Image preview - the first page of the document



>> Download bcy70 documenatation <<

Text preview - extract from the document

                                                                                                                                             BCY70
                                                                                                                                             BCY71
                                                                                                                                             BCY72



                                                                                         GENERAL PURPOSE
MECHANICAL DATA                                                                        PNP SILICON TRANSISTOR
Dimensions in mm (inches)
                                         5.84 (0.230)
                                         5.31 (0.209)
                                         4.95 (0.195)
                                         4.52 (0.178)




                                                                                     DESCRIPTION
                                                        5.33 (0.210)
                                                        4.32 (0.170)




                                                                                     The BCY70, BCY71 & BCY72 are silicon
                                                                                     planar epitaxial PNP tranistors in Jedec
                                                        12.7 (0.500)




                                                                                     TO18 metal case.
                                                            min.




                        0.48 (0.019)
                        0.41 (0.016)
                            dia.




                          2.54 (0.100)
                             Nom.




                                         3        1
                                              2


             TO18 PACKAGE(TO-206AA)
                            Underside View
  PIN 1
