37E1-000G      Service Handbook                      Revision.   VER 1.0 Page No.   11 / 14


    1-10     Panel Bracket Disassembly

                                                      Operation Procedure
    1. Loosen 10 screws from Panel Bracket (Fig.1).
    2. Loosen 14 screws from Panel (Fig.2).




                                                                                          Fig.1




                                                                                          Fig.2




                                                            11
Document Title.   JT02-37E1-000G   Service Handbook        Revision.   VER 1.0 Page No.   12 / 14


2. Connection Diagram




                                                      12
Document Title.   JT02-37E1-000G   Service Handbook        Revision.   VER 1.0 Page No.   13 / 14


3. Appendix




                                                      13
