Image preview - the first page of the document
>> Download 14k documenatation <<
Text preview - extract from the document
14K
Table of Contents
14K BOM................................................................................ 1
14K 14" LCD Instruction manual...................................................... 41
14K Sub. Assembly S.O.P.............................................................. 55
14K System Setup Instruction manual................................................ 75
14K Disassembly........................................................................ 89
/
========================= ================================== ======= ===
0 M-R14KT1 R14KT1 MODEL SET 1
0.1 O-R14KT1-BASE R14KT1-BASE PCE 1
..2 85-000682-00 R14KT1-#8162/#8574 BASE SYSTEM-W PCE 1
...3 63-000710-00 ALL MODEL-PRODUCT BAR CODE LABEL PCE 32
...3 66-682090-00 R14KT1-PCB'A W/GENERIC BIOS SET PCE 1
...3 80-8A1700-00B R14KT1-PCB ASS'Y-JP-USB+RJ11-REV PCE 1
...3 80-8A1710-00A R14KT1-PCB ASS'Y-JP-COM-REV:A-W/ PCE 1
...3 86-682000-00 #8162/#8574 SYSTEM CABINET-R14KT PCE 1
....4 29+015370+00 R14KT1-SB-USB FPC-CA370A PCE 1
....4 29+016372+00 R14KT1-COMPORT FFC-M/B-CA372B PCE 1
....4 29-005070-00 P14G-HDD CABLE-CA304A PCE 1
....4 40+003660+00 R14KT1-HEATSINK MODULE W/FAN-D30 PCE 1
....4 40+006200+00 R14KT1-CPU DOOR-#8574-M-D3081B PCE 1
....4 40+006201+01 R14KT1-COMMUNICATION DOOR-#8574- PCE 1
....4 40+006203+00 R14KT1-STAND OFF-NI+SELF-LOCKING PCE 2
....4 40+011160+80 R14KT1-HDD DOOR-#8574-C3516F PCE 1
....4 40+011164+60 R14KT1-CD-ROM BRACKET DOOR-#8574 PCE 1
....4 40+031364+01 P14N-HDD BRACKET-B2256B PCE 1
....4 40-008163-00 E12T-AL FOIL FOR K/B BRACKET EMI PCE 1
....4 41+420526+04 SCREW BPS/W-B3892C-M2.6X4L,D6. PCE 3
....4 41-420520-03 SCREW BPS/W (5.5)-M2X3L-NYLOK- PCE 5
....4 41-720026-03 SCREW ISOT-M2.6X3L D4.5/H0.8mm PCE 3
....4 41-720926-04 SCREW ISOT-2.6X4L-BLACK-NYLOK-B4 PCE 13
....4 41-721026-06 SCREW ISOT-M2.6X6L D4.5/H0.8mm PCE 16
....4 41-721520-03 SCREW ISOT-M2X3L-SELF-LOCKING PCE 2
....4 41-850926-08 SCREW ISOP-M2.6X8L-BLACK-SELF-LO PCE 2
....4 44-000001-00 PROCESS MATERIALS FOR SYSTEM PCE 1
....4 50-023390-00 P14N3-MYLAR FOR TOUCHPAD BRACKET PCE 2
....4 50-023476-00 E12B-MYLAR FOR TOUCH PAD-KS-0025 PCE 1
1
/
========================= ================================== ======= ===
....4 50-961401-T1 P14N-#8162 K/B COVER ASS'Y-E1075 PCE 1
....4 51-035010-10 N100T1-EMI GASKET 773GT-10X4X100 PCE 0.03
....4 51-035010-10 N100T1-EMI GASKET 773GT-10X4X100 PCE 0.02
....4 51-350094-06 CONDUCTIVE SPONGE 10X1X1000mm-KL PCE 0.02
....4 51-350094-15 P88S-CONDUCTIVE SPONGE 10X0.5X10 PCE 0.02
....4 51-350094-16 P93S-CONDUCTIOVE SPONGE 10X2X100 PCE 0.16
....4 51-350094-16 P93S-CONDUCTIOVE SPONGE 10X2X100 PCE 0.15
....4 52-000040-00 A2121-FOOT RUBBER-D4926A PCE 2
....4 52-002264-00 P14N-K/B RUBBER-E4032C PCE 1
....4 52-002276-00 P14N-K/B RUBBER COVER-E4075B PCE 1
....4 77-682007-00 R14KT1-#8574 LOWER COVER KIT PCE 1
.....5 40+002560+03 R14KT1-LOWER COVER-#8574-M-B1392 PCE 1
.....5 40-006040-00 N222S1-BATTERY HOOK-B3377B PCE 1
.....5 40-011951-00 N222S1-BATTERY LATCH SPRING-D479 PCE 1
.....5 41-420520-03 SCREW BPS/W (5.5)-M2X3L-NYLOK- PCE 2
.....5 50+043041+30 R14KT1-BATTERY LATCH-#8574-C3514 PCE 1
.....5 52-000040-00 A2121-FOOT RUBBER-D4926A PCE 2
....4 77-682007-10 R14KT1-#8162 UPPER COVER KIT PCE 1
.....5 22-300037-01 SPK (R)(L) W/MICROPHONE-W/O RUBB PCE 1
.....5 27-300051-10 N222S1-GASKET TAPE-D4877A PCE 3
.....5 27-300051-20 N222S1-GASKET TAPE-D4877A PCE 3
.....5 27-300051-30 P14N-GASKET TAPE-D4877A PCE 1
.....5 29-160250-00 P02G-TPD-PCB/MB FFC-P1.0x12P-CA2 PCE 1
.....5 29-160287-01 A2121-FFC TOUCHPAD TO TOUCHPAD P PCE 1
.....5 40+008281+00 R14KT1-UPPER COVER SPEAKER AL-FO PCE 2
.....5 40+008321+00 R14DT1-AL FOIL FOR POWER BUTTON- PCE 1
.....5 40-002243-00 P14N-SPEAKER COVER-E4017A PCE 2
.....5 40-007050-50 A5000M-K/B SHIELDING ESD CU-FOIL PCE 2
.....5 40-008055-00 P14N-BOSS FOIL-E4185A PCE 1
.....5 40-008192-00 R15B-AL FOIL FOR CPU MODULE-F424 PCE 1
2
/
========================= ================================== ======= ===
.....5 40-031362-00 P14N-TOUCHPAD BRACKET-B2254A PCE 1
.....5 41-720026-03 SCREW ISOT-M2.6X3L D4.5/H0.8mm PCE 8
.....5 41-720926-04 SCREW ISOT-2.6X4L-BLACK-NYLOK-B4 PCE 2
.....5 50+023694+00 R14KT1-UPPER COVER LENS MYLAR-F4 PCE 1
.....5 50-023256-00 P14N-TOUCHPAD SYNAPTICS MYLAR-E4 PCE 1
.....5 50-023263-00 P14N-SWITCH MYLAR-KL1885A PCE 1
.....5 50-040167-00 P78-MICRO PHONE RUBBER-B4549A PCE 1
.....5 50-968201-02 R14KT1-#8162 UPPER COVER ASS'Y-E PCE 1
.....5 51+036331+00 R14KT1-UPPER COVER SPONGE-F44780 PCE 1
.....5 51-350094-01 CONDUCTIVE SPONGE 5X2X1000mm-KL1 PCE 0.03
.....5 51-350094-05 CONDUCTIVE SPONGE 9X3.5X1000mm-K PCE . 25
.....5 73-080052-00 TOUCH PAD-FOR SOTEC-SYNAPTICS-TM PCE 1
.....5 80-561000-00A P14N-PCB ASS'Y-SE-TOUCHPAD-REV:A PCE 1
..2 85-000682-10 R14KT1-#8162/#8574 BASE SYSTEM-W PCE 1
...3 63-000710-00 ALL MODEL-PRODUCT BAR CODE LABEL PCE 32
...3 66-682090-10 R14KT1-PCB'A W/T/H BIOS SET PCE 1
...3 80-8A1700-00B R14KT1-PCB ASS'Y-JP-USB+RJ11-REV PCE 1
...3 80-8A1710-00A R14KT1-PCB ASS'Y-JP-COM-REV:A-W/ PCE 1
...3 86-682000-00 #8162/#8574 SYSTEM CABINET-R14KT PCE 1
....4 29+015370+00 R14KT1-SB-USB FPC-CA370A PCE 1
....4 29+016372+00 R14KT1-COMPORT FFC-M/B-CA372B PCE 1
....4 29-005070-00 P14G-HDD CABLE-CA304A PCE 1
....4 40+003660+00 R14KT1-HEATSINK MODULE W/FAN-D30 PCE 1
....4 40+006200+00 R14KT1-CPU DOOR-#8574-M-D3081B PCE 1
....4 40+006201+01 R14KT1-COMMUNICATION DOOR-#8574- PCE 1
....4 40+006203+00 R14KT1-STAND OFF-NI+SELF-LOCKING PCE 2
....4 40+011160+80 R14KT1-HDD DOOR-#8574-C3516F PCE 1
