Image preview - the first page of the document
>> Download hfe_mcintosh_mc207_service_vq1001_on documenatation <<
Text preview - extract from the document
POWER AMPLIFIER
SERIAL NO. VQ1001 And Above
CONTENTS
Performance Specifications ........................................ 2 Heatsink 2-Channel Schematic and PCB ............ 21 - 26
Notes ......................................................................... 2 Display Schematic and PCB ............................... 29 - 32
Rear Panel .................................................................. 3 Capacitor Schematic and PCB .................................. 33
Section Location ........................................................ 5 Power Supply Schematic and PCB ..................... 34 - 35
Block Diagram ........................................................... 6 Parts List ............................................................ 36 - 42
Interconnection Diagram ...................................... 7 - 8 Exploded Views and Parts Lists .......................... 43 - 46
Input Schematic and PCB .................................... 9 - 12 Repacking Instruction .............................................. 47
Heatsink 1-Channel Schematic and PCB ............ 13 - 18
SERVICE MANUAL
Serial Number VQ1001 And Above
PERFORMANCE SPECIFICATIONS
Power Output Intermodulation Distortion
Minimum sine wave continuous average power output per Maximum Intermodulation Distortion if instantaneous peak
channel, all channels operating is: 200 watts into 4 ohm or output per channel does not exceed twice the rated output, for
8 ohm load any combination of frequencies from 20Hz to 20,000Hz, with
all channels operating is: 0.005% for 4 or 8 ohm loads
Rated Power Band
20Hz to 20,000Hz Input Impedance
20,000 ohms Balanced
Total Harmonic Distortion 10,000 ohms Unbalanced
Maximum Total Harmonic Distortion at any power level from
250 milliwatts to rated power output is: 0.005% for 4 or 8 Wide Band Damping Factor
ohm loads Greater than 60 at 4 ohms
Greater than 140 at 8 ohms
Dynamic Headroom
1.7dB Power Requirements
100 Volts, 50/60Hz at 1440 watts
Frequency Response 110 Volts, 50/60Hz at 13.0 amps
+0, -0.25dB from 20Hz to 20,000Hz 120 Volts, 50/60Hz at 12.0 amps
+0, -3dB from 10Hz to 100,000Hz 220 Volts, 50/60Hz at 6.0 amps
230 Volts, 50/60Hz at 6.0 amps
Sensitivity 240 Volts, 50/60Hz at 6.0 amps
1.0 Volt Unbalanced with a 4 ohm Loudspeaker Note: Refer to the rear panel of the MC207 for the correct voltage.
2.0 Volt Balanced with a 4 ohm Loudspeaker
1.4 Volt Unbalanced with a 8 ohm Loudspeaker Dimensions
2.8 Volt Balanced with a 8 ohm Loudspeaker Front Panel: 17-1/2 inches (44.45cm) wide, 9-7/16 inches
(23.97cm) high. Depth behind front mounting panel is
A-Weighted Signal To Noise Ratio 18-3/4 inches (47.63cm), including clearance for connectors.
89dB (112dB below rated output)
Weight
83 pounds (37.6kg) net, 116 pounds (52.6kg) in shipping carton
NOTES
1. The heavy lines on the schematic denote the primary 4. On PC board drawings, Square pad indicates:
signal path. a. Polarized Capacitors - Positive
b. Diodes - Cathode
2. Unless otherwise noted, all voltages indicated on the c. Others - Pin 1
schematics are measured under the following conditions:
a. AC input at 120 volts, 50/60Hz. 5. WARNING
b. All voltages are +/-10% with respect to ground. A Parts marked with the symbol have critical
high impedance (10 megaohm) voltmeter must be used. characteristics. Use only replacement parts recom-
mended by the manufacturer.
3. Unless otherwise specified:
a. Resistor values are in ohms.
b. Capacitor values are microfarads (uF).
c. Inductor values are in microhenries (uH).
2
MC207
REAR PANEL
3
NOTES
4
MC207
SECTION LOCATIONS
TOP VIEW
TOP VIEW WITH COVER REMOVED
5
BLOCK DIAGRAM
6
MC207
1 INTERCONNECT
7 8
2 INPUT 050065
9 10
MC207
2 INPUT 050065
11 12
A
3B HEATSINK 1-CHANNEL 050070
13 14
MC207
A
3B HEATSINK 1-CHANNEL DRIVER SECTION 050070
15 16
A
3B HEATSINK 1-CHANNEL 050070
* Denotes components on reverse or backside of PC Board.
17 18
MC207
NOTES
19 20
A
4B
C
HEATSINK 2-CHANNEL 050064
21 22
MC207
A
4 B
C
HEATSINK 2-CHANNEL DRIVER SECTION 050064
23 24 25
A
3A 4B
B C
HEATSINK 2-CHANNEL 050064 5 DISPLAY ILLUMINATION SECTION 050066
* Denotes components on reverse or backside of PC Board.
26 27 28
MC207
5 DISPLAY METER SECTION 050066 5 DISPLAY POWER GUARD SECTION 050066
29 30
5 DISPLAY 050066
* Denotes components on reverse or backside of PC Board.
31 32
MC207
6 CAPACITOR 050063
* Denotes components on reverse or backside of PC Board.
