Image preview - the first page of the document



>> Download Panel_Mitsubishi_AA121SR01_1_[DS] documenatation <<

Text preview - extract from the document

   Global LCD Panel Exchange Center            www.panelook.com

                            Melco Display Technology, Inc.                                                       MCTLMEG 121SR01 090423


                              Brief Spec. : 12.1" SVGA(AA121SR01)
                                                 TYPE NAME                                                 AA121SR01
                                                 Screen Size / Resolution                                12.1-inch SVGA
                                                 LCD Type                                               Transmissive, TN
                                                 Active Screen Area Size [mm]                          246.0(H) x 184.5(V)
                                                 Pixel Number                                            800(H) x 600(V)
         KEY FEATURES                            Pixel Pitch [mm]                                     0.3075(H) x 0.3075(V)
  * Brightness 450cd/                            Contrast Ratio                                               600 :1
  * Response Time 16ms                           Brightness [cd/m2]                                       450(IL=6.0mA)
  * Wide Operation Temperature                   Viewing Angle (CR>10) [ o]                          -80 ~ 80(H), -60 ~ 80(V)
                                                 Optimum Viewing Angle Max. CR                               6 o'clock
      Range (-30 ~ 80oC)
                                                 Colors                                                  262K(6 bit/color)
  * Natural Color Matrix                         Response Time [msec]                                            16
  * Long lamp Life 50,000hr                      Color Saturation (vs. NTSC) [%]                                 40
    and easy replaceable lamp unit               Natural Color Matrix                                           Yes
  * Wide View Angle                              Backlight                                          CCFL, 2Lamps(Replaceable)
    80/80(R/L), 80/60(U/D)                       Lamp Life [h]                                                50,000
                                                 Interface                                                    CMOS
                                                 Power Consumption [W]                                          7.6
                                                 Power Supply [V]                                                3.3
                                                 Reverse Scan                                                  YES
                                                 Module Outline Dimensions       W                             280.0
                                                                     [mm]        H                             210.0
                                                                                 D                              12.0
                                                 Module Mass [g]                                                770
                                                 Operation Temperature Range [oC]                            -30 ~ 80
                                                 Storage Temperature Range[oC]                               -30 ~ 80
  Confidential                                                                                                                        1
                                                   www.MitsubishiElectric.co.jp/service/tft_tech/
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!                              www.panelook.com