....4 40+011164+60 R14KT1-CD-ROM BRACKET DOOR-#8574 PCE 1
....4 40+031364+01 P14N-HDD BRACKET-B2256B PCE 1
3
/
========================= ================================== ======= ===
....4 40-008163-00 E12T-AL FOIL FOR K/B BRACKET EMI PCE 1
....4 41+420526+04 SCREW BPS/W-B3892C-M2.6X4L,D6. PCE 3
....4 41-420520-03 SCREW BPS/W (5.5)-M2X3L-NYLOK- PCE 5
....4 41-720026-03 SCREW ISOT-M2.6X3L D4.5/H0.8mm PCE 3
....4 41-720926-04 SCREW ISOT-2.6X4L-BLACK-NYLOK-B4 PCE 13
....4 41-721026-06 SCREW ISOT-M2.6X6L D4.5/H0.8mm PCE 16
....4 41-721520-03 SCREW ISOT-M2X3L-SELF-LOCKING PCE 2
....4 41-850926-08 SCREW ISOP-M2.6X8L-BLACK-SELF-LO PCE 2
....4 44-000001-00 PROCESS MATERIALS FOR SYSTEM PCE 1
....4 50-023390-00 P14N3-MYLAR FOR TOUCHPAD BRACKET PCE 2
....4 50-023476-00 E12B-MYLAR FOR TOUCH PAD-KS-0025 PCE 1
....4 50-961401-T1 P14N-#8162 K/B COVER ASS'Y-E1075 PCE 1
....4 51-035010-10 N100T1-EMI GASKET 773GT-10X4X100 PCE 0.03
....4 51-035010-10 N100T1-EMI GASKET 773GT-10X4X100 PCE 0.02
....4 51-350094-06 CONDUCTIVE SPONGE 10X1X1000mm-KL PCE 0.02
....4 51-350094-15 P88S-CONDUCTIVE SPONGE 10X0.5X10 PCE 0.02
....4 51-350094-16 P93S-CONDUCTIOVE SPONGE 10X2X100 PCE 0.16
....4 51-350094-16 P93S-CONDUCTIOVE SPONGE 10X2X100 PCE 0.15
....4 52-000040-00 A2121-FOOT RUBBER-D4926A PCE 2
....4 52-002264-00 P14N-K/B RUBBER-E4032C PCE 1
....4 52-002276-00 P14N-K/B RUBBER COVER-E4075B PCE 1
....4 77-682007-00 R14KT1-#8574 LOWER COVER KIT PCE 1
.....5 40+002560+03 R14KT1-LOWER COVER-#8574-M-B1392 PCE 1
.....5 40-006040-00 N222S1-BATTERY HOOK-B3377B PCE 1
.....5 40-011951-00 N222S1-BATTERY LATCH SPRING-D479 PCE 1
.....5 41-420520-03 SCREW BPS/W (5.5)-M2X3L-NYLOK- PCE 2
.....5 50+043041+30 R14KT1-BATTERY LATCH-#8574-C3514 PCE 1
.....5 52-000040-00 A2121-FOOT RUBBER-D4926A PCE 2
....4 77-682007-10 R14KT1-#8162 UPPER COVER KIT PCE 1
4
/
========================= ================================== ======= ===
.....5 22-300037-01 SPK (R)(L) W/MICROPHONE-W/O RUBB PCE 1
.....5 27-300051-10 N222S1-GASKET TAPE-D4877A PCE 3
.....5 27-300051-20 N222S1-GASKET TAPE-D4877A PCE 3
.....5 27-300051-30 P14N-GASKET TAPE-D4877A PCE 1
.....5 29-160250-00 P02G-TPD-PCB/MB FFC-P1.0x12P-CA2 PCE 1
.....5 29-160287-01 A2121-FFC TOUCHPAD TO TOUCHPAD P PCE 1
.....5 40+008281+00 R14KT1-UPPER COVER SPEAKER AL-FO PCE 2
.....5 40+008321+00 R14DT1-AL FOIL FOR POWER BUTTON- PCE 1
.....5 40-002243-00 P14N-SPEAKER COVER-E4017A PCE 2
.....5 40-007050-50 A5000M-K/B SHIELDING ESD CU-FOIL PCE 2
.....5 40-008055-00 P14N-BOSS FOIL-E4185A PCE 1
.....5 40-008192-00 R15B-AL FOIL FOR CPU MODULE-F424 PCE 1
.....5 40-031362-00 P14N-TOUCHPAD BRACKET-B2254A PCE 1
.....5 41-720026-03 SCREW ISOT-M2.6X3L D4.5/H0.8mm PCE 8
.....5 41-720926-04 SCREW ISOT-2.6X4L-BLACK-NYLOK-B4 PCE 2
.....5 50+023694+00 R14KT1-UPPER COVER LENS MYLAR-F4 PCE 1
.....5 50-023256-00 P14N-TOUCHPAD SYNAPTICS MYLAR-E4 PCE 1
.....5 50-023263-00 P14N-SWITCH MYLAR-KL1885A PCE 1
.....5 50-040167-00 P78-MICRO PHONE RUBBER-B4549A PCE 1
.....5 50-968201-02 R14KT1-#8162 UPPER COVER ASS'Y-E PCE 1
.....5 51+036331+00 R14KT1-UPPER COVER SPONGE-F44780 PCE 1
.....5 51-350094-01 CONDUCTIVE SPONGE 5X2X1000mm-KL1 PCE 0.03
.....5 51-350094-05 CONDUCTIVE SPONGE 9X3.5X1000mm-K PCE 0.25
.....5 73-080052-00 TOUCH PAD-FOR SOTEC-SYNAPTICS-TM PCE 1
.....5 80-561000-00A P14N-PCB ASS'Y-SE-TOUCHPAD-REV:A PCE 1
..2 85-000682-20 R14KT1-#8162/#8574 BASE SYSTEM-W PCE 1
...3 63-000710-00 ALL MODEL-PRODUCT BAR CODE LABEL PCE 32
...3 66-682090-20 R14KT1-PCB'A W/HASEE BIOS SET PCE 1
...3 80-8A1700-00B R14KT1-PCB ASS'Y-JP-USB+RJ11-REV PCE 1
5
/
========================= ================================== ======= ===
...3 80-8A1710-00A R14KT1-PCB ASS'Y-JP-COM-REV:A-W/ PCE 1
...3 86-682000-00 #8162/#8574 SYSTEM CABINET-R14KT PCE 1
....4 29+015370+00 R14KT1-SB-USB FPC-CA370A PCE 1
....4 29+016372+00 R14KT1-COMPORT FFC-M/B-CA372B PCE 1
....4 29-005070-00 P14G-HDD CABLE-CA304A PCE 1
....4 40+003660+00 R14KT1-HEATSINK MODULE W/FAN-D30 PCE 1
....4 40+006200+00 R14KT1-CPU DOOR-#8574-M-D3081B PCE 1
....4 40+006201+01 R14KT1-COMMUNICATION DOOR-#8574- PCE 1
....4 40+006203+00 R14KT1-STAND OFF-NI+SELF-LOCKING PCE 2
....4 40+011160+80 R14KT1-HDD DOOR-#8574-C3516F PCE 1
....4 40+011164+60 R14KT1-CD-ROM BRACKET DOOR-#8574 PCE 1
....4 40+031364+01 P14N-HDD BRACKET-B2256B PCE 1
....4 40-008163-00 E12T-AL FOIL FOR K/B BRACKET EMI PCE 1
....4 41+420526+04 SCREW BPS/W-B3892C-M2.6X4L,D6. PCE 3
....4 41-420520-03 SCREW BPS/W (5.5)-M2X3L-NYLOK- PCE 5
....4 41-720026-03 SCREW ISOT-M2.6X3L D4.5/H0.8mm PCE 3
....4 41-720926-04 SCREW ISOT-2.6X4L-BLACK-NYLOK-B4 PCE 13
....4 41-721026-06 SCREW ISOT-M2.6X6L D4.5/H0.8mm PCE 16
....4 41-721520-03 SCREW ISOT-M2X3L-SELF-LOCKING PCE 2
....4 41-850926-08 SCREW ISOP-M2.6X8L-BLACK-SELF-LO PCE 2
....4 44-000001-00 PROCESS MATERIALS FOR SYSTEM PCE 1
....4 50-023390-00 P14N3-MYLAR FOR TOUCHPAD BRACKET PCE 2
....4 50-023476-00 E12B-MYLAR FOR TOUCH PAD-KS-0025 PCE 1
....4 50-961401-T1 P14N-#8162 K/B COVER ASS'Y-E1075 PCE 1
....4 51-035010-10 N100T1-EMI GASKET 773GT-10X4X100 PCE 0.03
....4 51-035010-10 N100T1-EMI GASKET 773GT-10X4X100 PCE 0.02
....4 51-350094-06 CONDUCTIVE SPONGE 10X1X1000mm-KL PCE 0.02
....4 51-350094-15 P88S-CONDUCTIVE SPONGE 10X0.5X10 PCE 0.02
....4 51-350094-16 P93S-CONDUCTIOVE SPONGE 10X2X100 PCE 0.16
....4 51-350094-16 P93S-CONDUCTIOVE SPONGE 10X2X100 PCE . 15
6
/
========================= ================================== ======= ===
....4 52-000040-00 A2121-FOOT RUBBER-D4926A PCE 2
....4 52-002264-00 P14N-K/B RUBBER-E4032C PCE 1
....4 52-002276-00 P14N-K/B RUBBER COVER-E4075B PCE 1
