Image preview - the first page of the document
>> Download VT-3633 (CRE3091-OIRT) SERVICE-MANUAL documenatation <<
Text preview - extract from the document
SERVICE MANUAL
PWR
MUTE BAND
SEL ST
P
+ SCN LD DIS
VOL A/PS LOC
- TUNE
M
D
1 2 3 4 5 6
MODEL:VT-3633
2004-4-3 WiWi Industries Limtied
Buyer: VITEK Engineering Department
Model: CRE-3091 Bill of Materials
TITLE: VITEK VT-3633 PLL AM/FM OIRT CAR RADIO AUTO-REVERSE TAPE PLAYER 25Wx4 POWER, 2LINE
Checked By:(Elec): C.K.HAN Checked By:(Mech):__________________Approved By:________________
NO ITEM DESCRIPTION QTY LOCATION
1 001-3091S-300 P.C.B MAIN BOARD 1
2 001-0000S-B90 P.C.B FILTER BOX 1
3 002-01140-A09 I.C LA1140 IF "SIP" 1 IC5
4 002-6043P-A01 I.C TA7343/6043 "SIP" 1 IC3
5 002-04558-G00 I.C TJM4558-C DUAL OP-AMP "SOP8" 1 IC4
6 002-03161-A09 I.C LA3161 1 IC1
7 002-07381-J06 I.C TDA7381 1 IC6
8 002-0700R-H00 I.C DSC-700R 1 IC2
9 002-02313-B00 I.C TDA7313D/PT2313L 1 IC8
10 002-7029P-T00 I.C KIA7029P 1 Q30
11 002-78L05-F00 I.C KIA78L05 1 Q29
Q26.25.13.18.35.3.9.16.6.1.23.
12 003-3199Y-A00 TRANSISTOR C3199 15 12.7.4.19
13 003-01303-D03 TRANSISTOR KTD1303 NPN TO-92 2 Q27.36
14 003-01923-A00 TRANSISTOR C1923 1 Q2
15 003-0966Y-A02 TRANSISTOR A966 2 Q11.24
16 003-1267Y-A00 TRANSISTOR A1267 2 Q8.28
17 003-1271Y-A03 TRANSISTOR A1271 2 Q5.14
18 003-3203Y-D03 TRANSISTOR C3203 2 Q15.17
19 004-04001-000 DIODE IN4001 2 D4. FILTER BOX
D32.33.30.11.1.3.14.29.17.20.24
20 004-04148-000 DIODE IN4148 13 .8.5
21 005-00051-A00 ZENER DIODE 1/2W 5.1V 2 ZD1.31
22 005-00056-A00 ZENER DIODE 1/2W 5.6V 2 ZD4.2
23 005-00100-A00 ZENER DIODE 1/2W 10V 2 ZD3.5
PAGE 1 OF 9
24 006-04500-000 CYSTAL 4.5MHz 1 XT1
25 007-05046-7GY I.F.T 7mm K5046 1 T1
26 008-80357-C00 LCD DISPLAY 80357TT-P A2 1
27 009-1019A-A01 TUNER AM CET-1019A 1
28 009-02027-A02 TUNER FM CET-2027F/SV (OIRT) 1
29 010-A0222-000 CHOCK COIL 22mH 1 L1
30 011-A100F-200 RES 1/2W +-5% 10 OHM 1 R30
D2.R119.88.111.109.1.3.108.12.
31 011-A102A-200 RES 1/16W +-5% 1K OHM 14 85.79.37.38.123
32 011-A100A-200 RES 1/16W +-5% 10 OHM 1 R98
33 011-A101A-200 RES 1/16W +-5% 100 OHM 3 R81.133.53
R61.121.45.154.153.86.101.155.
34 011-A103A-200 RES 1/16W +-5% 10K OHM 18 33.43.39.40.46.32.4.70.171.95
35 011-A104A-200 RES 1/16W +-5% 100K OHM 3 R87.90.21
36 011-A122A-200 RES 1/16W +-5% 1.2K OHM 5 R99.97.42.49.151
011-A121A-200 RES 1/16W +-5% 120 OHM 1 R22
37 011-A151A-200 RES 1/16W +-5% 150 OHM 1 R80
38 011-A152A-200 RES 1/16W +-5% 1.5K OHM 1 R41
39 011-A153A-200 RES 1/16W +-5% 15K OHM 1 R11
41 011-A183A-200 RES 1/16W +-5% 18K OHM 1 R66
42 011-A184A-200 RES 1/16W +-5% 180K OHM 1 R34
43 011-A220A-200 RES 1/16W +-5% 22 OHM 1 R68
R63.179.156.161.48.15.176.9.
