CT-730D-CIRCUIT BLOCK


>> Download CT-730D-CIRCUIT BLOCK documenatation <<

Text preview - extract from the document
                           VDA730 Block
                                INVERTER                BACKLIGHT ON

                               BLIGHT DRIVER
                                                         InnoLux PANEL 350nits
                                   BIT3105




                                    KEY        UPS017        VIDIO DRIVER
                                                               AN2526FH



                                                AD BORRD
                         EAR
                                                                            AV OUT
                        PHON




                                                        DVD,CARD READ
                           AUDIO DRIVER
                                                          PROCESSOR
                             EUA5202                                                   USB,CAR
POWERL                                                     SHPE8281
                                                                                       D READ
5973D013T
                               AUDIO AMP-EN
                   BLIGHT-EN
                         MIC CHIP
                         PIC16F72                       SDRAM      FLASH
            POWER-EN                                                                 DVD LOAD
                                                                  MEMORY



                                MPEG BOARD