33
7 POWER SUPPLY 050062
34
MC207
7 POWER SUPPLY 050062
35
PARTS LIST
Ref Part
No. No. Description
1 INTERCONNECT
C1 ASSEMBLY CAPACITOR 052005 C43 CAP ELECT 10UF 16V 4X5 CASE 066382
C2 ASSEMBLY CAPACITOR 052005 C44 CAP MONO 47PF 200V 10% NPO 061299
D1 DIODE BRID RECT 070139 C45 CAP ELECT 10UF 16V 4X5 CASE 066382
M1 METER MC207 124089 C46 CAP MONO 22PF 200V 10% NPO 061298
M2 METER MC207 124089 C47 CAP MONO 22PF 200V 10% NPO 061298
M3 METER MC207 124089 J1 CONN MALE 9 POS FRICTION LOCK 117244
RT1 ASSEMBLY THERMISTOR 052017 J2 JACK RCA BLK 117847
RT2 ASSEMBLY THERMISTOR 052017 J3 JACK RCA 1X2 BLK/BLK 14MM 117848
S1 SWITCH POWER 146243 J4 CONN 4 PIN 117215
S2 SWITCH POWER 146243 J5 CONN 4 PIN 117215
T1 POTTED TRANSFORMER POWER 050061 J6 RECEPTACLE XLR FEMALE 117685
TB1 TERMINAL BLOCK AC 074091 J7 RECEPTACLE XLR FEMALE 117685
TB2 POST BINDING DUAL 084124 J8 JACK RCA 1X2 BLK/BLK 14MM 117848
TB3 POST BINDING DUAL 084124 J9 CONN 4 PIN 117215
TB4 POST BINDING DUAL 084124 J10 CONN D 25-PIN 117501
TB5 POST BINDING DUAL 084124 J11 CONN 4 PIN 117215
TB6 POST BINDING DUAL 084124 J12 RECEPTACLE XLR FEMALE 117685
TB7 POST BINDING DUAL 084124 J13 RECEPTACLE XLR FEMALE 117685
TB8 POST BINDING DUAL 084124 J14 RECEPTACLE XLR FEMALE 117685
J16 JACK RCA 1X2 BLK/BLK 14MM 117848
J17 CONN 4 PIN 117215
2 050065 INPUT PCB J18 RECEPTACLE XLR FEMALE 117685
C1 CAP ELECT 10UF 16V 4X5 CASE 066382 J19 JACK HEADPHONE DUAL BLACK 1/8 117825
C2 CAP ELECT 10UF 16V 4X5 CASE 066382 J20 RECEPTACLE XLR FEMALE 117685
C3 CAP MONO 47PF 200V 10% NPO 061299 R1 RES MF 1K 1% 1/4W 144090
C4 CAP MONO 47PF 200V 10% NPO 061299 R2 RES MF 1K 1% 1/4W 144090
C5 CAP ELECT 10UF 16V 4X5 CASE 066382 R3 RES MF 20K 1% 1/4W 144104
C6 CAP ELECT 10UF 16V 4X5 CASE 066382 R4 RES MF 221 OHM 1% 1/4W 144172
C7 CAP MONO .1uF 50V 20% Z5U 061305 R5 RES MF 20K 1% 1/4W 144104
C8 CAP MONO .1uF 50V 20% Z5U 061305 R6 RES MF 221 OHM 1% 1/4W 144172
C9 CAP MONO 22PF 200V 10% NPO 061298 R7 RES MF 100K 1% 1/4W 144113
C10 CAP MONO 22PF 200V 10% NPO 061298 R8 RES MF 100K 1% 1/4W 144113
C11 CAP MONO 47PF 200V 10% NPO 061299 R9 RES MF 20K 1% 1/4W 144104
C12 CAP ELECT 10UF 50V 066445 R10 RES MF 20K 1% 1/4W 144104
C13 CAP MONO 47PF 200V 10% NPO 061299 R11 RES MF 10K 1% 1/4W 144053
C14 CAP ELECT 10UF 50V 066445 R12 RES MF 10K 1% 1/4W 144053
C15 CAP ELECT 10UF 16V 4X5 CASE 066382 R13 RES MF 10 OHM 1% 1/4W 144157
C16 CAP ELECT 10UF 16V 4X5 CASE 066382 R14 RES MF 10K 1% 1/4W 144053
C17 CAP MONO 47PF 200V 10% NPO 061299 R16 RES MF 100K 1% 1/4W 144113
C18 CAP ELECT 10UF 16V 4X5 CASE 066382 R17 RES MF 10K 1% 1/4W 144053
C19 CAP MONO 47PF 200V 10% NPO 061299 R18 RES MF 100K 1% 1/4W 144113
C20 CAP MONO .1uF 50V 20% Z5U 061305 R19 RES MF 10 OHM 1% 1/4W 144157
C21 CAP MONO .1uF 50V 20% Z5U 061305 R20 RES MF 1K 1% 1/4W 144090
C22 CAP ELECT 10UF 16V 4X5 CASE 066382 R21 RES MF 20K 1% 1/4W 144104
C23 CAP MONO 22PF 200V 10% NPO 061298 R22 RES MF 221 OHM 1% 1/4W 144172
C24 CAP MONO .1uF 50V 20% Z5U 061305 R23 RES MF 1K 1% 1/4W 144090
C25 CAP MONO .1uF 50V 20% Z5U 061305 R24 RES MF 100K 1% 1/4W 144113
C26 CAP MONO 47PF 200V 10% NPO 061299 R25 RES MF 20K 1% 1/4W 144104
C27 CAP MONO 22PF 200V 10% NPO 061298 R26 RES MF 20K 1% 1/4W 144104
C28 CAP MONO 47PF 200V 10% NPO 061299 R27 RES MF 221 OHM 1% 1/4W 144172
C29 CAP ELECT 10UF 16V 4X5 CASE 066382 R28 RES MF 100K 1% 1/4W 144113
C30 CAP MONO 47PF 200V 10% NPO 061299 R29 RES MF 10K 1% 1/4W 144053
C31 CAP ELECT 10UF 16V 4X5 CASE 066382 R30 RES MF 20K 1% 1/4W 144104
C32 CAP MONO 22PF 200V 10% NPO 061298 R31 RES MF 10K 1% 1/4W 144053
C33 CAP MONO 47PF 200V 10% NPO 061299 R33 RES MF 100K 1% 1/4W 144113
C34 CAP ELECT 10UF 16V 4X5 CASE 066382 R34 RES MF 10K 1% 1/4W 144053
C35 CAP MONO 47PF 200V 10% NPO 061299 R35 RES MF 10K 1% 1/4W 144053
C36 CAP ELECT 10UF 16V 4X5 CASE 066382 R37 RES MF 100K 1% 1/4W 144113
C38 CAP MONO 22PF 200V 10% NPO 061298 R38 RES MF 1K 1% 1/4W 144090
C39 CAP MONO .1uF 50V 20% Z5U 061305 R39 RES MF 20K 1% 1/4W 144104
C40 CAP MONO .1uF 50V 20% Z5U 061305 R40 RES MF 221 OHM 1% 1/4W 144172
C41 CAP MONO 47PF 200V 10% NPO 061299 R41 RES MF 100K 1% 1/4W 144113
36
MC207
PARTS LIST con't
R42 RES MF 20K 1% 1/4W 144104 J2 CONN 4 PIN 117215
R43 RES MF 10K 1% 1/4W 144053 J4 CONN HEADER 2 PIN 0.156 117404
R44 RES MF 10K 1% 1/4W 144053 J5 BLADE FASTON .110 117712
R45 RES MF 100K 1% 1/4W 144113 J6 BLADE FASTON W/FEET 117708
R46 RES MF 100 OHM 1% 1/4W 144196 J8 CONN HEADER 2 PIN 0.156 117404
