Image preview - the first page of the document
>> Download PANTECH G200 1 documenatation <<
Text preview - extract from the document
G200 Exploded View and Its Parts List ANTECH
1 6220 0129 10 WINDOW LCD SUB
2 6210 0047 00 PLATE DECO FRONT
14
3 6220 0128 00 WINDOW LED
1
ASSY 6201 0497 40 ( BLUE )
4 FRONT 6201 0497 50 ( E_SILVER )
15 UPPER
5 3043 0000 55 FPCB
2
6 3330 5000 50 LCD MODULE
16
7 3550 7000 32 SPEAKER
8 3011 6000 06 COIN MOTOR
3 ASSY 6201 0498 00 ( BLUE )
18 9 FRONT 6201 0498 10 ( E_SILVER )
17
LOWER
10 6115 0031 00 HINGE
11 6220 0130 10 WINDOW LCD MAIN
4
12 6105 0036 00 PLATE DECO EAR
13 6105 0035 00 PLATE NAME
19
COVER 6201 0457 00 ( BLUE )
14 EAR
JACK
5 6201 0499 00 ( BLUE )
7 ASSY
15 BACK 6201 0499 10 ( E_SILVER )
UPPER
6
20
16 6215 0084 00 BUTTON SIDE
8
17 6201 0045 00 DECO BACK SIDE L
18 6201 0046 00 DECO BACK SIDE R
21 19 6260 0059 10 KEYPAD
9 20 6120 0258 00 DOME SHEET
22 21 3550 3000 11 MIC
22 1330 1900 01 MAIN B'D
10
6201 0456 00 ( GRAY )
COVER
23 I/O JACK
23
3571 6000 57 ( BLUE )
11
24 24 ANTENNA 3571 6000 77 ( E_SILVER )
25 ASSY 6201 0496 00 ( BLUE )
12 25 BACK 6201 0496 30 ( E_SILVER )
LOWER
13
26
6261 0112 00 ( GRAY )
RUBBER
26 TEST
Customer Service Team
Titan-G200 Electrical Parts List
CODE Reference.No DESCRIPTION
1330190001 TITAN MAIN B'D
2031000004 C210,C149,C181 CAPACITOR TANTALUM//TAJR106M006RNJ / 10uF
2036800005 C711 CAP TANTAL//F950J686MAAAQ2-6.3V / 68uF
2121000002 C741 CAPACITOR CHIP//GRP1555C1H100DZ01E /10pF
2121010002 C163,C726,C806,C810,C164 CAPACITOR CHIP//GRP1555C1H101JD01E / 100pF
2121020004 C169,C708 CAPACITOR CHIP//GRP155R71H102KA01E / 1000pF
2121030003 C195,C706 CAPACITOR CHIP//GRP155R71C103KA01E / 0.01uF
C100,C101,C102,C103,C104,C106,C107,C108,
C109,C110,C111,C112,C113,C114,C115,C116,
C117,C118,C119,C120,C121,C122,C124,C126,
2121040003 CAPACITOR CHIP//GRP155F51C104ZA01E / 0.1uF
C127,C128,C137,C144,C152,C153,C167,C168,
C174,C175,C179,C180,C184,C187,C189,C190,
C191,C192,C194,C205,C206,C213,C501
2121050008 C123,C196,C197,C198 CAPACITOR CHIP//GRP155F50J105ZD02E / 1uF
2121060005 C138,C139,C140,C143 CAPACITOR CHIP//GJ221BF50J106ZD01L / 10uF
2121290004 C510,C511 CAPACITOR CHIP//GRP1555C1H1R2CZ01E / 1.2pF
2121690002 C512,C513 CAPACITOR CHIP//GRP155C1H1R6CZ01E//1.6pF
2121890012 C204,C150,C136 GRM219R61A475KE19D//4.7uF(0.85t)
2122200001 C705,C740,C724 CAPACITOR CHIP//GRP1555C1H220JZ01E / 22pF
2122230005 C176 CAPACITOR CHIP//GRP155R61C223KD01E / 0.022uF
2122240005 C141 CAPACITOR CHIP//GRP155F51A224ZD02E / 220nF
2122250002 C142,C170 CAPACITOR CHIP//GRM21BR60J225KC01L / 2.2uF
2122250012 C801,C910 CAPACITOR CHIP//GRM188R60J225KE01D / 2.2uF (0603)
2122710008 C750 CAPACITOR//GRP1555C1H271JA01E//270pF
