Image preview - the first page of the document



>> Download RC-754 documenatation <<

Text preview - extract from the document

RC-754 EXPLODED VIEW




                       1/2
EXPLODED VIEW LIST

NO         PARTS NAME    Q'TY   NO       PARTS NAME       Q'TY   NO           PARTS NAME    Q'TY

1    FRONT PANEL          1     18 FRONT PCB               1     70   TUBE                   1

1B DECORATION             2     19 BACK PANEL              1     71   BRACKET CONNECTOR      1

2    DSP 8 KNOB           1     20 GUIDE PUSH(L)           1     72   ANT Jack               1

3    SCN 7 KNOB           1     21 GUIDE PUSH(R)           1     73   BRKT ANT               1

4    1~6 KNOB             6     22 TRIM OUT                1     74   SPRING LOCK PLATE L    1

5    CLK 0 KNOB           1     23 TRIM BASE CDP           1     75   SPRING LOCK PLATE R    1

6    AS.PS KNOB           1     24 WINDOW                  1     76   SCREW TAPTITE          2

7    OPEN KNOB            1          MOD CRYSLTAL KNOB           77   KOMEC Mecha            1
                                25                         2
     VOL+ CRYSTAL KNOB               MUT9 CRYSLTAL KNOB          78   BRACKET DECK CD        1
8                         2
     UP CRYSTAL KNOB            60 CHASSIS MAIN            1     78A SCREW MACHINE           4

9    1# KNOB ARM          2     61 SCREW HEXAGON           1     79   FIBER                  1

10 2# KNOB ARM            2     62 WASHER SPRING           2     80   COVER BOTTOM (cdp)     1

11   ELP KNOB ARM         2     63 NUT HEX                 2     81   COVER TOP              1

     VOL- CRYSTAL KNOB          64 HEAT SINK (hi power)    1     82   HALF SLEEVE            1
12                        2
     DN CRYSTAL KNOB            65 SCREW MACHINE           2     83   SCREW CARD NAME        1

13 SEL shift KNOB         1     66 MAIN PCB                1     84   FOR SCREW CARD         2

14 CIRCLE KNOB INSTER     2     67 SCREW TAPTITE           12

15 BND LOU ent KNOB       1     67A SCREW TAPTITE          4

16 CUSHION BUTTON         1     68 HOLDER IC               1

17 MAIN REFLECTOR         1     69 SCREW MACHINE           2

17A PWR KNOB              1     70A CONNETOR               1



                                                                                             2/2