R47 RES MF 1K 1% 1/4W 144090 J9 CONN 2 PIN MALE 117213
R48 RES MF 20K 1% 1/4W 144104 K1 RELAY 24VDC 5A 277VAC 087057
R49 RES MF 221 OHM 1% 1/4W 144172 K2 RELAY 24VDC 5A 277VAC 087057
R50 RES MF 100K 1% 1/4W 144113 L2 CHOKE 0.65UH OUTPUT 122297
R51 RES MF 20K 1% 1/4W 144104 LD1 LDR NETWORK 144179
R55 RES MF 10K 1% 1/4W 144053 Q1 TRANSISTOR NPN 132223
R56 RES MF 10K 1% 1/4W 144053 Q2 TRANSISTOR PNP 132224
R58 RES MF 100K 1% 1/4W 144113 Q3 TRANSISTOR NPN 132268
R59 RES MF 1K 1% 1/4W 144090 Q4 TRANSISTOR PNP 132267
R60 RES MF 20K 1% 1/4W 144104 Q5 TRANSISTOR NPN 132223
R61 RES MF 221 OHM 1% 1/4W 144172 Q6 TRANSISTOR NPN 132285
R62 RES MF 100K 1% 1/4W 144113 Q7 TRANSISTOR PNP 132286
R63 RES MF 20K 1% 1/4W 144104 Q8 TRANSISTOR PNP POWER 132297
R64 RES MF 100 OHM 1% 1/4W 144196 Q9 TRANSISTOR NPN POWER 132296
R65 RES MF 10K 1% 1/4W 144053 Q10 TRANSISTOR PNP POWER 132297
R66 RES MF 10K 1% 1/4W 144053 Q11 TRANSISTOR NPN POWER 132296
R68 RES MF 100K 1% 1/4W 144113 Q20 TRANSISTOR NPN POWER 132296
S1 SWITCH SLIDE 148059 Q22 TRANSISTOR PNP POWER 132297
SP1 BRACKET PCB CARD MOUNTING 003611 Q23 TRANSISTOR NPN POWER 132296
U1 IC DUAL OPERATIONAL AMPLIFIER 133260 Q25 TRANSISTOR PNP POWER 132297
U2 IC DUAL OPERATIONAL AMPLIFIER 133260 Q27 TRANSISTOR PNP 132224
U3 IC DUAL OPERATIONAL AMPLIFIER 133260 Q29 TRANSISTOR PNP POWER 132255
U4 IC DUAL OPERATIONAL AMPLIFIER 133260 Q30 TRANSISTOR SI NPN 25V 132254
Q31 TRANSISTOR NPN 132223
3A Q32 TRANSISTOR NPN 132223
050070 HEATSINK 1-CHANNEL PCB Q33 TRANSISTOR PNP POWER 132255
3B
C1 CAP ELECT 47UF 35V 066446 Q35 TRANSISTOR NPN 132223
C2 CAP ELECT 47UF 35V 066446 Q37 TRANSISTOR NPN 132285
C3 CAP MONO .1uF 50V 20% Z5U 061305 Q39 TRANSISTOR PNP 132286
C4 CAP POLYPROP 0.15UF 10% 250VDC 064363 Q41 TRANSISTOR PNP 132224
C7 CAP MONO 100PF 100V 10% NPO 061300 Q49 TRANSISTOR PNP 132224
C8 CAP MONO 100PF 100V 10% NPO 061300 Q50 TRANSISTOR NPN 132223
C9 CAP MONO .01UF 50V 20% X7R 061304 Q51 TRANSISTOR NPN 132223
C14 CAP MONO 100PF 100V 10% NPO 061300 Q52 TRANSISTOR NPN 132223
C16 CAP MONO .01UF 50V 20% X7R 061304 Q53 TRANSISTOR PNP POWER 132255
C22 CAP ELECT 220UF 25V 066507 Q54 TRANSISTOR PNP 132224
C27 CAP MONO 100PF 100V 10% NPO 061300 Q55 TRANSISTOR PNP POWER 132255
C30 CAP ELECT 47UF 35V 066446 Q56 TRANSISTOR PNP POWER 132255
C31 CAP ELECT .47UF 50V 066244 Q59 TRANSISTOR NPN 132223
C32 CAP MONO .1uF 50V 20% Z5U 061305 Q60 TRANSISTOR SI NPN 25V 132254
C33 CAP MONO .1uF 50V 20% Z5U 061305 Q61 TRANSISTOR SI NPN 25V 132254
C35 CAP ELECT 10UF 100VDC 066462 Q63 TRANSISTOR NPN 132223
C36 CAP ELECT 10UF 100VDC 066462 Q64 TRANSISTOR PNP POWER 132255
C37 CAP ELECT 10UF 100VDC 066462 R1 RES MF 332 OHM 1% 1/4W 144446
C38 CAP ELECT 10UF 100VDC 066462 R2 RES MET OX 680 OHM 5% .5W 137093
C40 CAP ELECT 220UF 50V 20% 066254 R3 RES MF 22.1K 1% 1/4W 144187
C41 CAP ELECT 10UF 100VDC 066462 R4 RES MF 100K 1% 1/4W 144113
C47 CAP POLYPROP .047UF 10% 250VDC 064364 R5 RES MF 22.1K 1% 1/4W 144187
C51 CAP ELECT 10UF 100VDC 066462 R6 RES MET OX 1.8k 5% .5W 137094
C200 CAP ELECT 10UF 100VDC 066462 R7 RES MET OX 430 OHM 5% .5W 137095
D1 DIODE SILICON 070047 R8 RES MF 332 OHM 1% 1/4W 144446
D2 DIODE SILICON 070047 R9 RES MET OX 680 OHM 5% .5W 137093
D4 DIODE SILICON 070047 R10 RES MF 22.1K 1% 1/4W 144187
D5 DIODE SILICON 070047 R11 RES MET OX 1.8k 5% .5W 137094
D6 DIODE RECTIFIER 070131 R12 RES MET OX 47 OHM 5% .5W 137096
D7 DIODE RECTIFIER 070131 R13 POT TRIM 200 OHM 20% HORIZ AD 134390
IC2 IC DUAL AMP 133259 R14 RES MF 100K 1% 1/4W 144113
J1 CONN MALE 9 POS FRICTION LOCK 117244 R15 RES MF 100 OHM 1% 1/4W 144196
37
PARTS LIST con't
R16 RES MF 100 OHM 1% 1/4W 144196 C3 CAP MONO .1uF 50V 20% Z5U 061305
R17 RES MF 100 OHM 1% 1/4W 144196 C4 CAP POLYPROP 0.15UF 10% 250VDC 064363
R30 RES MF 475K 1% 1/4W 144364 C7 CAP MONO 100PF 100V 10% NPO 061300
R32 RES MF 47.5K 1% 1/4W 144108 C8 CAP MONO 100PF 100V 10% NPO 061300
R33 RES MF 47.5K 1% 1/4W 144108 C9 CAP MONO .01UF 50V 20% X7R 061304
R34 RES MF 5.11K 1% 1/4W 144083 C10 CAP ELECT 47UF 35V 066446
R36 RES 511 OHM 1% 1/4W 144123 C11 CAP ELECT 47UF 35V 066446
R37 RES MF 681K 1% 1/4W 144443 C12 CAP MONO 100PF 100V 10% NPO 061300
R38 RES MF 866 OHM 1% 1/4W 144028 C13 CAP MONO 100PF 100V 10% NPO 061300
R39 RES MF 2.21 OHM 1/4W 1% 144378 C14 CAP MONO 100PF 100V 10% NPO 061300
R41 RES WW DUAL .47 OHM 5% 3W 139244 C15 CAP MONO .1uF 50V 20% Z5U 061305