114.8.115.10.19.157.82.83.44.5
44 011-A223A-200 RES 1/16W +-5% 22K OHM 21 1. 74.84.52
45 011-A222A-200 RES 1/16W +-5% 2.2K OHM 2 R143.147
46 011-A224A-200 RES 1/16W +-5% 220K OHM 3 R26.102.18
47 011-A330A-200 RES 1/16W +-5% 33 OHM 6 R6.17.164.92.91.76
48 011-A331A-200 RES 1/16W +-5% 330 OHM 3 R7.5.78
49 011-A332A-200 RES 1/16W +-5% 3.3K OHM 4 R28.29.25.50
50 011-A333A-200 RES 1/16W +-5% 33K OHM 4 R20.104.130.126
51 011-A334A-200 RES 1/16W +-5% 330K OHM 3 R57.58.23
PAGE 2 OF 9
52 011-A471A-200 RES 1/16W +-5% 470 OHM 3 R71.27.56
R60.65.120.94.16.
53 011-A472A-200 RES 1/16W +-5% 4.7K OHM 14 100.152.93.2.64.47.73.77.75
R59.116.163.13.118.
54 011-A473A-200 RES 1/16W +-5% 47K OHM 10 131.14.128.117.31
55 011-A562A-200 RES 1/16W +-5% 5.6K OHM 7 R124.35.36.125.122.123.24
56 011-A821A-200 RES 1/16W +-5% 820 OHM 2 R62.67
57 011-A822A-200 RES 1/16W +-5% 8.2K OHM 2 R129.132
58 012-1107B-300 ELEC CAP 100uF 10V 5x7mm 1 C55
59 012-2107C-300 ELEC CAP 100uF 16V 6x7mm 1 C134
60 012-B475F-300 ELEC CAP 4.7uF 50V 4x7mm 3 C133.19.129
61 012-B476C-300 ELEC CAP 47uF 16V 4x7mm 1 C35
62 012-C105F-300 ELEC CAP 1uF 50V 5x11mm 9 C111.110.15.13.8.20.25.42.67
63 012-C106C-300 ELEC CAP 10uF 16V 5x11mm 3 C118.9.81
64 012-C107C-300 ELEC CAP 100uF 16V 5x11mm 6 C99.22.74.DECK:1.138.91
65 012-C224F-300 ELEC CAP 0.22uF 50V 5x11mm 4 C93.95.96.94
66 012-C225F-300 ELEC CAP 2.2uF 50V 5x11mm 4 C127.106.90.126
67 012-E227C-300 ELEC CAP 220uF 16V 6x12mm 1 C114
68 012-C335F-300 ELEC CAP 3.3uF 50V 5x11mm 1 C21
C33.29.28.34.136.137.32.64.65.
69 012-C475F-300 ELEC CAP 4.7uF 50V 5x11mm 10 133
70 012-C476C-300 ELEC CAP 47uF 16V 5x11mm 7 C105.85.98.86.58.70.31
71 012-L228C-300 ELEC CAP 2200uF 16V 10x18mm 1 C62
72 012-P108D-300 ELEC CAP 1000uF 16V 13x20mm 1 FILTER BOX
73 013-A102A-400 MYLAR CAP +-20% 0.001uF 50V 6 C51.104.100.97.101.102
74 013-A103A-400 MYLAR CAP +-20% 0.01uF 50V 1 C77
75 013-A183A-400 MYLAR CAP +-20% 0.018uF 50V 2 C26.27
76 013-A222A-400 MYLAR CAP +-20% 0.0022uF 50V 3 C14.113.112
77 013-A272A-400 MYLAR CAP +-20% 0.0027uF 50V 2 C30.36
78 013-A333A-400 MYLAR CAP +-20% 0.033uF 50V 4 C84.52.116.117
79 013-B102A-400 POLY CAP 1000PF 50V 1 C23
80 014-A101C-500 CRE CAP +-10% 100PF 50V 4 C11.16.128.135
PAGE 3 OF 9
81 014-A102C-500 CRE CAP +-10% 0.001uF 50V 3 C18.88.125
82 014-A103C-500 CRE CAP +-10% 0.01uF 50V 4 C60.40.41.75
C89.109.38.37.66.59.47.115.69.