....4 77-682007-00 R14KT1-#8574 LOWER COVER KIT PCE 1
.....5 40+002560+03 R14KT1-LOWER COVER-#8574-M-B1392 PCE 1
.....5 40-006040-00 N222S1-BATTERY HOOK-B3377B PCE 1
.....5 40-011951-00 N222S1-BATTERY LATCH SPRING-D479 PCE 1
.....5 41-420520-03 SCREW BPS/W (5.5)-M2X3L-NYLOK- PCE 2
.....5 50+043041+30 R14KT1-BATTERY LATCH-#8574-C3514 PCE 1
.....5 52-000040-00 A2121-FOOT RUBBER-D4926A PCE 2
....4 77-682007-10 R14KT1-#8162 UPPER COVER KIT PCE 1
.....5 22-300037-01 SPK (R)(L) W/MICROPHONE-W/O RUBB PCE 1
.....5 27-300051-10 N222S1-GASKET TAPE-D4877A PCE 3
.....5 27-300051-20 N222S1-GASKET TAPE-D4877A PCE 3
.....5 27-300051-30 P14N-GASKET TAPE-D4877A PCE 1
.....5 29-160250-00 P02G-TPD-PCB/MB FFC-P1.0x12P-CA2 PCE 1
.....5 29-160287-01 A2121-FFC TOUCHPAD TO TOUCHPAD P PCE 1
.....5 40+008281+00 R14KT1-UPPER COVER SPEAKER AL-FO PCE 2
.....5 40+008321+00 R14DT1-AL FOIL FOR POWER BUTTON- PCE 1
.....5 40-002243-00 P14N-SPEAKER COVER-E4017A PCE 2
.....5 40-007050-50 A5000M-K/B SHIELDING ESD CU-FOIL PCE 2
.....5 40-008055-00 P14N-BOSS FOIL-E4185A PCE 1
.....5 40-008192-00 R15B-AL FOIL FOR CPU MODULE-F424 PCE 1
.....5 40-031362-00 P14N-TOUCHPAD BRACKET-B2254A PCE 1
.....5 41-720026-03 SCREW ISOT-M2.6X3L D4.5/H0.8mm PCE 8
.....5 41-720926-04 SCREW ISOT-2.6X4L-BLACK-NYLOK-B4 PCE 2
.....5 50+023694+00 R14KT1-UPPER COVER LENS MYLAR-F4 PCE 1
.....5 50-023256-00 P14N-TOUCHPAD SYNAPTICS MYLAR-E4 PCE 1
.....5 50-023263-00 P14N-SWITCH MYLAR-KL1885A PCE 1
.....5 50-040167-00 P78-MICRO PHONE RUBBER-B4549A PCE 1
7
/
========================= ================================== ======= ===
.....5 50-968201-02 R14KT1-#8162 UPPER COVER ASS'Y-E PCE 1
.....5 51+036331+00 R14KT1-UPPER COVER SPONGE-F44780 PCE 1
.....5 51-350094-01 CONDUCTIVE SPONGE 5X2X1000mm-KL1 PCE 0.03
.....5 51-350094-05 CONDUCTIVE SPONGE 9X3.5X1000mm-K PCE . 25
.....5 73-080052-00 TOUCH PAD-FOR SOTEC-SYNAPTICS-TM PCE 1
.....5 80-561000-00A P14N-PCB ASS'Y-SE-TOUCHPAD-REV:A PCE 1
..2 85-000682-30 R14KT1-#8162/#8574 BASE SYSTEM-W PCE 1
...3 63-000710-00 ALL MODEL-PRODUCT BAR CODE LABEL PCE 32
...3 66-682090-30 R14KT1-PCB'A W/GENERIC BIOS & WL PCE 1
...3 80-8A1700-00B R14KT1-PCB ASS'Y-JP-USB+RJ11-REV PCE 1
...3 80-8A1710-00A R14KT1-PCB ASS'Y-JP-COM-REV:A-W/ PCE 1
...3 86-682000-00 #8162/#8574 SYSTEM CABINET-R14KT PCE 1
....4 29+015370+00 R14KT1-SB-USB FPC-CA370A PCE 1
....4 29+016372+00 R14KT1-COMPORT FFC-M/B-CA372B PCE 1
....4 29-005070-00 P14G-HDD CABLE-CA304A PCE 1
....4 40+003660+00 R14KT1-HEATSINK MODULE W/FAN-D30 PCE 1
....4 40+006200+00 R14KT1-CPU DOOR-#8574-M-D3081B PCE 1
....4 40+006201+01 R14KT1-COMMUNICATION DOOR-#8574- PCE 1
....4 40+006203+00 R14KT1-STAND OFF-NI+SELF-LOCKING PCE 2
....4 40+011160+80 R14KT1-HDD DOOR-#8574-C3516F PCE 1
....4 40+011164+60 R14KT1-CD-ROM BRACKET DOOR-#8574 PCE 1
....4 40+031364+01 P14N-HDD BRACKET-B2256B PCE 1
....4 40-008163-00 E12T-AL FOIL FOR K/B BRACKET EMI PCE 1
....4 41+420526+04 SCREW BPS/W-B3892C-M2.6X4L,D6. PCE 3
....4 41-420520-03 SCREW BPS/W (5.5)-M2X3L-NYLOK- PCE 5
....4 41-720026-03 SCREW ISOT-M2.6X3L D4.5/H0.8mm PCE 3
....4 41-720926-04 SCREW ISOT-2.6X4L-BLACK-NYLOK-B4 PCE 13
....4 41-721026-06 SCREW ISOT-M2.6X6L D4.5/H0.8mm PCE 16
....4 41-721520-03 SCREW ISOT-M2X3L-SELF-LOCKING PCE 2
8
/
========================= ================================== ======= ===
....4 41-850926-08 SCREW ISOP-M2.6X8L-BLACK-SELF-LO PCE 2
....4 44-000001-00 PROCESS MATERIALS FOR SYSTEM PCE 1
....4 50-023390-00 P14N3-MYLAR FOR TOUCHPAD BRACKET PCE 2
....4 50-023476-00 E12B-MYLAR FOR TOUCH PAD-KS-0025 PCE 1
....4 50-961401-T1 P14N-#8162 K/B COVER ASS'Y-E1075 PCE 1
....4 51-035010-10 N100T1-EMI GASKET 773GT-10X4X100 PCE 0.03
....4 51-035010-10 N100T1-EMI GASKET 773GT-10X4X100 PCE 0.02
....4 51-350094-06 CONDUCTIVE SPONGE 10X1X1000mm-KL PCE 0.02
....4 51-350094-15 P88S-CONDUCTIVE SPONGE 10X0.5X10 PCE 0.02
....4 51-350094-16 P93S-CONDUCTIOVE SPONGE 10X2X100 PCE 0.16
....4 51-350094-16 P93S-CONDUCTIOVE SPONGE 10X2X100 PCE . 15
....4 52-000040-00 A2121-FOOT RUBBER-D4926A PCE 2
....4 52-002264-00 P14N-K/B RUBBER-E4032C PCE 1
....4 52-002276-00 P14N-K/B RUBBER COVER-E4075B PCE 1
....4 77-682007-00 R14KT1-#8574 LOWER COVER KIT PCE 1
.....5 40+002560+03 R14KT1-LOWER COVER-#8574-M-B1392 PCE 1
.....5 40-006040-00 N222S1-BATTERY HOOK-B3377B PCE 1
.....5 40-011951-00 N222S1-BATTERY LATCH SPRING-D479 PCE 1
.....5 41-420520-03 SCREW BPS/W (5.5)-M2X3L-NYLOK- PCE 2
.....5 50+043041+30 R14KT1-BATTERY LATCH-#8574-C3514 PCE 1
.....5 52-000040-00 A2121-FOOT RUBBER-D4926A PCE 2
....4 77-682007-10 R14KT1-#8162 UPPER COVER KIT PCE 1
.....5 22-300037-01 SPK (R)(L) W/MICROPHONE-W/O RUBB PCE 1
.....5 27-300051-10 N222S1-GASKET TAPE-D4877A PCE 3
.....5 27-300051-20 N222S1-GASKET TAPE-D4877A PCE 3
.....5 27-300051-30 P14N-GASKET TAPE-D4877A PCE 1
.....5 29-160250-00 P02G-TPD-PCB/MB FFC-P1.0x12P-CA2 PCE 1
.....5 29-160287-01 A2121-FFC TOUCHPAD TO TOUCHPAD P PCE 1
.....5 40+008281+00 R14KT1-UPPER COVER SPEAKER AL-FO PCE 2
.....5 40+008321+00 R14DT1-AL FOIL FOR POWER BUTTON- PCE 1
9
/
========================= ================================== ======= ===
.....5 40-002243-00 P14N-SPEAKER COVER-E4017A PCE 2
.....5 40-007050-50 A5000M-K/B SHIELDING ESD CU-FOIL PCE 2
.....5 40-008055-00 P14N-BOSS FOIL-E4185A PCE 1
.....5 40-008192-00 R15B-AL FOIL FOR CPU MODULE-F424 PCE 1
.....5 40-031362-00 P14N-TOUCHPAD BRACKET-B2254A PCE 1
.....5 41-720026-03 SCREW ISOT-M2.6X3L D4.5/H0.8mm PCE 8
.....5 41-720926-04 SCREW ISOT-2.6X4L-BLACK-NYLOK-B4 PCE 2
.....5 50+023694+00 R14KT1-UPPER COVER LENS MYLAR-F4 PCE 1
.....5 50-023256-00 P14N-TOUCHPAD SYNAPTICS MYLAR-E4 PCE 1