C129,C130,C131,C132,C133,C134,C135,C147,
2123300001 M2113743N38//CAPN//s-c0402 GRP1555C1H330JZ01E / 33pF
C148,C151,C182,C211,C212,C601
2123690003 C713 CAPACITOR//GRP1555C1H3R6CZ01E / 3.6pF
C1,C4,C5,C6,C7,C8,C9,C10,C11,C12,C13,C14,
2124700001 CAPACITOR CHIP//GRP1555C1H470JZ01E / 47pF
C15,C161
2124700001 C3,C16,C17,C160,C162 CAPACITOR CHIP//GRP1555C1H470JZ01E / 47pF
2124710001 C911 CAPACITOR CHIP//GRP155R71H471KD01E / 470pF
2124740001 C18,C199 CAPACITOR CHIP//GRP155F51A474ZD02E / 0.47uF
2124790001 C704 CAPACITOR CHIP//GRP1555C1H4R7CZ01E / 4.7pF
2125080001 C701,C702,C725 CAPACITOR CHIP//GRP1555C1HR50CZ01E / 0.5pF
2125600002 C742,C743 CAPACITOR CHIP//GRP1555C1H560JZ01E / 56pF
2126890002 C712 CAPACITOR CHIP//GRP1555C1H6R8CZ01E / 6.8pF
2128200002 C707 CAPACITOR CHIP//GRP1555C1H820JZ01E//82pF
2128290001 C177,C515
M2113743N24//CAPN//s_c0402 GRP1555C1H8R2DZ01E /
8.2pF
1
Customer Service Team
Titan-G200 Electrical Parts List
CODE Reference.No DESCRIPTION
R111,R142,R144,R131,R174,R178,R182,R208,R
2520000001 RESISTOR CHIP//MCR01MZSJ 000 / 0
209,R210,R220,R227
2520000008 R192 RES//MCR03EZHJ000/0
2520272001 R110 RESISTOR CHIP//MCR01MZSJ 272 / 2.7K
2520682001 R226 RESISTOR CHIP//MCR01MZSJ 682 / 6.8K
2521000001 R1,R2,R3,R4,R5,R136,R146,R195,R233 RESISTOR CHIP//MCR01MZSJ 101 / 100
R147,R148,R149,R150,R151,R152,R153,R154,R
2521000001 RESISTOR CHIP//MCR01MZSJ 101 / 100
155,R156
2521001001 R118 RESISTOR CHIP//MCR01MZSJ 102 / 1K
2521002001 R133,R235 RESISTOR CHIP//MCR01MZSJ 103 / 10K
2521002001 R234,R236 RESISTOR CHIP//MCR01MZSJ 103 / 10K
R106,R116,R141,R157,R173,R180,R222,R176,R
2521003001 RESISTOR CHIP//MCR01MZSJ 104 / 100K
177
2521003001 R139,R140,R6 RESISTOR CHIP//MCR01MZSJ 104 / 100K
2521004009 R117 RESISTOR CHIP // MCR01MZSJ105 / 1M ohm
2521005002 R138 RESISTOR CHIP//MCR03EZHJ 106 / 10M
2521009001 R801 RESISTOR CHIP//MCR01MZSJ 100 / 10
2521009012 R160 RESISTOR CHIP//MCR03EZHJ 100 / 10
2521502004 R712 RESISTOR CHIP//MCR01MZSJ 153 / 15K
2522000001 R123,R124,R125,R126,R127,R128 RESISTOR CHIP//MCR01MZSJ 201 / 200
2522201001 R107,R129 RESISTOR CHIP//MCR01MZSJ 222 / 2.2K
2523301003 R104,R105 RESISTOR CHIP//MCR01MZSJ 332 / 3.3K
2523303001 R137 RES//MCR01MZSF3303/330K
2523307001 R115 RESISTOR//SR73H2BTD R330 F//0.33
2523308001 R223,R224 RESISTOR CHIP//MCR01MZSJ 3R3 / 3.3
2523309001 R112,R113,R114,R211 RESISTOR CHIP//MCR01MZSJ 330 / 33
2523602004 R191 RESISTOR CHIP//MCR01MZSJ 363 / 36K
2524121001 R101 RESISTOR//RK73H1ETP4121F/4.12K
2524700001 R102,R225 RESISTOR CHIP//MCR01MZSJ 471 / 470
2524701003 R108,R166,R175 RESISTOR CHIP//MCR01MZSJ 472 / 4.7K
2524702001 R109 RESISTOR CHIP//MCR01MZSJ 473 / 47K
3012000062 U701 POWER AMP//RF3133TR13