83 014-A104C-500 CRE CAP +-10% 0.1uF 50V 14 43.44.46.2.35
84 014-A150C-500 CRE CAP +-10% 15PF 50V 1 C10
86 014-A223C-500 CRE CAP +-10% 0.022uF 50V 6 C3.61.4.5.12.7
87 014-A250C-500 CRE CAP +-10% 25PF 50V 1 C79
88 014-A473C-500 CRE CAP +-10% 0.047uF 50V 1 C6
89 015-H0103-E00 SEMT-FIXED 10KB 1 VR3
90 015-H0104-E00 SEMT-FIXED 100KB 1 VR1
91 015-H0203-E00 SEMT-FIXED 20KB 1 VR4
92 015-H0503-E00 SEMT-FIXED 50KB 1 VR2
93 016-C0300-000 TRIMMER CAP 30PF 1 C80
94 017-B0107-400 CER FILTER 10.7MFA 2 CF1.2
95 022-C7000-000 FAUSE 7A 1
96 023-A0050-RD0 LED RED 5mm 1 D10
97 029-B0000-000 ANTER JACK SOUBLE SERCW 1
98 033-S1000-GY0 WIRE 28# 1P Shield 100mm 1
99 033-S1900-GY0 WIRE 28# 1P Shield 190mm 1 OIRT
100 025-TA040-385 4P TACT SW. 3.85mm 160G/F 1
101 034-A1612-006 I.S.O 16P W/WIRE 12P 1
102 035-B0400-BK1 JUMPRE WIRE #20 40mm BLACK 1
103 035-E2000-GN1 JUMPER WIRE #26 200mm GREEN 2 DECK
104 035-E0400-BK1 JUMPER WIRE #26 40mm Black 1 DECK
105 035-E0600-BK1 JUMPER WIRE #26 60mm Black 1
106 035-E0600-RD1 JUMPER WIRE #26 60mm RED 1
107 035-E0600-BE1 JUMPER WIRE #26 60mm BLUE 1
108 036-A0250-030 3P WAFER P=2.5mm 1
109 036-A0250-060 6P WAFER P=2.5mm 1
110 036-J0250-120 DETACHABLE CON 12P SOCKET 1
PAGE 4 OF 9
111 037-C6120-3B0 H'ING 3P P=2.5mm 1xSH 120mm 1
112 037-A5270-6B2 H'ING 6P P=2.5mm DECK CONAR 1 2x270mm 3x140mm
113 037-G0300-203 RCA 2xSH L=300mm GREY W/O H'ING 1
114 042-30010-000 FUSE HOLDER 2
115 201-EI240-000 CHOKE TRANS EI-24 1
116 203-1105S-ARD DECK A/R Detachable CS-36xZT 1
117 221-S0040-040 BARE WIRE D=0.4x40mm 70
118 230-100BK-100 PLASTICTIE L=100mm BLACK 2
119 231-P0060-130 RUBBER TUBE PVC D=13 L=50mm 1.0mm 1
120 315-30990-AWE LCD LAMP COVER 0.11x53.5x22mm 1 DRAW PAPER WHITE
121 316-WE773-115 LCD FILTER WHITE 2 DRAW PAPER
FRONT PCB
122 001-3091D-M80 P.C.B FRONT BOARD 1
123 011-S102A-200 0805 RES +-5% 1K OHM 3 R6.20.16
124 011-S152A-200 0805 RES +-5% 1.5K OHM 2 R7.17
125 011-S181A-200 0805 RES +-5% 180 OHM 2 R1.11
126 011-S221A-200 0805 RES +-5% 220 OHM 2 R12.2
127 011-S222A-200 0805 RES +-5% 2.2KOHM 2 R8.18
128 011-S331A-200 0805 RES +-5% 330 OHM 2 R13.3
129 011-S332A-200 0805 RES +-5% 3.3K OHM 2 R9.19
130 011-S471A-200 0805 RES +-5% 470 OHM 3 R14.4.26
131 011-S472A-200 0805 RES +-5% 4.7K OHM 1 R10
132 011-S681A-200 0805 RES +-5% 680 OHM 7 R5.15.21.22.23.24.25
133 023-A0030-BE3 LED Super Bright 3mm 3.6V 20mA BLUE 2 LAMP BOARD
134 023-D0000-BE0 0603 LED BJS170TS-JPH BLUE 10
135 025-TA020-430 TACT SWITCH 2P 4.3mm 20
136 025-TA02S-430 TACT SWITCH 2P 4.3mm SMD 1
137 035-F0900-BK1 JUMPRE WIRE #28 90mm BLACK 2 LAMP
138 036-H0250-120 DETACHABLE CON 12P PLUG P=2.5mm 1
PAGE 5 OF 9
139 040-BE026-A00 LAMP CAP 2.6mm BLUE 2
140 209-30910-V00 HOOK-SPRING 1 SUS T=0.4
141 209-10040-B00 DOOR SPRING 1 SUS T0.3
SUS T0.3 (FOR EJECT
142 209-30010-D00 KNOB SPRING (L=19)(A/R) 3 LEVER)
143 209-11000-N00 LOCK SPRING 2 SUS T0.4
144 209-39050-E00 DOOR BUTTON SPRING 1
145 209-39870-T00 PULL-SPRING 1 SUS T0.35
146 212-52090-14S SPRING WASHER (5.2) 3 SET:1 ACC:2
147 212-52100-05P PLATE WASHER (5.2) 3 SET:1 ACC:2
148 214-30010-A00 MAIN FIBER 1 FIBER T0.5
149 216-3888A-C00 HEAT SINK 1 AL DIE CASTING
150 217-1001E-E12 MOUNTING STRIP 1 EGI T1.2
151 218-3880E-E10 IC BRACKET 1
152 218-3091L-E10 DECK-BRACKET-L A/R 1 EGI T=1.0mm
153 218-3091R-E10 DECK-BRACKET-R A/R 1 EGI T=1.0mm
154 218-3099T-E10 DECK-BRACKET 1 EGI T1.0
155 222-1001S-E06 SLEEVE CASE 1 EGI T0.6
156 222-3091B-E06 BOTTOM-COVER 1 EGI T=0.6mm
157 222-3091F-E10 FRONT-BRACKET 1 EGI T=1.0mm
158 222-3091T-E10 TOP-COVER 1 EGI T=1.0mm
159 223-3091L-H10 SIDE-CHASSIS L 1
160 223-3888R-E10 SIDE-CHASSIS R 1 EGI T=1.0
161 225-09007-400 CUSHION BOTTOM 9x7x4 4 RUBBER BLACK
162 227-30010-EA5 CASE CUSHION 2 SPONGE T15mm
230-100WE-200 WIRE CLIP 1
163 233-N050W-H00 HEX NUT (M5) 2 SET:1 ACC:1
164 234-HEX50-220 SCREW: MS 5x22 HEX 1 SET:1
165 234-KB017-040 SCREW: TS 1.7x4 KB 5 PCB-REFLECTOR:5
PAGE 6 OF 9
166 234-MS030-040 SCREW: MS 3x4 PM5.5x4x1 4 FRONT-BKT:4
167 234-PA020-10B SCREW: TS 2x10 PA BLACK 4 BACK:4
168 234-PA050-160 SCREW: TS 5x16 PA 1 ACCESSORY:1
169 234-PB020-05B SCREW: TS 2x5 PB BLACK 4 PCB-LCD:4
170 234-PM026-030 SCREW: MS 2.6x3 PM 1 EJECT LEV ER (R):1
171 234-PM030-250 SCREW: MS 3x2.5 PM 2
172 234-PM030-130 SCREW: MS 3x13 PM 2 IC:2
173 234-PT030-030 SCREW: TTP 3x3 TAP TYPE 4
174 234-PT030-050 SCREW: TTP 3x5 TAP TYPE 8
175 234-PTT30-050 SCREW: TTP 3x5 TAP TYPE (B) 9
234-PTT30-080 SCREW: TTP 3x8 TAP TYPE (B) 2
176 235-34100-H10 SET KEY 2 EGI T1.0
177 236-65220-E10 CORD CLAMER (B) 1 EGI T1.0 (LINE OUT)
178 301-0C025-060 POLY BAG 1 (OPEN) 2.5'x6'x0.04T
179 301-0C070-105 POLY BAG 1 (OPEN) 7'x10.5'x0.05T
180 301-0C110-140 POLY BAG 1 (OPEN) 11'x14'x0.04T
181 303-3091A-000 SNOW BOX 2
182 304-3091A-A10 GIEF BOX 1
183 305-3091A-A10 INST'S MANUAL 1
184 306-30910-A06 CARTON BOX 1
