Image preview - the first page of the document
>> Download Primare_T23-DAB_FM_Tuner_sm documenatation <<
Text preview - extract from the document
PRIMARE
T23 DAB / FM Tuner
Service Manual
Downloaded from www.Manualslib.com manuals search engine
1. Schematics and Pcb.
2. Technical Specifications.
Confidential !
This document is not allowed to show for third part without written permission
from Primare Systems AB.
This document is subject to change without notice.
Author:
Bjorn Holmqvist
Primare Systems AB
[email protected]
Downloaded from www.Manualslib.com manuals search engine
Downloaded from www.Manualslib.com manuals search engine
Downloaded from www.Manualslib.com manuals search engine
Downloaded from www.Manualslib.com manuals search engine
Downloaded from www.Manualslib.com manuals search engine
Downloaded from www.Manualslib.com manuals search engine
Downloaded from www.Manualslib.com manuals search engine
Downloaded from www.Manualslib.com manuals search engine
Downloaded from www.Manualslib.com manuals search engine
Downloaded from www.Manualslib.com manuals search engine
Downloaded from www.Manualslib.com manuals search engine
DVD26FI1.job - Tue Dec 07 16:06:01 2004
Downloaded from www.Manualslib.com manuals search engine
T23 Performance Data
FM
Stereo tuner, 87.5-108Mhz
RDS decoding
Number of Presets: 40
Usable sensitivity: FM Mono 10dBuV
FM Stereo 20dBuV
DAB
Band III (174-240Mhz) and L (1452-1492Mhz).
Usable Sensitivity: 29dBuV band III
30dBuV band L
Number of Presets 10
Outputs / inputs
1 Line inputs (RCA)
1 75R SPDIF (RCA)
1 TOSlink
1 IR input
1 RS232 input
50R Antenna Input (F-connector) combined for DAB / FM.
Downloaded from www.Manualslib.com manuals search engine