R42 RES WW DUAL .47 OHM 5% 3W 139244 C16 CAP MONO .01UF 50V 20% X7R 061304
R43 RES WW DUAL .47 OHM 5% 3W 139244 C17 CAP MONO .01UF 50V 20% X7R 061304
R45 RES WW DUAL .47 OHM 5% 3W 139244 C18 CAP MONO .01UF 50V 20% X7R 061304
R46 RES MF 4.75K 1% 1/4W 144097 C19 CAP MONO 100PF 100V 10% NPO 061300
R48 RES MF 100 OHM 1% 1/4W 144196 C22 CAP ELECT 220UF 25V 066507
R50 RES MF 14.7K 1% 1/4W 144149 C27 CAP MONO 100PF 100V 10% NPO 061300
R51 RES MF 221 OHM 1% 1/4W 144172 C28 CAP MONO 100PF 100V 10% NPO 061300
R52 RES MF 267K 1% 1/4W 144118 C29 CAP ELECT 47UF 35V 066446
R53 RES MF 221 OHM 1% 1/4W 144172 C30 CAP ELECT 47UF 35V 066446
R54 RES MF 3.32K 1% 1/4W 144095 C31 CAP ELECT .47UF 50V 066244
R55 RES MF 3.32K 1% 1/4W 144095 C32 CAP MONO .1uF 50V 20% Z5U 061305
R56 RES MF 10K 1% 1/4W 144053 C33 CAP MONO .1uF 50V 20% Z5U 061305
R57 RES MF 475K 1% 1/4W 144364 C35 CAP ELECT 10UF 100VDC 066462
R58 RES MF 1.1K 1% 1/4W 144091 C36 CAP ELECT 10UF 100VDC 066462
R59 RES MF 2.21 OHM 1/4W 1% 144378 C37 CAP ELECT 10UF 100VDC 066462
R60 RES FP 22 OHM 1/4W 5% 137033 C38 CAP ELECT 10UF 100VDC 066462
R62 RES MF 22.1K 1% 1/4W 144187 C39 CAP ELECT .47UF 50V 066244
R63 RES FP 22 OHM 1/4W 5% 137033 C40 CAP ELECT 220UF 50V 20% 066254
R65 RES MF 681K 1% 1/4W 144443 C41 CAP ELECT 10UF 100VDC 066462
R67 RES MF 100 OHM 1% 1/4W 144196 C44 CAP ELECT 220UF 25V 066507
R70 RES MF 100 OHM 1% 1/4W 144196 C47 CAP POLYPROP .047UF 10% 250VDC 064364
R71 RES MF 100 OHM 1% 1/4W 144196 C48 CAP POLYPROP .047UF 10% 250VDC 064364
R72 RES MF 100 OHM 1% 1/4W 144196 C50 CAP ELECT 10UF 100VDC 066462
R77 RES MF 1M 1/4W 144269 C51 CAP ELECT 10UF 100VDC 066462
R79 RES CF 10 OHM 5% 1/2W 141165 C200 CAP ELECT 10UF 100VDC 066462
R82 RES MF 1M 1/4W 144269 D1 DIODE SILICON 070047
R83 RES MF 10K 1% 1/4W 144053 D2 DIODE SILICON 070047
R84 RES MF 47.5K 1% 1/4W 144108 D4 DIODE SILICON 070047
R85 RES MF 1.1K 1% 1/4W 144091 D5 DIODE SILICON 070047
R86 RES MF 4.75K 1% 1/4W 144097 D6 DIODE RECTIFIER 070131
R88 RES MF 12.1K 1% 1/4W 144154 D7 DIODE RECTIFIER 070131
R90 RES MF 1.1K 1% 1/4W 144091 D8 DIODE SILICON 070047
R93 RES MF 4.75K 1% 1/4W 144097 D9 DIODE SILICON 070047
R101 RES MF 953 OHM 1/4W 1% 144473 D11 DIODE SILICON 070047
R103 RES MF 332K 1% 1/4W 144119 D12 DIODE SILICON 070047
R104 RES MF 15K 1% 1/4W 144412 D13 DIODE RECTIFIER 070131
R105 RES MF 6.49K 1% 1/4W 144140 D14 DIODE RECTIFIER 070131
R106 RES MF 475 OHM 1% 1/4W 144086 IC1 IC DUAL AMP 133259
R109 RES CF 0 OHM 5% 1/4W 141389 IC2 IC DUAL AMP 133259
R111 RES MET OX 430 OHM 5% .5W 137095 J1 CONN MALE 9 POS FRICTION LOCK 117244
R114 RES CF 10 OHM 5% 1/2W 141165 J2 CONN 4 PIN 117215
R119 RES MO 4.7 OHM 1W 5% 144464 J3 CONN HEADER 2 PIN 0.156 117404
R122 RES MF 47.5K 1% 1/4W 144108 J4 CONN HEADER 2 PIN 0.156 117404
R123 RES MF 22.1K 1% 1/4W 144187 J5 BLADE FASTON .110 117712
R124 RES MF 47.5K 1% 1/4W 144108 J6 BLADE FASTON W/FEET 117708
RT1 SENSOR THERMAL 144249 J8 CONN HEADER 2 PIN 0.156 117404
RT2 SENSOR THERMAL 144249 J9 CONN 2 PIN MALE 117213
4A
J10 CONN 2 PIN MALE 117213
K1 RELAY 24VDC 5A 277VAC 087057
4B 050064 HEATSINK 2-CHANNEL PCB K2 RELAY 24VDC 5A 277VAC 087057
4B C1 CAP ELECT 47UF 35V 066446 L1 CHOKE 0.65UH OUTPUT 122297
C2 CAP ELECT 47UF 35V 066446 L2 CHOKE 0.65UH OUTPUT 122297
38
MC207
PARTS LIST con't
LD1 LDR NETWORK 144179 Q62 TRANSISTOR PNP 132224
LD2 LDR NETWORK 144179 Q63 TRANSISTOR NPN 132223
Q1 TRANSISTOR NPN 132223 Q64 TRANSISTOR PNP POWER 132255
Q2 TRANSISTOR PNP 132224 R1 RES MF 332 OHM 1% 1/4W 144446
Q3 TRANSISTOR NPN 132268 R2 RES MET OX 680 OHM 5% .5W 137093
Q4 TRANSISTOR PNP 132267 R3 RES MF 22.1K 1% 1/4W 144187
Q5 TRANSISTOR NPN 132223 R4 RES MF 100K 1% 1/4W 144113
Q6 TRANSISTOR NPN 132285 R5 RES MF 22.1K 1% 1/4W 144187
Q7 TRANSISTOR PNP 132286 R6 RES MET OX 1.8k 5% .5W 137094
Q8 TRANSISTOR PNP POWER 132297 R7 RES MET OX 430 OHM 5% .5W 137095
Q9 TRANSISTOR NPN POWER 132296 R8 RES MF 332 OHM 1% 1/4W 144446
Q10 TRANSISTOR PNP POWER 132297 R9 RES MET OX 680 OHM 5% .5W 137093
Q11 TRANSISTOR NPN POWER 132296 R10 RES MF 22.1K 1% 1/4W 144187
Q12 TRANSISTOR NPN 132223 R11 RES MET OX 1.8k 5% .5W 137094
Q13 TRANSISTOR PNP 132224 R12 RES MET OX 47 OHM 5% .5W 137096
Q14 TRANSISTOR NPN 132223 R13 POT TRIM 200 OHM 20% HORIZ AD 134390
Q15 TRANSISTOR PNP 132286 R14 RES MF 100K 1% 1/4W 144113
Q16 TRANSISTOR NPN 132285 R15 RES MF 100 OHM 1% 1/4W 144196
Q17 TRANSISTOR PNP 132267 R16 RES MF 100 OHM 1% 1/4W 144196
