RC-752 EXPLODED VIEW
EXPLODED VIEW A
1/2
EXPLODED VIEW LIST
NO PART NO PARTS NAME Q'TY NO PART NO PARTS NAME Q'TY
1 5A7700-P01-0 FRONT CHASSIS 1 41 3L0014-000-P 7 PINSX2 WAFER 1
2 5A7700-P02-L BRACKET LOCK -L 1 42 6B2922-010-0 CON-Back Plate 1
3 4D7700-31-00 PUSH LOCK 1 43 4A7700-04002 BACK PANEL 1
4 4D7700-30-00 PUSH LEVER 1 44 4D7700-27-L0 GUIDE PUSH(L) 1
5 5A7700-P07-0 COPPER POLE 2 45 8T0000-D03-L SPRING GUIDE PUSH L 1
6 8T7700-SHO-0 FRONT CHASSIS SPRING 1 46 4D7700-28-R0 GUIDE PUSH(R) 1
7 8T7700-LOG-0 FRONT CHASSIS SPRING 1 47 8T0000-D03-R SPRING GUIDE PUSH R 1
8 4A7700-01024 TRIM BASE 1 49 8LTT2-PH0210 SCREW TAPTITE 4
9 4A7700-32003 BUTTON-EJECT(CDP) 1 50 4B7700-05M25 WINDOW 1
10 6D0000-P01-1 DISC SLOT 1 51 4A7700-02024 TRIM OUT 1
11 4A7700-29-00 SENSOR KNOB 1 60 5A7000-P11-1 CHASSIS MAIN 1
12 8T7700-P05-0 SPRING SHEET 1 61 8LSHM-515000 SCREW HEXAGON 1
13 6G48TQ-000-0 Damper Gear 1 62 8LWS0-D52D10 WASHER SPRING 2
14 5A7700-P03-1 BRACKET LOCK-R 1 63 8LNHM-500000 NUT HEX 2
15 8LBHM-000203 SCREW MACHINE 1 64 5B7000-P15-2 HEAT SINK (hi power) 1
16B 1P7800DET-01 Detachable PCB(Single) 1 65 8LBHM-000305 SCREW MACHINE 2
16 8LBHM-000205 SCREW MACHINE 4 66 1P7383-000-4 MAIN PCB 1
17 8LBHM-000268 SCREW MACHINE 3 67 8LBHT-000305 SCREW TAPTITE 12
48 4A7700-03024 FRONT PANEL 1 67A 8LBHT-000304 SCREW TAPTITE 4
18 4A7700-20TRA DECORATION 1 68 5A7000-P18-2 HOLDER IC 1
19 4AB7700-23RM24 DISP KNOB 1 69 8LBHM-000314 SCREW MACHINE 2
20 4AB7700-24124 1 KNOB 1 70A 3I4CH-1210-1 CONNETOR 1
21 4AB7700-24224 2 KNOB 1 70 6E0000-127-0 TUBE 1
22 4AB7700-24324 3 KNOB 1 71 5A7000-P12-0 BRACKET CONNECTOR 1
23 4AB7700-24424 4 KNOB 1 72 3A0150-000-0 ANT Jack 1
24 4AB7700-24524 5 KNOB 1 73 5A7000-P13-0 BRKT ANT 1
25 4AB7700-24624 6 KNOB 1 74 8T7000-P14-2 SPRING LOCK PLATE L 1
26 4AB7700-24RM24 SCN 7 KNOB 1 75 8T7000-P14-0 SPRING LOCK PLATE R 1
27 4AB7700-25RM24 DSP8 KNOB 1 76 8LBHK-000305A SCREW TAPTITE 2
28 4AB7700-21003 VOL KNOB 1 77 2C225A-21P-0 KOMEC Mecha 1
29 4AB7700-22003 SEEK KNOB 1 78 5A7300-P07-2 BRACKET DECK CD 1
30 4B7700-08-00 CRYSTAL KNOB 4 78A 8LBHM-000265 SCREW MACHINE 4
34 4A7700-10018 L CRYSTAL KNOB ARM 2 79 6F7700-P21-0 FIBER 1
35 4B7700-09023 BND LOD KNOB 1 80 5A7000-P20-3 COVER BOTTOM (cdp) 1
35 4B7700-09123 MOD KNOB 1 81 5A7000-P19-4 COVER TOP 1
36 4A7700-26024 OPEN KNOB 1 82 5A7000-P22-0 HALF SLEEVE 1
37 8T1137-320-0 SPRING OPEN 1 83 7H7700-ENG-0 SCREW CARD NAME 1
38 6A7700-T0001 CUSHION BUTTON 1 84 8L0HM-000314 FOR SCREW CARD 2
39 4B7700-06-00 MAIN REFLECTOR 1
40 1PCF7700-002 FRONT PCB 1
