Image preview - the first page of the document



>> Download M-B55 documenatation <<

Text preview - extract from the document

    1                                     2                                                        3                                                        4




D                                                                                                                                                                            D



                                                                                        USB5V
                                                                                                   R4
                                                                                                   1K

                                                                               C9                      C04                   LED
                                                                               220UF                   103


        R IN    R1
                8.2K
                                                                                             16
                                   VR1A       C3
                                   50K        1UF                                                            14
               C01     R2
               221     33K                                                10
C                            C1                                                                                                                                              C
                             681                                   C4                                                       C8
                                                                                                                                               SP1
                                                       C02         47UF                                                     100UF
                                                                          11                                                                   4 ohm
                                              C2                                                             15
                                              471
                                                                                        U1                                    C6
                                                             R3                                                     C7       220UF
                                                             680                       TEA2025B                    224
                                                                          8                                                              C03
                                                                                       KA2206                                            103
                                                                    C5
                                                                    100UF
        L IN    R1'
                8.2K                                                                                         3

                                   VR1B                                                                             C6'       C8'              SP2
                                              C3'
                                   50K                                                                            100UF       220UF            4 ohm
                       R2'                    1UF
               C01'                                                                                          2
                       33K   C1'                                          7
B              221                                                                                                                                                           B
                             681                                   C4'
                                                                   47UF                                                                 C03'
                                                    C02'                                                           C7'                  103
                                              C2'                         6
                                                                                                                   224
                                              471

                                                             R3'                   1,4,5,9,12,13
                                                             680




                                                                                                                         * NO USED


                                                                                                                    Title
A                                                                                                                                                                            A
                                                                                                                                M-B55 USB STEREO SPEAKERS
                                                                                                                    Size       Number                             Revision
                                                                                                                     A4
                                                                                                                    Date:     26-Mar-2003                Sheet of
                                                                                                                    File:     F:\huang bf\AN\M-b55.ddb   Drawn By:
                                                                                                                                                              L.M.An
    1                                     2                                                        3                                                        4