Q18 TRANSISTOR NPN 132268 R17 RES MF 100 OHM 1% 1/4W 144196
Q19 TRANSISTOR NPN POWER 132296 R18 RES MET OX 47 OHM 5% .5W 137096
Q20 TRANSISTOR NPN POWER 132296 R19 RES MET OX 1.8k 5% .5W 137094
Q21 TRANSISTOR PNP POWER 132297 R20 RES MF 332 OHM 1% 1/4W 144446
Q22 TRANSISTOR PNP POWER 132297 R21 RES MF 22.1K 1% 1/4W 144187
Q23 TRANSISTOR NPN POWER 132296 R22 RES MET OX 680 OHM 5% .5W 137093
Q24 TRANSISTOR NPN POWER 132296 R23 RES MET OX 430 OHM 5% .5W 137095
Q25 TRANSISTOR PNP POWER 132297 R24 RES MET OX 680 OHM 5% .5W 137093
Q26 TRANSISTOR PNP POWER 132297 R25 RES MF 22.1K 1% 1/4W 144187
Q27 TRANSISTOR PNP 132224 R26 RES MET OX 1.8k 5% .5W 137094
Q28 TRANSISTOR SI NPN 25V 132254 R27 RES MF 332 OHM 1% 1/4W 144446
Q29 TRANSISTOR PNP POWER 132255 R28 POT TRIM 200 OHM 20% HORIZ AD 134390
Q30 TRANSISTOR SI NPN 25V 132254 R29 RES MF 475K 1% 1/4W 144364
Q31 TRANSISTOR NPN 132223 R30 RES MF 475K 1% 1/4W 144364
Q32 TRANSISTOR NPN 132223 R31 RES MF 5.11K 1% 1/4W 144083
Q33 TRANSISTOR PNP POWER 132255 R32 RES MF 47.5K 1% 1/4W 144108
Q34 TRANSISTOR NPN 132223 R33 RES MF 47.5K 1% 1/4W 144108
Q35 TRANSISTOR NPN 132223 R34 RES MF 5.11K 1% 1/4W 144083
Q36 TRANSISTOR NPN 132285 R35 RES MF 47.5K 1% 1/4W 144108
Q37 TRANSISTOR NPN 132285 R36 RES 511 OHM 1% 1/4W 144123
Q38 TRANSISTOR PNP POWER 132255 R37 RES MF 681K 1% 1/4W 144443
Q39 TRANSISTOR PNP 132286 R38 RES MF 866 OHM 1% 1/4W 144028
Q40 TRANSISTOR PNP 132224 R39 RES MF 2.21 OHM 1/4W 1% 144378
Q41 TRANSISTOR PNP 132224 R40 RES WW DUAL .47 OHM 5% 3W 139244
Q42 TRANSISTOR NPN 132223 R41 RES WW DUAL .47 OHM 5% 3W 139244
Q43 TRANSISTOR PNP 132224 R42 RES WW DUAL .47 OHM 5% 3W 139244
Q44 TRANSISTOR PNP POWER 132255 R43 RES WW DUAL .47 OHM 5% 3W 139244
Q45 TRANSISTOR PNP POWER 132255 R44 RES WW DUAL .47 OHM 5% 3W 139244
Q46 TRANSISTOR PNP 132224 R45 RES WW DUAL .47 OHM 5% 3W 139244
Q47 TRANSISTOR SI NPN 25V 132254 R46 RES MF 4.75K 1% 1/4W 144097
Q48 TRANSISTOR PNP 132286 R47 RES MF 4.75K 1% 1/4W 144097
Q49 TRANSISTOR PNP 132224 R48 RES MF 100 OHM 1% 1/4W 144196
Q50 TRANSISTOR NPN 132223 R49 RES MF 1.1K 1% 1/4W 144091
Q51 TRANSISTOR NPN 132223 R50 RES MF 14.7K 1% 1/4W 144149
Q52 TRANSISTOR NPN 132223 R51 RES MF 221 OHM 1% 1/4W 144172
Q53 TRANSISTOR PNP POWER 132255 R52 RES MF 267K 1% 1/4W 144118
Q54 TRANSISTOR PNP 132224 R53 RES MF 221 OHM 1% 1/4W 144172
Q55 TRANSISTOR PNP POWER 132255 R54 RES MF 3.32K 1% 1/4W 144095
Q56 TRANSISTOR PNP POWER 132255 R55 RES MF 3.32K 1% 1/4W 144095
Q57 TRANSISTOR SI NPN 25V 132254 R56 RES MF 10K 1% 1/4W 144053
Q58 TRANSISTOR NPN 132223 R57 RES MF 475K 1% 1/4W 144364
Q59 TRANSISTOR NPN 132223 R58 RES MF 1.1K 1% 1/4W 144091
Q60 TRANSISTOR SI NPN 25V 132254 R59 RES MF 2.21 OHM 1/4W 1% 144378
Q61 TRANSISTOR SI NPN 25V 132254 R60 RES FP 22 OHM 1/4W 5% 137033
39
PARTS LIST con't
R61 RES MF 100 OHM 1% 1/4W 144196 5 050066 DISPLAY PCB
R62 RES MF 22.1K 1% 1/4W 144187 C1 CAP ELECT 10UF 50V 066445
R63 RES FP 22 OHM 1/4W 5% 137033 C2 CAP MPF 0.47UF 5% 50/63VDC 064333
R64 RES MF 10K 1% 1/4W 144053 C3 CAP MONO .1uF 50V 20% Z5U 061305
R65 RES MF 681K 1% 1/4W 144443 C4 CAP MONO .1uF 50V 20% Z5U 061305
R66 RES MF 681K 1% 1/4W 144443 C5 CAP MPF 0.1UF 5% 63VDC 064325
R67 RES MF 100 OHM 1% 1/4W 144196 C6 CAP ELECT 10UF 50V 066445
R68 RES MF 475K 1% 1/4W 144364 C7 CAP MPF 0.47UF 5% 50/63VDC 064333
R69 RES MF 22.1K 1% 1/4W 144187 C8 CAP MONO .1uF 50V 20% Z5U 061305
R70 RES MF 100 OHM 1% 1/4W 144196 C9 CAP MONO .1uF 50V 20% Z5U 061305
R71 RES MF 100 OHM 1% 1/4W 144196 C10 CAP MPF 0.1UF 5% 63VDC 064325
R72 RES MF 100 OHM 1% 1/4W 144196 C11 CAP ELECT 10UF 50V 066445
R73 RES MF 100 OHM 1% 1/4W 144196 C12 CAP MPF 0.47UF 5% 50/63VDC 064333
R74 RES MF 100 OHM 1% 1/4W 144196 C13 CAP MONO .1uF 50V 20% Z5U 061305
R75 RES MF 267K 1% 1/4W 144118 C14 CAP ELECT 100UF 16V OR 25V 066447
R76 RES MF 221 OHM 1% 1/4W 144172 C15 CAP MPF 0.1UF 5% 63VDC 064325
R77 RES MF 1M 1/4W 144269 C16 CAP MONO .1uF 50V 20% Z5U 061305
R78 RES MF 100 OHM 1% 1/4W 144196 D1 DIODE SILICON 070047
R79 RES CF 10 OHM 5% 1/2W 141165 D2 DIODE SILICON 070047
R80 RES CF 10 OHM 5% 1/2W 141165 D3 DIODE SILICON 070047
R81 RES MF 100 OHM 1% 1/4W 144196 D4 DIODE SILICON 070047
R82 RES MF 1M 1/4W 144269 D5 DIODE SILICON 070047
R83 RES MF 10K 1% 1/4W 144053 D6 DIODE SILICON 070047
R84 RES MF 47.5K 1% 1/4W 144108 D7 DIODE SILICON 070047
R85 RES MF 1.1K 1% 1/4W 144091 D8 DIODE SILICON 070047
R86 RES MF 4.75K 1% 1/4W 144097 D9 DIODE SILICON 070047
