Image preview - the first page of the document
TIANJIN EE19-D CCFL Driving Inverter Transformer


>> Download TIANJIN EE19-D CCFL Driving Inverter Transformer documenatation <<

Text preview - extract from the document
CCFL Driving Inverter Transformer
EE19 TYPE
MECHANICAL DIMENSION:




                                        6                    7
                                                                                                            SCHEMATIC

                                        1                    10

UNIT:mm



CHARACTERISTIC (REFERENCE)


                        INPUT VOLTAGE       SUITABLE FREQUENCY      MAX. LAMP WATTAGE   MAX. OPEN VOLTAGE         EFFICIENCY
    PART NO.
                             ( Vdc )               ( KHz )                 (W)               ( Vrms )                   (%)

     T01XXX                   5~22                 30~80                     8                2000                  75~80




TIANJIN MONITRONICS INC.
6-1,NO.1 XINGHUA BRANCH ROAD.XIQING ECONOMIC DEVELOPMENT AREA,TIANJIN CHINA
TEL: (022)83967173 83967172 83968665 FAX: (022)83968667 83968670 POSTCODE: 300381
http://www.tjmti.com.cn
