56
55
25 A
56 51
PARTS LIST
57
53
41356801TH Rev.1
54
4
31
55
10 60 43
52
8 View A
9,47
45
41
23 44 6
18 10
60 16 32
20 15 33
9,47 12
50 61
46 38 34
7
A
3
21, 22
Figure 8-1 Lower Base Unit
29
52
37
27
14 28 17
13
36
26 58 19 24
11 59
39
3
35 2
1
View A
42 40
2
Table 8-1 Lower Base Unit (1/2)
No. Name/Rating Part No. Use Remarks ODA Part No.
1 Hopping roller shaft 3PP4083-6020P001 1 51112601
2 Bearing 4PP4083-6022P002 2 51607402
3 Hopping roller one-way clutch gear 4PB4083-6024P001 2 51228901
4 Roller-Registration 41281101 1
5 Bearing (registration) 4PP4083-6031P001 1 51607501
6 Roller-Transfer Assy 40437802 1
7 Bearing TR 40438001 1
8 Roller-Back up 41301801 1
9 Bias spring 41584101 2
10 Holder-BU 41536201 2
11 Lever-Reset L 40581801 1 50805801
12 Reset lever R 3PP4083-6054P001 1 50805901
13 Cover open switch arm 3PP4083-6058P001 1 53068901
14 Stacker cover reset spring 4PP4083-6057P001 1 50924201
15 Fuser roller idle gear 4PP4083-6080P001 1 51229101
16 Eject roller idle gear 4PP4083-6081P001 1 51229201
17 Sensor plate (inlet) 4PP4083-6083P001 3 51010701
18 Lever eject sensor Assembly 40771401 1
19 Toner sensor (adhesion) 4PP4083-6086G001 1 50405501
20 Diselectrification bar 4PB4083-6979P001 1
21 Heat Assy - OP14i 40470107 1 120V
22 Heat Assy - OP14i 40470108 1 230V
23 Roller assy-Eject 40772501 1
24 Manual Feed guide Assy 40715501 1
25 Stacker-Assy 41423101 1
26 LED head unit - 51LS 41366001 1
27 Stacker cover damper arm 4PP4083-6191G001 1 53069101
28 Frame subassy-lower 41453901 1
29 Stacker cover damper 4PB4083-6197P001 1 51229401
30
31 Motor-Pulse (main) 41301901 1
32 Motor-Pulse (regist) 40722301 1
33 Gear-Idle A (Z60/20) 41279001 1
34 Gear-Idle B (Z45/16) 41279101 1
35 Cord-LED Assembly 40241702 1
36 Image drum unit 41331601 1 ODA
Image drum unit 41331602 1 OEL
Image drum unit 41331603 1 APS
37 Toner Cartridge 40433203 1 APS(2.5k)
Toner Cartridge (Type 8) 41331701 1 ODA(4k)
Toner Cartridge (Type 8) 41331702 1 OEL(4k)
Toner Cartridge (Type 8) 41221703 1 APS(4k)
38 Reduction gear 41279201 1
41356801TH Rev.1
Table 8-1 Lower Base Unit (2/2)
No. Name/Rating Part No. Use Remarks ODA Part No.
39 FG plate (O.P.) 4PP4083-7663P001 1
40 Rubber Hopping roller 4PB4076-5447P001 1
41 Diselectritication Film 3PB4083-6089P001 1
42 LED Contact 4PP4083-6173P001 1
43 Washer C 4PP4120-1210P001 1
44 Washer B 4PP4120-1209P001 1
45 Spacer-Bearing R 41583901 1
46 Spacer-Bearing L 41584001 1
47 Bias Spring A 41599601 2 Special parts for
envelope *
48
49
50 Sensor wire Assembly 41027701 1
51 Roller-Pressure 41281001 1
52 Holder-Regist L 41279501 1
53 Holder-Regist R 41279601 1
54 Gear-Pressure 41279801 1
55 Bearing-Pressure 41279401 2
56 Spring-Tension 41281201 2
57 Plate-Contact PA 41280401 1
58 Bearing-Regist L 41279301 1
59 Gear-Regist 41279701 1
60 Bearing-Ball 41584201 2
61 Bracket-Motor 41280001 1
* This part is countermesur for envelope wrinkle.
Both side springs must be exchanged at the same time.
41356801TH Rev.1
1
Figure 8-2 Upper cover unit
41356801TH Rev.1
Table 8-2 Upper cover unit
No. Name/Rating Part No. Use Remarks ODA Part No.
1 Cover-Upper 40715101 1
41356801TH Rev.1
16
10
17
11
8
7
5
30 29
9
30 18
31
4
12 19
20 22
1 31
21
25 6
15
21 20
27 26
19
22
3
24
2
28
23
13
Figure 8-3 Base unit
41356801TH Rev.1
Table 8-3 Base unit
No. Name/Rating Part No. Use Remarks ODA Part No.
1 Plate Base 41279901 1
2 Cassette guide (L) assy 3PP4083-7670G001 1 51011201
3 Cassette guide (R) assy 3PP4083-7671G001 1 51011301
4 Sensor plate (paper supply) 4PP4083-7667P001 1 51011401
5 Plate-Insulator 41301601 1
6 Board-M7E-2 41249207 1
7 PCB Assy-HV1 41228501 1
8 Power supply unit 41087901 1
Power supply unit 41088001 1
9 Fan motor 41454401 1 56510801
10 Contact assy 41445801 1
11 AC cord 3YS4011-1315P001 1 120V 51011501
AC cord 3YS4011-1266P001 1 220~240V
12 Cassette sensor plate 3PP4083-6154P001 1
13 Cassette Assy-Paper 40473001 1
14
15 Earth plate 4PP4083-6137P001 1 51011601
16 Face up stacker cover assy 2PA4128-1143G001 1 51011301
17 Frame Assy-OP 40715213 1
18 Card assy-op panel 41445901 1
19 Link pull block 4PP4122-1170P001 2
20 Cassette lock lever 3PP4083-7653P001 2
21 Cassette lock lever spring 4PP4083-7655P001 2
22 Sheet spring 4PP4083-7666P001 2
23 Beam 3PP4083-7660P001 1
24 Sheet link L assy 4PP4083-7657G001 1
25 Sheet link R assy 4PP4083-7658G001 1
26 FG plate (2nd) 4PP4083-7662P001 1
27 FG plate (bm) 4PP4083-7665P001 1
28 Connector cord 3YS4111-3527P001 1
29 Plate Guide-PCB 41301701 1
30 Polyethylene Tape 4YC4061-5115P001 2 L=91.5mm
31 Guide-Paper H 40828301 2
32 CS-RING (CS3-SUS) 4PB4013-3501P002 2
33 Board-MN6 40755408 1 APS
Board-MN8 41047304 1 APS
41356801TH Rev.1