R87 RES MF 14.7K 1% 1/4W 144149 D10 DIODE SILICON 070047
R88 RES MF 12.1K 1% 1/4W 144154 D11 DIODE SILICON 070047
R89 RES MF 953 OHM 1/4W 1% 144473 D12 DIODE SILICON 070047
R90 RES MF 1.1K 1% 1/4W 144091 D13 DIODE SILICON 070047
R91 RES MF 681K 1% 1/4W 144443 D14 DIODE SILICON 070047
R92 RES MF 866 OHM 1% 1/4W 144028 D15 DIODE SILICON 070047
R93 RES MF 4.75K 1% 1/4W 144097 D16 DIODE SILICON 070047
R94 RES MF 47.5K 1% 1/4W 144108 D17 DIODE SILICON 070047
R95 RES MF 1.1K 1% 1/4W 144091 D18 DIODE SILICON 070047
R96 RES MF 3.32K 1% 1/4W 144095 D19 DIODE SILICON 070047
R97 RES 511 OHM 1% 1/4W 144123 D20 DIODE SILICON 070047
R98 RES MF 3.32K 1% 1/4W 144095 D21 DIODE SILICON 070047
R99 RES MF 221 OHM 1% 1/4W 144172 D22 DIODE SILICON 070047
R100 RES MF 1.1K 1% 1/4W 144091 D23 DIODE SILICON 070047
R101 RES MF 953 OHM 1/4W 1% 144473 D24 DIODE SILICON 070047
R102 RES MF 332K 1% 1/4W 144119 D25 DIODE SILICON 070047
R103 RES MF 332K 1% 1/4W 144119 D26 DIODE SILICON 070047
R104 RES MF 15K 1% 1/4W 144412 D27 DIODE SILICON 070047
R105 RES MF 6.49K 1% 1/4W 144140 D28 DIODE SILICON 070047
R106 RES MF 475 OHM 1% 1/4W 144086 D29 DIODE SILICON 070047
R107 RES MF 475 OHM 1% 1/4W 144086 D30 DIODE SILICON 070047
R108 RES MF 6.49K 1% 1/4W 144140 DS1 LED BLUE 5MM HI-INTENSITY 058166
R109 RES CF 0 OHM 5% 1/4W 141389 DS2 LED BLUE 5MM HI-INTENSITY 058166
R110 RES MET OX 430 OHM 5% .5W 137095 DS3 LED GREEN 5MM HI-INTENSITY 058165
R111 RES MET OX 430 OHM 5% .5W 137095 DS4 LED GREEN 5MM HI-INTENSITY 058165
R112 RES MF 1M 1/4W 144269 DS5 LED RED HIGH EFFICIENCY 058148
R113 RES CF 10 OHM 5% 1/2W 141165 DS6 LED BLUE 5MM HI-INTENSITY 058166
R114 RES CF 10 OHM 5% 1/2W 141165 DS7 LED BLUE 5MM HI-INTENSITY 058166
R115 RES MF 1M 1/4W 144269 DS8 LED GREEN 5MM HI-INTENSITY 058165
R119 RES MO 4.7 OHM 1W 5% 144464 DS9 LED GREEN 5MM HI-INTENSITY 058165
R120 RES MO 4.7 OHM 1W 5% 144464 DS10 LED BLUE 5MM HI-INTENSITY 058166
R122 RES MF 47.5K 1% 1/4W 144108 DS11 LED BLUE 5MM HI-INTENSITY 058166
R123 RES MF 22.1K 1% 1/4W 144187 DS12 LED GREEN 5MM HI-INTENSITY 058165
R124 RES MF 47.5K 1% 1/4W 144108 DS13 LED GREEN 5MM HI-INTENSITY 058165
RT1 SENSOR THERMAL 144249 DS14 LED GREEN 5MM HI-INTENSITY 058165
RT2 SENSOR THERMAL 144249 DS15 LED GREEN 5MM HI-INTENSITY 058165
DS16 LED GREEN 5MM HI-INTENSITY 058165
40
MC207
PARTS LIST con't
DS17 LED AMBER 058133 R9 RES MF 221 OHM 1% 1/4W 144172
DS18 LED AMBER 058133 R10 RES MF 1.5K 1% 1/4W 144128
DS19 LED AMBER 058133 R11 POT TRIM 500 OHM 20% HORIZ ADJ 134410
DS20 LED AMBER 058133 R12 RES MF 221 OHM 1% 1/4W 144172
DS21 LED AMBER 058133 R13 RES MF 5.62K OHM 1% 1/4W 144447
DS22 LED AMBER 058133 R14 POT TRIM 500 OHM 20% HORIZ ADJ 134410
DS23 LED AMBER 058133 R15 RES MF 221 OHM 1% 1/4W 144172
J1 CONN MALE 9 POS FRICTION LOCK 117244 R16 POT TRIM 500 OHM 20% HORIZ ADJ 134410
J2 CONN MALE 9 POS FRICTION LOCK 117244 R17 RES MF 221 OHM 1% 1/4W 144172
J3 CONN MALE 9 POS FRICTION LOCK 117244 R18 POT TRIM 500 OHM 20% HORIZ ADJ 134410
J4 CONN MALE 9 POS FRICTION LOCK 117244 R19 RES MF 221 OHM 1% 1/4W 144172
J5 CONN MALE 9 POS FRICTION LOCK 117244 R20 POT TRIM 500 OHM 20% HORIZ ADJ 134410
J6 CONN MALE 9 POS FRICTION LOCK 117244 R21 RES MF 221 OHM 1% 1/4W 144172
J7 CONN 3 POS MALE MTS100 NORM 117214 R22 RES MF 27.4K 1% 1/4W 144141
J8 CONN 4 PIN 117215 R23 RES MF 365 OHM 1% 1/4W 144071
J9 CONN MALE 9 POS FRICTION LOCK 117244 R24 RES MF 1K 1% 1/4W 144090
J10 CONN 2 PIN MALE 117213 R25 RES MF 5.62K OHM 1% 1/4W 144447
J11 CONN 2 PIN MALE 117213 R26 RES MF 681 OHM 1% 1/4W 144195
J12 CONN 2 PIN MALE 117213 R27 RES MF 681 OHM 1% 1/4W 144195
Q1 TRANSISTOR PNP 132224 R28 RES MF 681 OHM 1% 1/4W 144195
Q2 TRANSISTOR PNP 132224 R29 RES MF 681 OHM 1% 1/4W 144195
Q3 TRANSISTOR NPN 132223 R30 RES MF 1M 1/4W 144269
Q4 TRANSISTOR PNP 132224 R31 RES MF 1M 1/4W 144269
Q5 TRANSISTOR NPN 132223 R32 RES MF 1M 1/4W 144269
Q6 TRANSISTOR PNP 132224 R33 RES MF 1M 1/4W 144269
Q7 TRANSISTOR PNP 132224 R34 RES MF 187K 1% 1/4W 144406
Q8 TRANSISTOR PNP 132224 R35 RES MF 187K 1% 1/4W 144406
Q9 TRANSISTOR PNP 132224 R36 RES MF 187K 1% 1/4W 144406
Q10 TRANSISTOR PNP 132224 R37 RES MF 187K 1% 1/4W 144406
Q11 TRANSISTOR PNP 132224 R38 RES MF 681 OHM 1% 1/4W 144195
Q12 TRANSISTOR PNP 132224 R39 RES MF 681 OHM 1% 1/4W 144195
Q13 TRANSISTOR PNP 132224 R40 RES MF 681 OHM 1% 1/4W 144195
Q14 TRANSISTOR PNP 132224 R41 RES MF 1M 1/4W 144269