3012000073 Z701 RF SWITCHPLEXER//SHS-C090DR
3101000010 D116 DIODE-ZN//CRY82
3104100011 D114,D115 DIODE SHOTTKY//RB520S-30TE61
3104200027 DA101 TVS DIODE//LC0406FC05C-T7-2
3110100013 Q102 TR//2SC5585 2
Customer Service Team
Titan-G200 Electrical Parts List
CODE Reference.No DESCRIPTION
3114000036 Q101 POWER MOSFET(P-CHANNEL)//Si7703EDN
3114000037 Q105 MOTOR SWITCH TR//NUD3105LT1
3200100105 U113 LDO REGULAOTR//LP2985IM5X-2.8
3200100130 U111 COMPARATOR//LMV331M7
3200100169 U114 IC-DUAL OR GATE//NC7WZ32
3200100262 U102 VBC//AD6521
3200100283 U907 LDO REGULATOR//LP3985IM5X-2.8
3200100286 U112 SWITCH//A3212ELH
3200100329 U104 MCP//M6MGD137W33WG
3200100336 U107 CMOS 2-INPUT NAND GATE//MC74VHC1G00DFT2
3200100361 U116 AUDIO AMP//TPA6203A1
3200100387 U105 MELODY IC//OKI ML2870 QFN
3200100397 U101 BASEBAND PROCESSOR//AD6526
3200100399 U103 GSM POWER MANAGEMENT SYSTEM//ADP3522XCP-3
3200100403 U117 ANALOG SWITCH//MAX4684EBC
3200100428 U710 IC RF CHIPSET//SI4205
D102,D103,D104,D105,D106,D107,D108,D109,
3330600037 KEY PAD LED//LEBB-S14E
D110,D111,D112,D113
V104,V105,V106,V107,V108,V109,V111,V112,V1
3411100020 ARRAY VARISTOR//AVLC18S02015P/ 15pF
13,V121,V124
3411100021 V110,V114,V115,V126 ARRAY VARISTOR//AVLC5S02100P/100pF
V117,V119,V123,V125,V127,V128,V129,V130,V1
3411100021 ARRAY VARISTOR//AVLC5S02100P/100pF
31,V132,V133
3500100260 L724 INDUCT-FIX//LL1005-FH27NJ/27nH
3500100287 L722 INDUCTOR CHIP // LL1005-FH2N2S / 2.2nH
3500100464 L513 INDUCTOR//LL1005 FH4N7S / 4.7nH
3500100466 L723 INDUCTOR//LL1005 FH39NJ / 39nH
3500100514 L511 IND//LMC1608T-6N8J// 6.8nH
3500100515 L510 IND//LMC1608T-24NJ// 24nH
3520090002 Z510 GSM RF SAW FILTER//B7820
3520090003 Z512 DCS RF SAW FILTER//B7821
3530200018 X101 CRYSTAL//Q13MC1461000200/32.768kHz, 12.5pF
3530500022 V801 VCTCXO//VC-TCXO-212C4(13MHz)
3540200009 B101,B102,B103,B104 BEAD//BLM18HK601SN1D
3572200006 Z705,Z706 ATTENUATOR//RAC101A6CTH,6dB
3612600186 BT101 BACKUP BATTERY//NBL414R-TT33(2V)
3701200008 SW102,SW103 LUMI SWITCH//LS10N2-T 3
Customer Service Team
Titan-G200 Electrical Parts List
CODE Reference.No DESCRIPTION
3721100055 J103 LCD CONN//24-5602-032-002-829(ELCO_SOCKET)
3721100056 J101 CARKIT//AXR512483202
3721100082 J701 RF SWITCH CONNECTOR//KMS-506
3725000024 J106 EARPHONE JACK//AJ422-4-SMT
3725000029 J108 BATTERY CONTACT//HB4P004C
3725000040 J103-JST SIM CONNECTOR//SCK-6B-12PT
6105002700 FG3 MUSEII//PLATE SOLDER SUPPORT//BsP-1/2H,0.2t
6120019100 J702 FORTE//PLATE CONTACT ANT//Pb-S-1/2H(0.15t),Ni3+Au0.2
6120025900 TITAN//SHIELD MELODY//BsP-1/2H,0.2t(PbSn 2.0)
6120026000 TITAN//SHIELD P-AM//BsP-1/2H,0.2t(PbSn 2.0)
6120026100 TITAN//SHIELD RF//BsP-1/2H 0.2t(PbSn 2.0)
4
Customer Service Team
