Image preview - the first page of the document



>> Download trc447 documenatation <<

Text preview - extract from the document

21-1576_rsj_012604.fm Page 1   Monday, January 26, 2004   11:39 AM




                                                              Deluxe Chrome-Faced
        www.radioshack.comSM                                 40-Channel Mobile CB
OWNER'S MANUAL --
                                                                               with Weather Alert
Please read before using this equipment.                                                        21-1576
CH9/NOR/CH19 (Page 6)                                                        S/RF/SWR/CAL (Page 10)
Signal Meter (Page 10)                                                              CB/WX/PA (Page 6)

Microphone Jack                                                                 NB/OFF/MON (Page 10)

                                                                                   DUAL/OFF (Page 7)
UP/DN (Page 6)

Microphone
                                                                                    MIC GAIN (Page 7/
                                                                                    13)

OFF/VOLUME
                                                                                      Rotate to tune to
                                                                                      a channel
SQUELCH (Page 6)
                                                                                    RF GAIN (Page 6)
SWR CAL (Page
10)




                                                                                     Mounting Bracket
Mounting hardware
                                                                              Microphone Holder and
                                                                              mounting hardware

                                                              DC Cable




Thank you for purchasing the RadioShack 40-Channel Mobile CB with Weather Alert. It
provides for communication on the citizen's radio band, lets you tune to local and national
weather service broadcasts, and lets you connect an optional PA speaker to use the public
address function. You can monitor the sound of CB or weather alert over a PA system while in
PA monitor mode. It has the maximum legal power output for the greatest available range, and
a built-in PLL (phase-locked loop) frequency synthesizer provides consistent, exact tuning.

CB radio provides hours of fun and entertainment! Listen and talk to people from all over the
country while traveling, and make new friends along routes that you regularly travel. It is also a
great way to keep informed of local emergencies, such as traffic accidents, road blocks,
weather alerts and so on.

                           ! IMPORTANT !