.....5 50-023263-00 P14N-SWITCH MYLAR-KL1885A PCE 1
.....5 50-040167-00 P78-MICRO PHONE RUBBER-B4549A PCE 1
.....5 50-968201-02 R14KT1-#8162 UPPER COVER ASS'Y-E PCE 1
.....5 51+036331+00 R14KT1-UPPER COVER SPONGE-F44780 PCE 1
.....5 51-350094-01 CONDUCTIVE SPONGE 5X2X1000mm-KL1 PCE 0.03
.....5 51-350094-05 CONDUCTIVE SPONGE 9X3.5X1000mm-K PCE 0.25
.....5 73-080052-00 TOUCH PAD-FOR SOTEC-SYNAPTICS-TM PCE 1
.....5 80-561000-00A P14N-PCB ASS'Y-SE-TOUCHPAD-REV:A PCE 1
..2 85-000682-40 R14KT1-#8162/#8574 BASE SYSTEM-W PCE 1
...3 63-000710-00 ALL MODEL-PRODUCT BAR CODE LABEL PCE 32
...3 66-682090-40 R14KT1-PCB'A W/REDFOX BIOS SET PCE 1
...3 80-8A1700-00B R14KT1-PCB ASS'Y-JP-USB+RJ11-REV PCE 1
....4 80-A17000-00B R14KT1-PCB ASS'Y-JP-USB+RJ11-REV PCE 1
...3 80-8A1710-00A R14KT1-PCB ASS'Y-JP-COM-REV:A-W/ PCE 1
...3 86-682000-00 #8162/#8574 SYSTEM CABINET-R14KT PCE 1
....4 29+015370+00 R14KT1-SB-USB FPC-CA370A PCE 1
....4 29+016372+00 R14KT1-COMPORT FFC-M/B-CA372B PCE 1
....4 29-005070-00 P14G-HDD CABLE-CA304A PCE 1
....4 40+003660+00 R14KT1-HEATSINK MODULE W/FAN-D30 PCE 1
....4 40+006200+00 R14KT1-CPU DOOR-#8574-M-D3081B PCE 1
10
/
========================= ================================== ======= ===
....4 40+006201+01 R14KT1-COMMUNICATION DOOR-#8574- PCE 1
....4 40+006203+00 R14KT1-STAND OFF-NI+SELF-LOCKING PCE 2
....4 40+011160+80 R14KT1-HDD DOOR-#8574-C3516F PCE 1
....4 40+011164+60 R14KT1-CD-ROM BRACKET DOOR-#8574 PCE 1
....4 40+031364+01 P14N-HDD BRACKET-B2256B PCE 1
....4 40-008163-00 E12T-AL FOIL FOR K/B BRACKET EMI PCE 1
....4 41+420526+04 SCREW BPS/W-B3892C-M2.6X4L,D6. PCE 3
....4 41-420520-03 SCREW BPS/W (5.5)-M2X3L-NYLOK- PCE 5
....4 41-720026-03 SCREW ISOT-M2.6X3L D4.5/H0.8mm PCE 3
....4 41-720926-04 SCREW ISOT-2.6X4L-BLACK-NYLOK-B4 PCE 13
....4 41-721026-06 SCREW ISOT-M2.6X6L D4.5/H0.8mm PCE 16
....4 41-721520-03 SCREW ISOT-M2X3L-SELF-LOCKING PCE 2
....4 41-850926-08 SCREW ISOP-M2.6X8L-BLACK-SELF-LO PCE 2
....4 44-000001-00 PROCESS MATERIALS FOR SYSTEM PCE 1
....4 50-023390-00 P14N3-MYLAR FOR TOUCHPAD BRACKET PCE 2
....4 50-023476-00 E12B-MYLAR FOR TOUCH PAD-KS-0025 PCE 1
....4 50-961401-T1 P14N-#8162 K/B COVER ASS'Y-E1075 PCE 1
....4 51-035010-10 N100T1-EMI GASKET 773GT-10X4X100 PCE 0.03
....4 51-035010-10 N100T1-EMI GASKET 773GT-10X4X100 PCE 0.02
....4 51-350094-06 CONDUCTIVE SPONGE 10X1X1000mm-KL PCE 0.02
....4 51-350094-15 P88S-CONDUCTIVE SPONGE 10X0.5X10 PCE 0.02
....4 51-350094-16 P93S-CONDUCTIOVE SPONGE 10X2X100 PCE 0.16
....4 51-350094-16 P93S-CONDUCTIOVE SPONGE 10X2X100 PCE 0.15
....4 52-000040-00 A2121-FOOT RUBBER-D4926A PCE 2
....4 52-002264-00 P14N-K/B RUBBER-E4032C PCE 1
....4 52-002276-00 P14N-K/B RUBBER COVER-E4075B PCE 1
....4 77-682007-00 R14KT1-#8574 LOWER COVER KIT PCE 1
.....5 40+002560+03 R14KT1-LOWER COVER-#8574-M-B1392 PCE 1
.....5 40-006040-00 N222S1-BATTERY HOOK-B3377B PCE 1
.....5 40-011951-00 N222S1-BATTERY LATCH SPRING-D479 PCE 1
11
/
========================= ================================== ======= ===
.....5 41-420520-03 SCREW BPS/W (5.5)-M2X3L-NYLOK- PCE 2
.....5 50+043041+30 R14KT1-BATTERY LATCH-#8574-C3514 PCE 1
.....5 52-000040-00 A2121-FOOT RUBBER-D4926A PCE 2
....4 77-682007-10 R14KT1-#8162 UPPER COVER KIT PCE 1
.....5 22-300037-01 SPK (R)(L) W/MICROPHONE-W/O RUBB PCE 1
.....5 27-300051-10 N222S1-GASKET TAPE-D4877A PCE 3
.....5 27-300051-20 N222S1-GASKET TAPE-D4877A PCE 3
.....5 27-300051-30 P14N-GASKET TAPE-D4877A PCE 1
.....5 29-160250-00 P02G-TPD-PCB/MB FFC-P1.0x12P-CA2 PCE 1
.....5 29-160287-01 A2121-FFC TOUCHPAD TO TOUCHPAD P PCE 1
.....5 40+008281+00 R14KT1-UPPER COVER SPEAKER AL-FO PCE 2
.....5 40+008321+00 R14DT1-AL FOIL FOR POWER BUTTON- PCE 1
.....5 40-002243-00 P14N-SPEAKER COVER-E4017A PCE 2
.....5 40-007050-50 A5000M-K/B SHIELDING ESD CU-FOIL PCE 2
.....5 40-008055-00 P14N-BOSS FOIL-E4185A PCE 1
.....5 40-008192-00 R15B-AL FOIL FOR CPU MODULE-F424 PCE 1
.....5 40-031362-00 P14N-TOUCHPAD BRACKET-B2254A PCE 1
.....5 41-720026-03 SCREW ISOT-M2.6X3L D4.5/H0.8mm PCE 8
.....5 41-720926-04 SCREW ISOT-2.6X4L-BLACK-NYLOK-B4 PCE 2
.....5 50+023694+00 R14KT1-UPPER COVER LENS MYLAR-F4 PCE 1
.....5 50-023256-00 P14N-TOUCHPAD SYNAPTICS MYLAR-E4 PCE 1
.....5 50-023263-00 P14N-SWITCH MYLAR-KL1885A PCE 1
.....5 50-040167-00 P78-MICRO PHONE RUBBER-B4549A PCE 1
.....5 50-968201-02 R14KT1-#8162 UPPER COVER ASS'Y-E PCE 1
.....5 51+036331+00 R14KT1-UPPER COVER SPONGE-F44780 PCE 1
.....5 51-350094-01 CONDUCTIVE SPONGE 5X2X1000mm-KL1 PCE 0.03
.....5 51-350094-05 CONDUCTIVE SPONGE 9X3.5X1000mm-K PCE 0.25
.....5 73-080052-00 TOUCH PAD-FOR SOTEC-SYNAPTICS-TM PCE 1
.....5 80-561000-00A P14N-PCB ASS'Y-SE-TOUCHPAD-REV:A PCE 1
12
/
========================= ================================== ======= ===
0.1 O-R14KT1-BAT R14KT1-BAT PCE 1
..2 89-682007-00 #8574/#8162 LI-ION BAT ASS'Y-PS- PCE 1
...3 23-050270-00 BAT-LIION-3S2P-2200mAh-#8574/#81 PCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
..2 89-682007-10 #8574/#8162 LI-ION BAT ASS'Y-SMP PCE 1
...3 23-050271-00 BAT-LIION-3S2P-2200mAh-#8574/#81 PCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
0.1 O-R14KT1-CPU R14KT1-CPU PCE 1
..2 89-665001-00 ASS'Y FOR AMD SAMPRON-3000+ 1800 PCE 1
...3 01-2001HB-M0 CPU-AMD K8 MOBILE SEMPRON 3000+- PCE 1
...3 63-001991-00 ALL MODEL-AMD SEMPRON INSIDE STI PCE 1
...3 63-001992-00 ALL MODEL-AMD SEMPRON OUTER CARTPCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
..2 89-671001-07 ASS'Y AMD SEMPROM-2800+ 1600MHZ PCE 1
...3 01-2000H9-M1 CPU-AMD K8 MOBILE SEMPRON 2800+- PCE 1
...3 63-001991-00 ALL MODEL-AMD SEMPRON INSIDE STI PCE 1
