Worden_Floppy_Jun78


>> Download Worden_Floppy_Jun78 documenatation <<

Text preview - extract from the document
An expanded outlook of design factors for a dual-density diskette
controller involves system integration of the diskette drive and covers
bit packing densities, data recovery methods, input and output
interfaces, and available methods of accessing data



 John Worden             Magnetic Peripherals, Incorporated, Oklahoma City. Oklahoma




I   mplementation of flexible diskette drives as low cost
 data processing peripheral memory devices is increasing
                                                             attention to the hardware/software interfaces of both
                                                             the diskette drive and the host computer. Specifically,
 rapidly in terminals and standalone systems, where          the controller' interface must consider diskette format,
 storage capacity, performance, and capability to random-    read/write-erase head design, data encoding and re-
 access data make them suitable for on- and offline          covery means, and diskette drive requirements. The
 information and software applications. Previously limited   host computer interface must be concerned with soft-
 by the ability to operate using single-density, single-     ware command-level interface, logical interface be-
 sided media, the storage capacity of flexible diskette      tween the two devices, and the timing relationships
 drives quadrupled during the past year when units           necessary for contiguous-sector data transfers-the
 capable of both double-density and 2-sided media            optimum condition for diskette data transfer.
 read/write operation were introduced. However, since
 existing single-sided, single-density-encoded diskette
 drive controllers were incapable of operating 2-sided,      Soft
