Image preview - the first page of the document
>> Download Guildline6535Datasheet documenatation <<
Text preview - extract from the document
High
6535 Automated High Resistance
Measurement System
The 6535 is a modular High Resistance Measurement System consisting of Guildline's new
6530 TeraOhm Bridge-Meter, our new 6564 High Resistance Scanner and optionally the
Temperature Stabilized 6636 High Resistance Standards. Individual data sheets can be
located on the Guildline Website for each of these instruments and standards.
Guildline's 6535 High Resistance Measurement System provides demanding users around the
world the best in DC High Resistance
Measurement performance and value for
the range of 100 kOhms to 20 POhms.
Incorporating some of the most unique
standards available for measurement, this
system is the only "turn-key" Automated
High Resistance Measurement System
available today. Guildline unique
Standards include the 6530 TeraOhm
Bridge-Meter, a 6564 High Resistance
Scanner and our 6636 Temperature
Stabilized High Value Resistance Standard.
The 6535 is used to automate multiple
measurements with Direct Measurement
and Bridge Ratio Modes up to 20 P's.
6535 Front View
The System is highly configurable to meet wide ranging workload requirements. The 6535 is
capable of dual modes of operation with direct resistance measurements from 100 k to 20 P
with voltages to 1000 Volts. Similarly, the 6535 System provides a Bridge Ratio mode to allow
the absolute best uncertainty found in any commercialized automated system today. The
Current Mode Option allows the System to measure direct current from 10-5 to 10-13 Amps. With
the use of the 6636 resistance standards, the 6535 System can also generate traceable, low
uncertainty, currents.
Guildline's unique design and modularity allows customers to purchase what they need today to
support their research, or the calibration of their current work-load, and be assured of an
upgrade path to support their future requirements. The system is typically delivered ready for
use in a single `fly-away' rack. In fact, a system with a built in 8 Element 6636 Resistance
Standard, 16 Scanner Channels, and the 6530 TeraOhm Bridge-Meter is less than 14" in total
height.
1
This High Resistance Measurement System, along with optional adaptors and utilities, provides
National Metrology Institutes, Calibration Companies, Power Companies, Militaries and other
customers with:
Two Modes of Operation, Direct Measurement and Bridge Mode
Standard Base Resistance Measurement from 1M to 100 T!
eXpanded Resistance Measurement Range from 100 k to 20 P!
eXpanded Performance of 8 ppm for 1 M to 1 G & < 50 ppm for 10 G to 1 T!
Multi-Ratios up to 1000:1!
Test Voltages from 1 to 1000 Volts!
Optional Current Mode to measure currents from 10-5 to 10-13 Amps!
Scanner Capabilities to 1000V and 64 Channels!
Transferring the Traceability of Primary Standards from NMI's or other sources!
Automated procedures for Calibrating High Resistance Decade Boxes!
Surface and Volume Resistivity with optional test fixtures!
Simple Artifact Verification Procedure to ensure the 6530 TeraOhm Bridge-Meter
remains within operating specifications!
This automation and functionality provided by the 6535 System improves the calibration
uncertainties, range of equipment that can be supported, and the efficiency of calibration
laboratories and research facilities. The 6535 High Resistance Measurement System can either
be operated manually or in a computerized mode via the Standard IEEE-488 communication.
The included GUI based software program, TeraCalTM,
incorporates features and utilities that allow operators to
improve measurement effectiveness and provide efficiency
for data management. This includes the ability to perform
automatic data acquisition, real time graphing of results, real
time uncertainty analysis, history logging, charting, and
regression analysis. All user definable test variables, such as 6636 Rear View
resistance standard to use, excitation voltage, etc can be
programmed on a per test basis. These features give users full control and flexibility in
automating routine calibration procedures and maximizing workload capabilities.
The new Guildline 6564 High Resistance Scanner is included with the system. The number of
channels can go from 8 all the way to 64. Customers
need to evaluate the number of standard resistors
they have or plan on having and the number of free
channels they wish to use. For example if a user
bought a 6535 with the highly stable 6636
6564 Scanner Front View Temperature Stabilized Resistance Standard, up to 8
channels would be required to connect all individual resistance standards for automation. The
6564 Scanner allows for completely automated measurements up to 1000 Volts at 100 TOhms
2
with no uncertainty added to the measurement process, and up to 20 POhms with an offset that
can be calibrated out. Remember, with TeraCal Software, multiple tests can be sequenced and
grouped for the Standards to run even when operators are not present! For example a complete
set of working standards from 100 kOhms to 100 TOhms can be calibrated in a single day
without operator intervention. The 6535 is a complete system capable of fully automated
multiple-channel calibrations and measurements.
A customer has the choice of four 6530 TeraOhm Bridge-Meter models. The 6530 XP and XPR
models provide the best uncertainties of any commercially available high resistance
measurement instrument including better uncertainties than commercially available dual source
bridges. The XR and XRP models provide the widest range of resistance measurement of any
instrument. Existing Guildline 6520 Teraohmmeters can be upgraded to any of the four 6530
Models which will provide better performance and uncertainties. And at the same time a 6520
customer can upgrade to a complete 6535 System at a substantially reduced price.
Another key feature of Guildline's 6535 System is its multi-ratio functionality which supports
ratios up to 1000:1. This feature allows customers to reduce the number of resistance standards
required, and associated annual calibration costs. As well, the multi-ratio functionality will
reduce calibration uncertainties by optimizing the use of lower value resistance standards that
provide better uncertainties. This multi-ratio functionality allows customers to greatly reduce
their uncertainties when laddering up from lower value resistance standards.
Comparison of 6535 Selected Models vs MIL TeraBridge Specifications