...3 63-001992-00 ALL MODEL-AMD SEMPRON OUTER CARTPCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
..2 89-682001-00 ASS'Y FOR AMD TURION-MT30 1600MH PCE 1
...3 01-2006L9-M0 CPU-AMD K8 MOBILE TURION 64 MT-3 PCE 1
...3 63+070900+00 AMD CARTON STICKER-TURION 64-PID PCE 1
...3 63+070901+00 AMD BEZEL STICKER-TURION 64-PID# PCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
..2 89-682001-01 ASS'Y FOR AMD TURION-MT32 1800MH PCE 1
...3 01-2005LB-M0 CPU-AMD K8 MOBILE TURION 64 MT-3 PCE 1
13
/
========================= ================================== ======= ===
...3 63+070900+00 AMD CARTON STICKER-TURION 64-PID PCE 1
...3 63+070901+00 AMD BEZEL STICKER-TURION 64-PID# PCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
..2 89-682001-02 ASS'Y FOR AMD TURION-MT34 1800MH PCE 1
...3 01-2006LB-M0 CPU-AMD K8 MOBILE TURION 64 MT-3 PCE 1
...3 63+070900+00 AMD CARTON STICKER-TURION 64-PID PCE 1
...3 63+070901+00 AMD BEZEL STICKER-TURION 64-PID# PCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
..2 89-682001-03 ASS'Y FOR AMD SEMPRON 3100+-1800 PCE 1
...3 01-2000HB-M0 CPU-AMD K8 MOBILE SEMPRON 3100+- PCE 1
...3 63-001991-00 ALL MODEL-AMD SEMPRON INSIDE STI PCE 1
...3 63-001992-00 ALL MODEL-AMD SEMPRON OUTER CARTPCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
..2 89-682001-04 ASS'Y FOR AMD TURION-MT28 1600MH PCE 1
...3 01-2005L9-M0 CPU-AMD K8 MOBILE TURION 64 MT-2 PCE 1
...3 63+070900+00 AMD CARTON STICKER-TURION 64-PID PCE 1
...3 63+070901+00 AMD BEZEL STICKER-TURION 64-PID# PCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
..2 89-682001-05 W/O CPU-AMD CPU THERMAL PAD ASS' PCE 1
...3 27+319070+00 R14KT1-KAPTON FOR THERMAL PAD-F4 PCE 1
...3 27+330221+00 R14KT1-THERMAL PAD-AF-S-05H-05B PCE 1
...3 60+001002+00 PE BAG 70X120mm PCE 1
0.1 O-R14KT1-HDD R14KT1-HDD PCE 1
..2 86-629204-20 40GB FUJITSU HDD ASS'Y-P14S PCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
14
/
========================= ================================== ======= ===
...3 70-922400-50 HDD-40GB-2.5"-9.5X100X70mm-MHT20 PCE 1
..2 86-674204-10 60GB HDD ASS'Y-FUJITSU-R15D PCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
...3 70-A22600-10 HDD-60GB-4200RPM-2.5" 9.5X100X70 PCE 1
..2 86-674204-20 80GB HDD ASS'Y-FUJITSU-R15D PCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
...3 70-B22801-00 HDD-80GB-4200RPM-MHT2080AT-FUJIT PCE 1
0.1 O-R14KT1-KB R14KT1-KB PCE 1
..2 89-682003-00 US K/B ASS'Y-R14KT1 PCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
...3 71+839101+00 K/B-85 KEY-EN-36599#-R14KT1-K981 PCE 1
..2 89-682003-01 FR K/B ASS'Y-R14KT1 PCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
...3 71+839105+00 K/B-85 KEY-FR-36599#-R14KT1-K981 PCE 1
..2 89-682003-02 XZ K/B ASS'Y-R14KT1 PCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
...3 71+839108+00 K/B-85 KEY-XZ-36599#-R14KT1-K981 PCE 1
..2 89-682003-03 XC K/B ASS'Y-R14KT1 PCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
...3 71+839139+00 K/B-85 KEY-XC-36599#-R14KT1-K981 PCE 1
..2 89-682003-04 ES K/B ASS'Y-R14KT1 PCE 1
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
...3 71+839109+00 K/B-85 KEY-ES-36599#-R14KT1-K981 PCE 1
15
/
========================= ================================== ======= ===
0.1 O-R14KT1-LCD R14KT1-LCD PCE 1
..2 86-682D05-00 #8162/#8574 DISPLAY ASS'Y-14.1" PCE 1
...3 22-600170-00 ANTENNA FOR LCD & 802.11A/B/G-F4 PCE 1
...3 22-600171-00 ANTENNA FOR BASE(802.11ABG)-F431 PCE 1
...3 27-600020-01 P14N-MAGNET-11.9X5.9X4mm-E4076A- PCE 1
...3 29-001780-00 R14KT1-LCD HARNESS FOR HYUNDAI-H PCE 1
...3 40+002241+I0 R14KT1-LCD COVER-#8574-B1192G PCE 1
...3 40+008280+00 R14KT1-LCD PANEL AL-FOIL-F44440 PCE 2
...3 40-008050-00 P14N-LCD AL FOIL-E4109A PCE 4
...3 40-011131-00 P90E-BATTERY LATCH SPRING-C4686A PCE 2
...3 40-015710-00 P14S-HINGE R-F4197A PCE 1
...3 40-015711-00 P14S-HINGE L-F4198A PCE 1
...3 40-030640-00 P14S-LCD BRACKET-MG R FOR TOSHIB PCE 1
...3 40-030641-00 P14S-LCD BRACKET-MG L FOR TOSHIB PCE 1
...3 41-720926-04 SCREW ISOT-2.6X4L-BLACK-NYLOK-B4 PCE 4
...3 41-721520-03 SCREW ISOT-M2X3L-SELF-LOCKING PCE 4
...3 41-721526-05 SCREW ISOT-M2.6X5L H=0.8mm-NYLOK PCE 2
...3 50+035093+70 R14KT1-ANTENNA COVER-#8574-E4091 PCE 1
...3 50-000360-00 R14S-LCD DUMMY LENS PLATE-E4823A PCE 1
...3 50-025030-00 P14N-LCD LENS-E4009A PCE 1
...3 50-041011-11 P14N-LCD HOOK R-POM-E4007E PCE 1
...3 50-041012-11 P14N-LCD HOOK L-POM-E4008E PCE 1
...3 50-961401-U2 P14N-#8162 LCD PANEL W/O LOGO-E1 PCE 1
...3 51+036332+00 R14KT1-SPONGE FOR LCD PANEL-245X PCE 1
...3 51-036080-20 P14N-LCD R SPONGE FOR QDI141-E40 PCE 1
...3 51-036084-20 P14N-LCD L SPONGE FOR QDI141-E41 PCE 1
...3 51-036085-20 P14N-LCD MIDDLE SPONGE FOR QDI14 PCE 1
...3 51-350094-05 CONDUCTIVE SPONGE 9X3.5X1000mm-K PCE 0.12
...3 52+002450+00 R14KT1-HYDIS LCD RUBBER-L-F44420 PCE 1
16
/
========================= ================================== ======= ===
...3 52+002451+00 R14KT1-HYDIS LCD RUBBER-R-F44430 PCE 1
...3 52-001085-H0 E14A-RUBBER PAD-PANTONE 428C-B44 PCE 2
...3 52-002054-00 P14S-RUBBER L FOR TOSHIBA-E4665A PCE 1
...3 52-002055-00 P14S-RUBBER R FOR TOSHIBA-E4664A PCE 1
...3 52-002056-00 P14S-UPPER RUBBER-FOR HYUNDAI HT PCE 2
...3 52-002271-10 E14A-PANEL SCREW RUBBER-PANTONE PCE 2
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 2
...3 72-11423H-03 LCD-14.1"-TFT XGA-A-60mm-HYUNDAI PCE 1
...3 76-030029-00 INVERTER-5V-5W-DARFON-V069-201-R PCE 1
..2 86-682D05-30 #8162/#8574 DISPLAY ASS'Y-14.1" PCE 1
...3 22-600170-00 ANTENNA FOR LCD & 802.11A/B/G-F4 PCE 1
...3 22-600171-00 ANTENNA FOR BASE(802.11ABG)-F431 PCE 1
...3 27-600020-01 P14N-MAGNET-11.9X5.9X4mm-E4076A- PCE 1
...3 29-001780-00 R14KT1-LCD HARNESS FOR HYUNDAI-H PCE 1
...3 40+002241+I0 R14KT1-LCD COVER-#8574-B1192G PCE 1
...3 40+008280+00 R14KT1-LCD PANEL AL-FOIL-F44440 PCE 2
...3 40-008050-00 P14N-LCD AL FOIL-E4109A PCE 4
...3 40-011131-00 P90E-BATTERY LATCH SPRING-C4686A PCE 2
...3 40-015710-00 P14S-HINGE R-F4197A PCE 1
...3 40-015711-00 P14S-HINGE L-F4198A PCE 1
...3 40-030640-00 P14S-LCD BRACKET-MG R FOR TOSHIB PCE 1
...3 40-030641-00 P14S-LCD BRACKET-MG L FOR TOSHIB PCE 1
...3 41-720926-04 SCREW ISOT-2.6X4L-BLACK-NYLOK-B4 PCE 4
...3 41-721520-03 SCREW ISOT-M2X3L-SELF-LOCKING PCE 4
...3 41-721526-05 SCREW ISOT-M2.6X5L H=0.8mm-NYLOK PCE 2
...3 50+035093+70 R14KT1-ANTENNA COVER-#8574-E4091 PCE 1
...3 50-000360-00 R14S-LCD DUMMY LENS PLATE-E4823A PCE 1
...3 50-025030-00 P14N-LCD LENS-E4009A PCE 1
...3 50-041011-11 P14N-LCD HOOK R-POM-E4007E PCE 1
17
/
========================= ================================== ======= ===
...3 50-041012-11 P14N-LCD HOOK L-POM-E4008E PCE 1
...3 50-961401-U2 P14N-#8162 LCD PANEL W/O LOGO-E1 PCE 1
...3 51+036332+00 R14KT1-SPONGE FOR LCD PANEL-245X PCE 1
...3 51-036080-20 P14N-LCD R SPONGE FOR QDI141-E40 PCE 1
...3 51-036084-20 P14N-LCD L SPONGE FOR QDI141-E41 PCE 1
...3 51-036085-20 P14N-LCD MIDDLE SPONGE FOR QDI14 PCE 1
...3 51-350094-05 CONDUCTIVE SPONGE 9X3.5X1000mm-K PCE 0.12
...3 52+002450+00 R14KT1-HYDIS LCD RUBBER-L-F44420 PCE 1
...3 52+002451+00 R14KT1-HYDIS LCD RUBBER-R-F44430 PCE 1
...3 52-001085-H0 E14A-RUBBER PAD-PANTONE 428C-B44 PCE 2
...3 52-002054-00 P14S-RUBBER L FOR TOSHIBA-E4665A PCE 1
...3 52-002055-00 P14S-RUBBER R FOR TOSHIBA-E4664A PCE 1
...3 52-002056-00 P14S-UPPER RUBBER-FOR HYUNDAI HT PCE 2
...3 52-002271-10 E14A-PANEL SCREW RUBBER-PANTONE PCE 2
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 2
...3 72+11423E+00 LCD-14.1" TFT XGA-AU-B141XG10 PCE 1
...3 76-030029-00 INVERTER-5V-5W-DARFON-V069-201-R PCE 1
..2 86-682D05-40 #8162/#8574 DISPLAY ASS'Y-14.1" PCE 1
...3 22-600170-00 ANTENNA FOR LCD & 802.11A/B/G-F4 PCE 1
...3 22-600171-00 ANTENNA FOR BASE(802.11ABG)-F431 PCE 1
...3 27-600020-01 P14N-MAGNET-11.9X5.9X4mm-E4076A- PCE 1
...3 29-001780-00 R14KT1-LCD HARNESS FOR HYUNDAI-H PCE 1
...3 40+002241+I0 R14KT1-LCD COVER-#8574-B1192G PCE 1
...3 40+008280+00 R14KT1-LCD PANEL AL-FOIL-F44440 PCE 2
...3 40-008050-00 P14N-LCD AL FOIL-E4109A PCE 4
...3 40-011131-00 P90E-BATTERY LATCH SPRING-C4686A PCE 2
...3 40-015710-00 P14S-HINGE R-F4197A PCE 1
...3 40-015711-00 P14S-HINGE L-F4198A PCE 1
...3 40-030640-00 P14S-LCD BRACKET-MG R FOR TOSHIB PCE 1
18
/
========================= ================================== ======= ===
...3 40-030641-00 P14S-LCD BRACKET-MG L FOR TOSHIB PCE 1
...3 41-720926-04 SCREW ISOT-2.6X4L-BLACK-NYLOK-B4 PCE 4
...3 41-721520-03 SCREW ISOT-M2X3L-SELF-LOCKING PCE 4
...3 41-721526-05 SCREW ISOT-M2.6X5L H=0.8mm-NYLOK PCE 2
...3 50+035093+70 R14KT1-ANTENNA COVER-#8574-E4091 PCE 1
...3 50-000360-00 R14S-LCD DUMMY LENS PLATE-E4823A PCE 1
...3 50-025030-00 P14N-LCD LENS-E4009A PCE 1
...3 50-041011-11 P14N-LCD HOOK R-POM-E4007E PCE 1
...3 50-041012-11 P14N-LCD HOOK L-POM-E4008E PCE 1
...3 50-961401-U2 P14N-#8162 LCD PANEL W/O LOGO-E1 PCE 1
...3 51+036330+00 R14KT1-LCD PANEL LOWER SPONGE-F4 PCE 1
...3 51-036080-40 P14N-LCD R SPONGE FOR TOSHIBA-T= PCE 1
...3 51-036084-40 P14N-LCD L SPONGE FOR TOSHIBA-T= PCE 1
...3 51-036085-40 P14N-LCD MIDDLE SPONGE FOR TOSHI PCE 1
...3 51-350094-05 CONDUCTIVE SPONGE 9X3.5X1000mm-K PCE 0.12
...3 52+002450+00 R14KT1-HYDIS LCD RUBBER-L-F44420 PCE 1
...3 52+002451+00 R14KT1-HYDIS LCD RUBBER-R-F44430 PCE 1
...3 52+002452+00 R14KT1-RUBBER FOR LCD-HYDIS HT14 PCE 1
...3 52-001085-H0 E14A-RUBBER PAD-PANTONE 428C-B44 PCE 2
...3 52-002054-00 P14S-RUBBER L FOR TOSHIBA-E4665A PCE 1
...3 52-002055-00 P14S-RUBBER R FOR TOSHIBA-E4664A PCE 1
...3 52-002056-00 P14S-UPPER RUBBER-FOR HYUNDAI HT PCE 1
...3 52-002271-10 E14A-PANEL SCREW RUBBER-PANTONE PCE 2
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 2
...3 72+11423H+20 LCD-14.1" TFT XGA-BOEHYDIS-HT14X PCE 1
...3 76-030029-00 INVERTER-5V-5W-DARFON-V069-201-R PCE 1
..2 86-682D05-50 #8162/#8574 DISPLAY ASS'Y-14.1" PCE 1
...3 22-600170-00 ANTENNA FOR LCD & 802.11A/B/G-F4 PCE 1
...3 22-600171-00 ANTENNA FOR BASE(802.11ABG)-F431 PCE 1
19
/
========================= ================================== ======= ===
...3 27-600020-01 P14N-MAGNET-11.9X5.9X4mm-E4076A- PCE 1
...3 29-001780-00 R14KT1-LCD HARNESS FOR HYUNDAI-H PCE 1
...3 40+002241+I0 R14KT1-LCD COVER-#8574-B1192G PCE 1
...3 40+008280+00 R14KT1-LCD PANEL AL-FOIL-F44440 PCE 2
...3 40-008050-00 P14N-LCD AL FOIL-E4109A PCE 4
...3 40-011131-00 P90E-BATTERY LATCH SPRING-C4686A PCE 2
...3 40-015710-00 P14S-HINGE R-F4197A PCE 1
...3 40-015711-00 P14S-HINGE L-F4198A PCE 1
...3 40-030640-00 P14S-LCD BRACKET-MG R FOR TOSHIB PCE 1
...3 40-030641-00 P14S-LCD BRACKET-MG L FOR TOSHIB PCE 1
...3 41-720926-04 SCREW ISOT-2.6X4L-BLACK-NYLOK-B4 PCE 4
...3 41-721520-03 SCREW ISOT-M2X3L-SELF-LOCKING PCE 4
...3 41-721526-05 SCREW ISOT-M2.6X5L H=0.8mm-NYLOK PCE 2
...3 50+035093+70 R14KT1-ANTENNA COVER-#8574-E4091 PCE 1
...3 50-000360-00 R14S-LCD DUMMY LENS PLATE-E4823A PCE 1
...3 50-025030-00 P14N-LCD LENS-E4009A PCE 1
...3 50-041011-11 P14N-LCD HOOK R-POM-E4007E PCE 1
...3 50-041012-11 P14N-LCD HOOK L-POM-E4008E PCE 1
...3 50-961401-V0 P14N-#8162 LCD PANEL ASS'Y-FOR H PCE 1
...3 51+036332+00 R14KT1-SPONGE FOR LCD PANEL-245X PCE 1
...3 51-036080-00 P14N-LCD R SPONGE FOR CHI MEI-E4 PCE 1
...3 51-036084-00 P14N-LCD L SPONGE FOR CHI MEI-E4 PCE 1
...3 51-036085-00 P14N-LCD MIDDLE SPONGE FOR CHI M PCE 1
...3 51-350094-05 CONDUCTIVE SPONGE 9X3.5X1000mm-K PCE 0.12
