Image preview - the first page of the document



>> Download 8-05v documenatation <<

Text preview - extract from the document

NO    CODE NO          DESCRIPTION               SPECIFICATION                 ITEM                     LOCATION
100 DPEC-10010A C-ELECT               100uF,20%,16V,GP,TP,6.3x11,5mm            18    AC3,AC8,AC12,AC21,AC28,AC33,AC36,AC39,
                                                                                      AC41,C65,DC3,DC7,DC23,DC24,JC4,RC5,
                                                                                      SC15,SC2
101 DPEC-10013A C-ELECT               1uF,20%,50V,GP,TP,5x11,5mm                4     JC7,JC8,JC9,RC9
102 DPEC-10016A C-ELECT               47uF,20%,16V,GP,TP,5x11,5mm               13    C13,C15,C17,C38,DC1,DC20,RC13,RC14,
                                                                                      RC30,RC32,SC36,SC43,SC44
103 DPEC-10027A C-ELECT               22uF,20%,16V,GP,TP,5x11,5mm               1     JC3
104 DPEC-10024A C-ELECT               220uF,20%,6.3V,GP,TP,6.3x11,5mm           8     DC5,DC9,VC5,VC12,VC17,VC18,VC23,VC26
105 DPEC-10048A C-ELECT               470uF,20%,16V,GP,TP,8x11.5,5mm            1     AC37
106 DPRA-10001A JUMPER WIRE           WIRE-NO SHEATH CU; SPCW,300V,1/0.5        4     VC3,VC15,VC16,VC22
107 DPEX-10019A X'TAL                 27MHz,10ppm,28-AAM,12pF,40/U              1     CY2
108 DPEX-10128A X-TAL                 16.9344MHz,ATS-HC,49S                     1     CY1
109 DPJA-10002A OPTICAL-JACK          TOTX178/VST5A                             1     JCON2
110 DPJA-10029A COXIAL/SUPER JACK     DASW-02C                                  1     JCON6
111 DPJA-10027A RCAJACK 4P            AV4-8.4-21/PB(G/Y|R/B)                    1     JCON3
112 DPJA-10028A RCAJACK 6P            AV6-8.4-21/PB(B/B|W/R|W/R)                1     JCON5
113 DPWA-10011A CONNECTOR-WAFER       STRAIGHT,SMW200-02,2mm                    1     CON1
114 DPWA-10005A CONNECTOR-WAFER       ANGLE,SMAW200-05,2mm                      1     CON5
115 DPWA-10007A CONNECTOR-WAFER       ANGLE,SMAW200-06,2mm                      2     CON4,CON6
116 DPWA-10010A CONNECTOR-WAFER       STRAIGHT,SMW200-13,2mm                    1     CON8
117 DPWA-10042A CONNECTOR-WAFER       SCB-0742-24-7,0.5mm,VERTICAL/04-6244-0    1     CON2
118 DPWA-10040A CONNECTOR-WAFER       STRAIGHT,7P,2.5mm                         1     CON3
119 DPPB-10057A PCB                   MAIN-PCB,EPOXY,1.6T,127x175(DMP-300)      1

     DPEX-10131A MICRO-SW             TC48-231-15                               1

     DPWI-10075A CONNECTOR-WIRE       ANGLE,5P,2mm,B/L,100mm                    1

     DPPB-10063A PCB                  MOTOR-PCB,PHENOL,1.6T,50x19(DMP-300       1

     DPWI-10076A CONNECTOR-WIRE       6P,2mm,110mm                              1

                               ASS'Y Total                                     579
