Image preview - the first page of the document
>> Download Vitran II - Manual documenatation <<
Text preview - extract from the document
V.112910 Part # MAN-VITRAN II Vitran II Hv1
$45.00 USD
TM
Vitran II
TM
Vitran II V.112910
This page intentionally left blank
2 M&R Companies 1N 372 Main St. Glen Ellyn, IL 60137 USA
Tel: +630-858-6101 Fax: +630-858-6134 www.mrprint.com | store.mrprint.com
TM
V.112910 Vitran II
Table of Contents
1. Safety and Operational Guidelines ...........................................................................................................................5
1.1 Management Responsibilities ...................................................................................................................................6
1.2 Operator Responsibilities ..........................................................................................................................................7
2. General Information....................................................................................................................................................8
2.1 Service and Parts......................................................................................................................................................9
2.2 Defined Purpose .....................................................................................................................................................10
2.3 Warranty..................................................................................................................................................................10
3. Product Specifications.............................................................................................................................................11
4. Assembly and Installation .......................................................................................................................................15
4.1 Assembly.................................................................................................................................................................15
4.1.1 UV Lamp Installation and Replacement ..........................................................................................................18
4.2 Installation ...............................................................................................................................................................18
5. Operation ...................................................................................................................................................................19
5.1 Dryer Control Panel.................................................................................................................................................19
5.1.1 Operator Interface............................................................................................................................................19
5.2 Conveyor Control Panel ..........................................................................................................................................25
5.3 Principles of UV Curing ...........................................................................................................................................26
5.4 Operation Overview ................................................................................................................................................27
5.4.1 Lamp Focus .....................................................................................................................................................27
5.5 Dryer Startup/Shutdown..........................................................................................................................................27
6. Scheduled Maintenance...........................................................................................................................................30
6.1 Scheduled Maintenance Log...................................................................................................................................34
7. Troubleshooting........................................................................................................................................................35
8. Replacement Parts ...................................................................................................................................................36
M&R Companies 1N 372 Main St. Glen Ellyn, IL 60137 USA 3
Tel: +630-858-6101 Fax: +630-858-6134 www.mrprint.com | store.mrprint.com
TM
Vitran II V.112910
This page intentionally left blank
4 M&R Companies 1N 372 Main St. Glen Ellyn, IL 60137 USA
Tel: +630-858-6101 Fax: +630-858-6134 www.mrprint.com | store.mrprint.com
TM
V.112910 Vitran II
1. Safety and Operational Guidelines
DANGER This symbol identifies situations that endanger people, property, and/or equipment. If such
conditions exist, the equipment must be shut down and all energy sources (electrical, gas, and
pneumatic) must be disconnected, purged, and locked out until the problem is resolved.
Never attempt to bypass or defeat any safety device. Do not attempt to operate the equipment if
any safety device is not functioning properly, or if any doubt exists about proper operation of safety
devices.
The product described in this publication may operate at high speed and contain numerous
moving parts. It may employ natural gas or propane, mechanical or pneumatic forces, and/or
hazardous voltages, and may create other conditions that could, through misuse, abuse,
unauthorized alteration or retrofitting, inattention, or lack of understanding, result in injury, death, or
damage to the product or to other equipment. In addition, improper operation may also depreciate
the value of the machine and other assets of the owner, and impair the working efficiency of the
machine.
Energy Sources M&R equipment may use one of more of the following energy sources:
