Image preview - the first page of the document



>> Download probe documenatation <<

Text preview - extract from the document

 Probes
 700998                                               700978                                                700929
150MHz Passive Probe                                 100:1 Probe                                           Isolation Probe
Designed for use with the DL2700, DL4100 and         A miniature probe conveniently designed for           A 10:1 probe designed for use with the 700926
DL1500 series of oscilloscopes and the 701856 mod-   high voltage measurement. Can handle a maxi-          isolated-input unit or the 701855 module for the
ule for the DL708/708E/DL716 digital scopes. 10:1    mum input voltage of 4000 V (DC+AC peak)              DL708/708E/DL716 digital scopes.
and 1:1 selectable.                                  and a bandwidth from DC to 100 MHz.




 700988                                              700937                                                 701930
400MHz Passive Probe                                 Current Probe                                         Current Probe
A probe designed for DL7100/DL7200/DL1740.           Bandwidth DC up to 50MHz. Can be directly             Bandwidth DC up to 10MHz. Can be directly
Allows the division ratio to be switched between     connected to an oscilloscope with 1M input            connected to an oscilloscope with 1M input
10:1 and 1:1.                                        impedance. Power supply 700938 has two ter-           impedance.
                                                     minal uses with current probe.




 700997                                               700924                                               700925
300MHz Passive Probe                                 100MHz Band Differential Probe                        15MHz Band Differential Probe
A 10:1 probe for the DL4200 oscilloscope.            A probe lets you make wide-band differential          A probe designed for digital oscilloscopes to
                                                     input measurements. Just connect the probe            transform its single-ended input to differential
                                                     to the input of a single-end input digital oscillo-   input.
                                                     scope.




 701920                                               700939                                               700945
500MHz Band Differential Probe                       FET Probe                                             Miniature Probe
A probe lets you make wide-band differential         Input impedance 1.8pF, Bandwidth from DC to           A 300MHz probe with a small head. Best suited
input measurements.                                  900MHz.                                               for measurement of printed circuit boards with
Permissible differential voltage :