Q15 TRANSISTOR PNP 132224 R42 RES MF 10K 1% 1/4W 144053
Q16 TRANSISTOR PNP 132224 R43 RES MF 121K 1% 1/4W 144418
Q17 TRANSISTOR PNP 132224 R44 RES MF 187K 1% 1/4W 144406
Q18 TRANSISTOR PNP 132224 R45 RES MF 187K 1% 1/4W 144406
Q19 TRANSISTOR PNP 132224 R46 RES MF 187K 1% 1/4W 144406
Q20 TRANSISTOR NPN 132223 R47 RES MF 68.1K 1% 1/4W 144081
Q21 TRANSISTOR NPN 132223 R48 RES MF 10M 1% 1/4W 144264
Q22 TRANSISTOR NPN 132223 R49 RES MF 27.4K 1% 1/4W 144141
Q23 TRANSISTOR NPN 132223 R50 RES MF 2.67K 1% 1/4W 144121
Q24 TRANSISTOR NPN 132223 R51 RES MF 10.2K 1% 1/4W 144130
Q25 TRANSISTOR NPN 132223 R52 RES MF 5.62K OHM 1% 1/4W 144447
Q26 TRANSISTOR NPN 132223 R53 RES MF 221 OHM 1% 1/4W 144172
Q27 TRANSISTOR NPN 132223 R54 RES MF 4.75M 1/4W 1% 144379
Q28 TRANSISTOR NPN 132223 R55 RES MF 121K 1% 1/4W 144418
Q29 TRANSISTOR NPN 132223 R56 POT TRIM 100K OHM 20% 134383
Q30 TRANSISTOR NPN 132223 R57 RES MF 1.21K 1% 1/4W 144191
Q31 TRANSISTOR NPN 132223 R58 RES MF 68.1K 1% 1/4W 144081
Q32 TRANSISTOR NPN 132223 R59 RES MF 10M 1% 1/4W 144264
Q33 TRANSISTOR NPN 132223 R60 RES MF 27.4K 1% 1/4W 144141
Q34 TRANSISTOR NPN 132223 R61 RES MF 2.67K 1% 1/4W 144121
Q35 TRANSISTOR PNP 132224 R62 RES MF 10.2K 1% 1/4W 144130
Q36 TRANSISTOR PNP 132224 R63 RES MF 5.62K OHM 1% 1/4W 144447
R1 RES MF 5.62K OHM 1% 1/4W 144447 R64 RES MF 221 OHM 1% 1/4W 144172
R2 RES MF 15K 1% 1/4W 144412 R65 RES MF 4.75M 1/4W 1% 144379
R3 RES MF 100K 1% 1/4W 144113 R66 RES MF 121K 1% 1/4W 144418
R4 RES MF 22.1K 1% 1/4W 144187 R67 POT TRIM 100K OHM 20% 134383
R5 RES MF 10K 1% 1/4W 144053 R68 RES MF 1.21K 1% 1/4W 144191
R6 RES MF 100K 1% 1/4W 144113 R69 RES MF 68.1K 1% 1/4W 144081
R7 RES MF 5.62K OHM 1% 1/4W 144447 R70 RES MF 10M 1% 1/4W 144264
R8 POT TRIM 500 OHM 20% HORIZ ADJ 134410 R71 RES MF 27.4K 1% 1/4W 144141
41
PARTS LIST con't
R72 RES MF 2.67K 1% 1/4W 144121 D5 DIODE RECTIFIER 070131
R73 RES MF 10.2K 1% 1/4W 144130 D6 DIODE ZENER 6.2V 5% 500MW 070085
R74 RES MF 5.62K OHM 1% 1/4W 144447 D7 DIODE SILICON 070047
R75 RES MF 221 OHM 1% 1/4W 144172 F1 FUSE 3.15A SLO-BLO 5X20 IEC 089098
R76 RES MF 20 OHM 1/4W 144174 IC1 IC REGULATOR +5 VOLT 133093
R77 RES MF 4.75M 1/4W 1% 144379 J1 BLADE FASTON W/FEET 117708
R78 RES MF 121K 1% 1/4W 144418 J2 BLADE FASTON W/FEET 117708
R79 POT TRIM 100K OHM 20% 134383 J3 CONN MALE 9 POS FRICTION LOCK 117244
R80 RES MF 1.21K 1% 1/4W 144191 J4 BLADE FASTON W/FEET 117708
R81 RES MF 121K 1% 1/4W 144418 J5 CONN MALE 7 PIN 117217
R82 RES MF 10K 1% 1/4W 144053 J6 CONN 4 PIN 117215
R83 RES MF 121K 1% 1/4W 144418 J7 BLADE FASTON W/FEET 117708
R84 RES MF 47.5K 1% 1/4W 144108 J8 BLADE FASTON W/FEET 117708
R85 RES MF 10K 1% 1/4W 144053 J11 BLADE FASTON W/FEET 117708
R86 RES MF 47.5K 1% 1/4W 144108 J12 BLADE FASTON W/FEET 117708
R87 RES MF 47.5K 1% 1/4W 144108 K1 RELAY 48VDC 087049
R88 RES MF 187K 1% 1/4W 144406 Q1 TRANSISTOR NPN 132223
R89 RES MF 187K 1% 1/4W 144406 Q2 TRIAC OPTOCOUPLER 131024
R90 RES MF 15K 1% 1/4W 144412 Q3 OPTOCOUPLER OPTICAL SCR 131025
R91 RES MF 15K 1% 1/4W 144412 Q4 OPTOCOUPLER OPTICAL SCR 131025
R92 RES MF 15K 1% 1/4W 144412 Q5 SCR REV BLOCKING THYRISTOR 131026
R93 RES MF 15K 1% 1/4W 144412 Q6 SCR REV BLOCKING THYRISTOR 131026
R94 RES MF 15K 1% 1/4W 144412 Q7 SCR REV BLOCKING THYRISTOR 131026
R95 RES MF 15K 1% 1/4W 144412 Q8 SCR REV BLOCKING THYRISTOR 131026
U1 IC HEX SCHMITT INVERTER 133526 Q9 OPTOCOUPLER OPTICAL SCR 131025
U2 IC AND 3 INPUT X 3 133185 Q10 OPTOCOUPLER OPTICAL SCR 131025
U3 IC DUAL OPERATIONAL AMPLIFIER 133260 Q11 TRANSISTOR NPN 132223
U4 IC QUAD ANALOG SW 133117 R1 RES WW 1K 5W 10% 139121
U5 IC DUAL OPERATIONAL AMPLIFIER 133260 R2 RES MF 332K 1% 1/4W 144119
U6 IC DUAL OPERATIONAL AMPLIFIER 133260 R3 RES MF 33.2K 1% 1/4W 144015
R4 RES MF 33.2K 1% 1/4W 144015
R5 RES MF 22.1K 1% 1/4W 144187
6 050063 CAPACITOR PCB R6 RES MF 1.1K 1% 1/4W 144091
C1 CAP ELECT 67000UF 100V 066543 R7 RES MET OX 47 OHM 5% .5W 137096
C2 CAP ELECT 67000UF 100V 066543 R8 RES MET OX 47 OHM 5% .5W 137096
J1 BLADE FASTON W/FEET 117708 R9 RES MET OX 47 OHM 5% .5W 137096
J2 BLADE FASTON W/FEET 117708 R10 RES MET OX 47 OHM 5% .5W 137096
J3 BLADE FASTON W/FEET 117708 R11 RES MF 475 OHM 1% 1/4W 144086
J4 BLADE FASTON W/FEET 117708 R12 RES MF 20K 1% 1/4W 144104
J5 CONN HEADER 2 PIN 0.156 117404 U1 IC REGULATOR +12 VOLT 133119
J6 CONN HEADER 2 PIN 0.156 117404 U2 IC REGULATOR -12V 1A 133138
J7 CONN HEADER 2 PIN 0.156 117404
J8 CONN HEADER 2 PIN 0.156 117404