185 313-39000-S00 PVC SHEET 1 PVC BLACK T=0.3mm
186 314-3091A-000 AZIMUTH LABEL 1
187 314-3091T-000 TOP LABEL 1
188 314-3091W-000 WARRANTY LABER 1
189 319-00000-010 SILICA-GEL PACK 1gm 1
190 402-1001S-4BK NOSE PIECE CASE 1 PP BLACK
191 402-3091A-3BK BASE-PANLE 1 PC BLACK
192 402-3091B-1BK NOSE-PIECE 1 ABS BLACK
PAGE 7 OF 9
193 402-3091E-1BK NOSE-PIECE-BACK-A/R 1 ABS BLACK
194 405-3001A-3CR TAPE-DOOR 1 PC CLEAR
195 411-3091C-4WE LCD-CAP 1 PP WHITE
196 413-3091A-2CR LCD-WINDOW 1 PMMA CLEAR
197 414-3091L-2CR REFLECTOR-L 1 PMMA CLEAR
198 414-3091M-2CR REFLECTOR-M 1 PMMA CLEAR
199 414-3091R-2CR REFLECTOR-R 1 PMMA CLEAR
200 418-3091A-1BK FF-KNOB 1 ABS BLACK
201 419-3091A-1BK REW-KNOB 1 ABS BLACK
202 420-3001C-100 FF/REW KNOB ( R ) 2 ABS BLACK
203 423-3091A-1NL BAND-KNOB 2 ABS NATURAL
204 423-3091G-1BK SWITCH-COVER 1 ABS BLACK
205 426-3091B-3CR FUNCTION-KNOB-BASE 1 PC CLEAR
206 426-3987A-3BK PUSH-KNOB 1 ABS BLACK
207 427-3091A-1NL POWER-KNOB 1 ABS NATURAL
208 427-3091B-3CR POWER-KNOB-BASE 1 PC CLEAR
209 428-3091A-1NL VOLUME-KNOB 1 ABS NATURAL
210 428-3091B-3CR VOLUME-KNOB-BASE 1 PC CLEAR
211 429-3091A-1NL TUNE-TRACK-KNOB 1 ABS NATURAL
212 429-3091B-3CR TUNE-KNOB-BASE 1 PC CLEAR
213 430-3091B-1BK EJ-KNOB-A/R 1 ABS BLACK
214 430-3091H-1BK EJ-KB-COVER-A/R 1 ABS BLACK
215 430-3096E-1NL EJECT KNOB ( R ) 1 ABS BLACK
216 431-30911-1NL MEMORY-KNOB-1 1 ABS NATURAL
217 431-30912-1NL MEMORY-KNOB-2 1 ABS NATURAL
218 431-30913-1NL MEMORY-KNOB-3 1 ABS NATURAL
219 431-30914-1NL MEMORY-KNOB-4 1 ABS NATURAL
220 431-30915-1NL MEMORY-KNOB-5 1 ABS NATURAL
221 431-30916-1NL MEMORY-KNOB-6 1 ABS NATURAL
PAGE 8 OF 9
222 432-3091A-1NL SEL-KNOB 1 ABS NATURAL
223 432-3091B-3CR SEL-KNOB-BASE 1 PC CLEAR
224 434-3091A-1NL SCAN-KNOB 1 ABS NATURAL
225 434-3091B-3CR AS-LD-SCAN-BASE 1 PC CLEAR
226 435-3091A-1NL LD-KNOB 1 ABS NATURAL
227 438-3091A-1NL CD-KNOB 1 ABS NATURAL
228 439-3091A-1NL RELEASE-KNOB 1 ABS NATURAL
229 440-3987A-3BK HOOK 1 PC BLACK
230 441-3099N-3WE LCD CAP 37-29 1 P.C WHITE
231 442-3091A-1NL AST-KNOB 1 ABS NATURAL
232 446-3091A-1NL PTY-KNOB 1 ABS NATURAL
233 446-3091B-3CR PTY-TA-AF-BASE 1 PC CLEAR
234 446-3091C-1NL TA-KNOB 1 ABS NATURAL
235 446-3091D-1NL AF-KNOB 1 ABS NATURAL
236 463-0000C-4BK TILTER & FUSE BOX 1 PP BLACK
237 472-3850A-1BK CONNECTOR GUIDE 1 ABS (BLACK)
PAGE 9 OF 9
CRE3091 DRDS MP.sch-1 - Wed Sep 01 21:16:29 2004
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