...3 52+002450+00 R14KT1-HYDIS LCD RUBBER-L-F44420 PCE 1
...3 52+002451+00 R14KT1-HYDIS LCD RUBBER-R-F44430 PCE 1
...3 52-001085-H0 E14A-RUBBER PAD-PANTONE 428C-B44 PCE 2
...3 52-002054-00 P14S-RUBBER L FOR TOSHIBA-E4665A PCE 1
...3 52-002055-00 P14S-RUBBER R FOR TOSHIBA-E4664A PCE 1
...3 52-002056-00 P14S-UPPER RUBBER-FOR HYUNDAI HT PCE 2
20
/
========================= ================================== ======= ===
...3 52-002271-10 E14A-PANEL SCREW RUBBER-PANTONE PCE 2
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 2
...3 72-114233-30HAS LCD-14.1" TFT XGA-QDI-QD14XL07-H PCE 1
...3 76-030029-00 INVERTER-5V-5W-DARFON-V069-201-R PCE 1
0.1 O-R14KT1-MEM R14KT1-MEM PCE 1
..2 89-641002-04 ASS'Y FOR 256MB DDR RAM-0.13 PRO PCE 1
...3 18-060005-L0 DDR SO-DIMM-M2S5I08D6APS5F081AA- PCE 1
...3 63-250080-01 BAR CODE LABEL 20X8X0.08mm-KL162 PCE 1
..2 89-665002-00 ASS'Y FOR 512MB DDR RAM-W/A-DATA PCE 1
...3 18-060006-D0 DDR SDRAM SO-DIMM-ADFDB290800H-5 PCE 1
...3 63-250080-01 BAR CODE LABEL 20X8X0.08mm-KL162 PCE 1
0.1 O-R14KT1-MODEL R14KT1-MODEL PCE 1
..2 89-682006-00 PARTS KIT FOR GENERIC-R14KT1 PCE 1
...3 50+000531+00 R14KT1-PROTECT SHEET-FOR 14" LCD PCE 1
...3 63+B40400+30 R14KT1-FCC RATING LABEL-EN/XT-F4 PCE 1
...3 65-003000-04 LICENSE FEE-IBM ROYALTY FOR 486D PCE 1
..2 89-682006-01 PARTS KIT FOR T/H CHINA-R14KT1 PCE 1
...3 40+004090+D0 R15B-LCD COVER NAME PLATE-FOR TH PCE 1
...3 40+004360+00 ALL MODEL-LCD PANEL NAME PLATE-F PCE 1
...3 50+000531+00 R14KT1-PROTECT SHEET-FOR 14" LCD PCE 1
...3 63+023090+B0 R14KT1-MODEL NAME LABEL TWINHEAD PCE 1
...3 63+B40400+00 R14KT1-FCC RATING LABEL-EN/ZH/XT PCE 1
...3 65-003000-04 LICENSE FEE-IBM ROYALTY FOR 486D PCE 1
..2 89-682006-03 PARTS KIT FOR HASEE-R14KT1 PCE 1
...3 40+004090+T0 R14KT1-LCD COVER NAME PLATE-FOR PCE 1
21
/
========================= ================================== ======= ===
...3 50+000531+00 R14KT1-PROTECT SHEET-FOR 14" LCD PCE 1
...3 65-003000-04 LICENSE FEE-IBM ROYALTY FOR 486D PCE 1
..2 89-682006-04 PARTS KIT FOR REDFOX-R14KT1 PCE 1
...3 40+004090+V0 R14KT1-LCD COVER NAME PLATE-FOR PCE 1
...3 50+000531+00 R14KT1-PROTECT SHEET-FOR 14" LCD PCE 1
...3 63+B40400+30 R14KT1-FCC RATING LABEL-EN/XT-F4 PCE 1
...3 65-003000-04 LICENSE FEE-IBM ROYALTY FOR 486D PCE 1
0.1 O-R14KT1-MODEM R14KT1-MODEM PCE 1
..2 89-682005-36 56K MODEM ASS'Y-QCOM-R14KT1 PCE 1
...3 29+001774+00 R14KT1-MDC HARNESS-SH7740 PCE 1
...3 41-420520-03 SCREW BPS/W (5.5)-M2X3L-NYLOK- PCE 2
...3 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
...3 76-060009-00 MDC MODEM CARD-12mA-3.3V-39.6mW- PCE 1
0.1 O-R14KT1-ODD R14KT1-ODD PCE 1
..2 89-682005-30 #8574 QSI DVD DUAL ASS'Y-W/CYBER PCE 1
...3 70+150190+01 POWER DVD 5.0+POWER 2 GO 4.0+POW PCE 1
...3 86-682008-20 #8574 DVD-DUAL ASS'Y-QSI-R14KT1 PCE 1
....4 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
....4 70+250009+00 DVD DUAL(CD-RW/DVD-RW/DVD+RW)-SDPCE 1
....4 77-682008-10 R14KT1-#8574 DVD-DUAL KIT-G BAS PCE 1
.....5 40+031680+01 R14KT1-CD-ROM BRACKET-F4310A PCE 1
.....5 41-760520-25 SCREW ISOTT-M2X2.5L-NYLOK-B3516Z PCE 4
.....5 50-968201-21 R14KT1-#8574 DVD-DUAL BEZEL G BA PCE 1
..2 89-682005-31 #8574 QSI COMBO ASS'Y-W/CYBERLIN PCE 1
...3 70+150190+01 POWER DVD 5.0+POWER 2 GO 4.0+POW PCE 1
...3 86-682008-30 #8574 COMBO ASS'Y-QSI-R14KT1 PCE 1
22
/
========================= ================================== ======= ===
....4 63-250190-00 KEY PARTS BARCODE LABEL-KL18260 PCE 1
....4 70+210029+00 COMBO(CD-ROM/CD-RW/DVD-ROM)-GBAS PCE 1
....4 77-682008-00 R14KT1-#8574 COMBO KIT-G BAS LIT PCE 1
.....5 40+031680+01 R14KT1-CD-ROM BRACKET-F4310A PCE 1
.....5 41-760520-25 SCREW ISOTT-M2X2.5L-NYLOK-B3516Z PCE 4
.....5 50-968201-11 R14KT1-#8574 COMBO BEZEL G BAS A PCE 1
..2 89-682005-32 GBAS COMBO KIT ASS'Y-R14KT1 PCE 1
...3 60-010002-00 PE BAG 120X200mm PCE 1
...3 77-682008-00 R14KT1-#8574 COMBO KIT-G BAS LIT PCE 1
....4 40+031680+01 R14KT1-CD-ROM BRACKET-F4310A PCE 1
....4 41-760520-25 SCREW ISOTT-M2X2.5L-NYLOK-B3516Z PCE 4
....4 50-968201-11 R14KT1-#8574 COMBO BEZEL G BAS A PCE 1
0.1 O-R14KT1-OPT2 R14KT1-OPT2 PCE 1
..2 50-020355-00 N222S1-DUMMY CARD-C3707 PCE 1
..2 76-010604-00 ADAPTER-20V-65W-BLACK-3PIN-LISHI PCE 1
0.1 O-R14KT1-PACKING R14KT1-PACKING PCE 1
..2 87-000614-30 5 IN 1 PACKING-P14N PCE 1
...3 60-010026-00 PE BAG 200X150 mm A4382 PCE 1
...3 60-012001-00 PE BAG W/ARTWORK 360*380 PCE 1
...3 61-002152-00 P14N-5 IN 1 LOWER EPE CUSHION-C3 PCE 0.2
...3 61-002153-00 P14N-5 IN 1 UPPER EPE CUSHION-C3 PCE 0.2
...3 61-012272-00 P14N-5 IN 1 PAPER SHEET FOR BATT PCE 0.2
...3 61-012274-00 P14N-5 IN 1 PAPER BOARD FOR SYST PCE 0.2
...3 61-012414-40 P14S-PALLET AROUND PAPER BOARD-1 PCE . 17
...3 61-012415-20 P14S-PALLET UP DOWN PAPER BOARD- PCE . 33
...3 61-015040-00 A5010-PROTECT PAPER-D44770 PCE 1
...3 61-015090-00 E14B-PROTECT PAPER FOR SYSTEM-F4 PCE 1
23
/
========================= ================================== ======= ===
...3 61-050112-00 OUTER CARTON FOR P79S 2 IN 1-B33 PCE 0.2
...3 61-110010-00 PALLET FOR SHARP AV-1 -KL1302C PCE .0 166
...3 63-001132-00 PACKING LABEL 100X150mm-C4219A PCE 0.2
..2 89-682005-20 T/H-CHINA 2 IN 1 PACKING-R14KT1 PCE 1
...3 29-021060-00 E12T-TELEPHONE CORD (MODEM CABLE PCE 1
...3 62+009380+00 QUICK START GUIDE-8 IN 1-R1.00-F PCE 1
...3 62+079990+10 WARRENTY CARD 2005-XT-FOR CHINA- PCE 1
...3 62-079991-00 WARRENTY LIST PAPER-XT-FOR CHINA PCE 1
...3 62-099990-00 PASS CARD-XT-FOR CHINA-ALL TH MO PCE 1
...3 62-099991-00 PACKING LIST-XT-FOR CHINA-ALL TH PCE 1
...3 63+070111+00 R15D-CHINA LABEL FOR COLOR BOX PCE 1
...3 63+070231+00 F12DT1-3C LABEL-QCOM P/N.ML3054- PCE 1
...3 70+140870+00 UTILITY CD-R1.00-R14KT1 PCE 1
...3 76-010604-00 ADAPTER-20V-65W-BLACK-3PIN-LISHI PCE 1
...3 87-000682-00 2 IN 1 PACKING FOR DURABOOK-W/AC PCE 1
....4 50-000040-00 P9+-PLASTIC HANDLE-C35280 PCE 1
....4 60-010070-00 PLASTIC BAG-35cmX25cm-FOR CD/MAN PCE 1
....4 60-010200-00 BIG PE BAG PCE .0 417
....4 60-012001-00 PE BAG W/ARTWORK 360*380 PCE 1
....4 61+040106+C0 R14KT1-COLOR BOX -C3062E-FOR DUR PCE 1
....4 61-000845-00 PET OPC 1206 STRAC PCE .0 3
....4 61-002150-00 P14N-2 IN 1 L EPE CUSHION-C3532A PCE 1
....4 61-002151-00 P14N-2 IN 1 R EPE CUSHION-C3533A PCE 1
....4 61-009010-00 ALL MODEL-ANGLE PROTECTOR-KL1888 PCE .0 834
....4 61-012160-00 P14G-PAPER TUBE-FOR ADAPTER & PO PCE 1
....4 61-012261-00 P11-PAPER BOARD FOR EX-FDD-E4081 PCE 1
....4 61-012271-00 P14N-PAPER SHEET-FOR MOUSE & CAB PCE 1
....4 61-012414-F0 P14S-PALLET AROUND PAPER BOARD-8 PCE .0 417
....4 61-012415-50 P14S-PALLET UP DOWN PAPER BOARD- PCE .0 834
24
/
========================= ================================== ======= ===
....4 61-015040-00 A5010-PROTECT PAPER-D44770 PCE 1
....4 61-030330-00 A9110-INSIDE BOX FOR W/ACCESSORY PCE 1
....4 61-050136-00 A9110-2/1 CARTON W/ACCESSORY BO PCE 0.5
....4 61-097608-00 ANGLE PROTECTOR 76X76X800mm-KL14 PCE .0 834
....4 61-097615-00 ANGLE PROTECTOR 76X76X1040mm-KL1 PCE . 167
....4 61-110024-10 ALL MODEL-PALLET FOR T/H MODEL-W PCE .0 417
....4 63-001132-00 PACKING LABEL 100X150mm-C4219A PCE 1.5
..2 89-682005-21 T/H-ABEC 2 IN 1 PACKING-R14KT1 PCE 1
...3 29-021060-00 E12T-TELEPHONE CORD (MODEM CABLE PCE 1
...3 62+009380+00 QUICK START GUIDE-8 IN 1-R1.00-F PCE 1
...3 70+140870+00 UTILITY CD-R1.00-R14KT1 PCE 1
...3 76-010604-00 ADAPTER-20V-65W-BLACK-3PIN-LISHI PCE 1
...3 87-000682-00 2 IN 1 PACKING FOR DURABOOK-W/AC PCE 1
....4 50-000040-00 P9+-PLASTIC HANDLE-C35280 PCE 1
....4 60-010070-00 PLASTIC BAG-35cmX25cm-FOR CD/MAN PCE 1
....4 60-010200-00 BIG PE BAG PCE .0 417
....4 60-012001-00 PE BAG W/ARTWORK 360*380 PCE 1
....4 61+040106+C0 R14KT1-COLOR BOX -C3062E-FOR DUR PCE 1
....4 61-000845-00 PET OPC 1206 STRAC PCE .0 3
....4 61-002150-00 P14N-2 IN 1 L EPE CUSHION-C3532A PCE 1
....4 61-002151-00 P14N-2 IN 1 R EPE CUSHION-C3533A PCE 1
....4 61-009010-00 ALL MODEL-ANGLE PROTECTOR-KL1888 PCE .0 834
....4 61-012160-00 P14G-PAPER TUBE-FOR ADAPTER & PO PCE 1
....4 61-012261-00 P11-PAPER BOARD FOR EX-FDD-E4081 PCE 1
....4 61-012271-00 P14N-PAPER SHEET-FOR MOUSE & CAB PCE 1
....4 61-012414-F0 P14S-PALLET AROUND PAPER BOARD-8 PCE .0 417
....4 61-012415-50 P14S-PALLET UP DOWN PAPER BOARD- PCE .0 834
....4 61-015040-00 A5010-PROTECT PAPER-D44770 PCE 1
....4 61-030330-00 A9110-INSIDE BOX FOR W/ACCESSORY PCE 1
25
/
========================= ================================== ======= ===
....4 61-050136-00 A9110-2/1 CARTON W/ACCESSORY BO PCE 0.5
....4 61-097608-00 ANGLE PROTECTOR 76X76X800mm-KL14 PCE .0 834
....4 61-097615-00 ANGLE PROTECTOR 76X76X1040mm-KL1 PCE . 167
....4 61-110024-10 ALL MODEL-PALLET FOR T/H MODEL-W PCE .0 417
....4 63-001132-00 PACKING LABEL 100X150mm-C4219A PCE 1.5
..2 89-682005-22 5 IN 1 PACKING FOR HASEE-R14KT1 PCE 1
...3 27+319070+00 R14KT1-KAPTON FOR THERMAL PAD-F4 PCE 1
...3 27+330221+00 R14KT1-THERMAL PAD-AF-S-05H-05B PCE 1
...3 29-021060-00 E12T-TELEPHONE CORD (MODEM CABLE PCE 1
...3 60-010001-00 PE BAG 70X120mm PCE 1
...3 63+070231+00 F12DT1-3C LABEL-QCOM P/N.ML3054- PCE 1
...3 70+140870+00 UTILITY CD-R1.00-R14KT1 PCE 1
...3 76-010604-00 ADAPTER-20V-65W-BLACK-3PIN-LISHI PCE 1
...3 87-000614-70 5 IN 1 PACKING FOR INSIDE BOX-P1 PCE 1
....4 60-010065-00 PE BAG FOR P79 PORT REPLICAT PCE 1
....4 60-012001-00 PE BAG W/ARTWORK 360*380 PCE 1
....4 61-000845-00 PET OPC 1206 STRAC PCE .0 19
....4 61-002170-00 N222S8-5 IN 1 EPE CUSHION-FOR IN PCE 0.4
....4 61-007080-00 P14N-PAPER CUSHION FOR INSIDE BO PCE 1
....4 61-012273-00 P14N-PAPER BOARD FOR INSIDE BOX- PCE 1
....4 61-012412-00 D212A-5 IN 1 PAPER SHEET-E4734-F PCE 0.2
....4 61-012413-00 D212A-5 IN 1 PAPER TUBE-E47970-F PCE 0.4
....4 61-012414-80 E14A-PALLET AROUND PAPER BOARD-1 PCE .0 167
....4 61-012415-10 E14A-PALLET UP DOWN PAPER BOARD- PCE .0 167
....4 61-015040-00 A5010-PROTECT PAPER-D44770 PCE 1
....4 61-015090-00 E14B-PROTECT PAPER FOR SYSTEM-F4 PCE 1
....4 61-030040-00 INSIDE BOX FOR SLE-A2333A PCE 1
....4 61-050135-00 A9110-2/1 CARTON W/CARRY BAG-A26 PCE 0.2
....4 61-097608-00 ANGLE PROTECTOR 76X76X800mm-KL14 PCE .0 334
26
/
========================= ================================== ======= ===
....4 61-097615-00 ANGLE PROTECTOR 76X76X1040mm-KL1 PCE .0 334
....4 61-110010-00 PALLET FOR SHARP AV-1 -KL1302C PCE .0 167
....4 63-001132-00 PACKING LABEL 100X150mm-C4219A PCE 0.2
..2 89-682005-23 2 IN 1 PACKING FOR REDFOX-R14KT1 PCE 1
...3 29-021060-00 E12T-TELEPHONE CORD (MODEM CABLE PCE 1
...3 70+140870+01 UTILITY CD-R1.01-W/USER MANUAL-R PCE 1
...3 76-010604-00 ADAPTER-20V-65W-BLACK-3PIN-LISHI PCE 1
...3 87-000682-20 2 IN 1 PACKING FOR REDFOX-W/ACCE PCE 1
....4 50-000040-00 P9+-PLASTIC HANDLE-C35280 PCE 1
....4 60-010070-00 PLASTIC BAG-35cmX25cm-FOR CD/MAN PCE 1
....4 60-010200-00 BIG PE BAG PCE .0 417
....4 60-012001-00 PE BAG W/ARTWORK 360*380 PCE 1
....4 61+040106+D0 R14KT1-COLOR BOX -C3062-FOR REDF PCE 1
....4 61-000845-00 PET OPC 1206 STRAC PCE .0 3
....4 61-002150-00 P14N-2 IN 1 L EPE CUSHION-C3532A PCE 1
....4 61-002151-00 P14N-2 IN 1 R EPE CUSHION-C3533A PCE 1
....4 61-009010-00 ALL MODEL-ANGLE PROTECTOR-KL1888 PCE .0 834
....4 61-012160-00 P14G-PAPER TUBE-FOR ADAPTER & PO PCE 1
....4 61-012261-00 P11-PAPER BOARD FOR EX-FDD-E4081 PCE 1
....4 61-012271-00 P14N-PAPER ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