J9 CONN HEADER 2 PIN 0.156 117404
J10 BLADE FASTON W/FEET 117708
J11 BLADE FASTON W/FEET 117708
7 050062 POWER SUPPLY PCB
C1 CAP ELECT 3300UF 35V 066509
C2 CAP ELECT 100UF 25V 066447
C3 CAP MONO .1uF 50V 20% Z5U 061305
C4 CAP MONO .1uF 50V 20% Z5U 061305
C5 CAP ELECT 3300UF 35V 066509
C6 CAP MONO .1uF 50V 20% Z5U 061305
C7 CAP ELECT 100UF 25V 066447
C8 CAP ELECT 10UF 50V 066445
C9 CAP ELECT 10UF 50V 066445
C10 CAP ELECT 22UF 100V 066506
D1 DIODE RECTIFIER 070131
D2 DIODE RECTIFIER 070131
D3 DIODE ZENER 6.2V 5% 500MW 070085
D4 DIODE RECTIFIER 070131
42
MC207
MC207 EXPLODED VIEW
43 44
MC207 EXPLODED VIEW and PARTS LIST
Ref Part
No. No. Description
1 016507 GLASS 51 114118 TRANSISTOR CLIP 218
2 094360 TAPE FOAM 1/2 X 1/2 52 114119 TRANSISTOR CLIP 214
3 004939 BRACKET EXTRUSION 53 005007 ASSY HEATSINK PCB 1 CH
4 018615 END CAP 9" 54 005439 COVER HEATSINK CH 5-6
5 101042 SCREW TS 4-40 X 1/2 SLOT FILL 55 005406 HEATSINK COVER CENTER
6 094016 TAPE FOAM 1/4 X 1/8 56 005405 COVER HEATSINK CH 1-3
7 098113 CORD DIAL .027 BLACK BRAID SILK 57 084124 POST BINDING DUAL
8 018706 EXTRUSION BOTTOM 58 005419 OUTPUT PLATE TRIPLE
9 100149 SCREW MACH 6-32 X 1/4 FL U/H ST 59 005418 OUTPUT PLATE SINGLE
10 101232 SCREW 6-32 X 1/4 PH FLAT 60 104130 WASHER LOCK #10 SPLIT PHOS/BRNZ
11 018619 EXTRUSION TOP 61 104148 WASHER FLAT BRASS
12 104164 WASHER BLK FELT 1 X 1/4 X 1/16 62 110009 NUT M5 X 0.8 BRASS W/GOLD PLATE
13 049321 ASSY KNOB 63 074091 TERMINAL BLOCK AC
14 092413 ACETATE FILTER BLUE DISPLAY 64 005435 TERMINAL BRACKET
15 005407 SUBPANEL 65 104001 WASHER FLAT STEEL 4 X 9/32 X .025
16 017901 LOGO PUSHBUTTON BACKLIGHT 66 104142 WASHER LOCK 2.5mm INT STAR ZINC
17 017921 LOGO/SELECTOR BACKLIGHT 67 102022 NUT MACH 4-40 X 3/16 X 1/16
18 094429 FOAM TAPE WHITE 1/32" THK 68 114072 RIVET PLASTIC
19 146243 SWITCH POWER 69 005434 TRANSFORMER BRACKET
20 021159 BUSHING SWITCH 70 102003 NUT MACH 6-32 W/LOCK
21 104014 WASHER INT STAR 3/8 X .507 X .002 71 094255 CABLE TIE PANDUIT PLT1M-M
22 124089 METER MC207 72 017452 KLIP WIRE
23 017922 METER BACKLIGHT 73 021094 SPACER 4 X 1/4
24 005411 METER PLATE 74 104014 3/8 INT STAR WASHER
25 102001 NUT KEP 4-40 CADMIUM PLATE 75 084209 THERMSTRATE MC207
26 050066 ASSY METER/DISPLAY PCB 76 102020 NUT MACH 6-32 SELF LOCK
27 112038 SPACER STEEL 4 X 3/8L NCKL PLT 77 050062 ASSY POWER SUPPLY PCB
28 112060 SPACER 4 X 5/16 STEEL 78 018751 SUB HEATSINK
29 005404 DUST COVER 79 114141 CLIP RIGHT ANGLE
30 100287 SCREW MACH 8-32 X 3/8 PH TRUSS HD 80 100250 SCREW MACH SEMS 6-32 X 1/4 PH PN
31 126999 DECAL DUST COVER 81 084208 ISOSTRATE POWER SUPPLY
32 005408 CHASSIS 82 005410 CHASSIS SUPPORT REAR
33 101054 SCREW TAPTITE 6-32 X 1/4 PH PN BLK 83 070139 DIODE BRIDGE RECTIFIER
34 078024 GROMMET RUBBER 1" ID 84 084207 THERMAL PAD 1.25 X 1.25 ALUMINUM
35 078040 GROMMET 3/4" X 1" 85 102006 NUT MACH 10-32 W/LOCK
36 017956 TRANSFORMER SHIELD 86 005401 HEATSINK VENT
37 050061 POTTED TRANSFORMER POWER 87 101176 SCREW TC 6-32 X 1/2 PH PN TYPE F
38 166001 DECAL POWER TRANSFORMER 88 005065 ASSY INPUT PCB
39 050090 CAN POTTED CAPACITOR 89 088023 CIRCUIT BREAKER 10A 240VAC
40 166002 DECAL CAPACITOR COVER 90 117487 RECEPTACLE AC LINE
41 094450 SOUND DAMPING PAD MC207 91 100250 SCREW MACH SEMS 6-32 X 1/4 PH PN
42 050063 ASSY CAPACITOR PCB 92 101197 SCREW HI-LO 4-24 X 3/8 PH RD BLK
43 005413 CAPACITOR CLAMP 93 112015 STANDOFF
44 102045 NUT KEP 6-32 X 1/2 PH PN 94 104004 WASHER LOCK 5 X .255 INT STAR
45 100118 SCREW MACH 6-32 X 1/2 PH PN 95 005400 BOTTOM COVER
46 018750 HEATSINK 96 017937 FOOT
47 084183 ISOSTRATE 97 100159 SCREW MACH 10-32 X 3/4 PH PN
48 050064 ASSY HEATSINK PCB 2 CH 98 101078 ST 8-32 X 5/16 PH PN
49 101059 SCREW SM 6 X 5/8 PH PN TYPE A 99 100173 MS 8-32 X 1/4 PH PN
50 112087 SPACER PCB 1/4"
45 46
MC207
REPACKING INSTRUCTION
47
POWER AMPLIFIER
SERVICE MANUAL
SERIAL NO. VQ1001 And Above
The continuous improvement of its products is the policy of McIntosh Laboratory Incorporated, who reserve the right to improve design without
notice. Because of the constant upgrading of McIntosh products' circuitry and components, the Company cannot insure, and does not warrant, the
accuracy of the within schematic material, which is intended for information only.
McINTOSH LABORATORY, INC., 2 CHAMBERS STREET, BINGHAMTON, NEW YORK 13903 Printed in U.S.A. Part Number 040929
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
