Image preview - the first page of the document



>> Download Panel_Mitsubishi_AA121XH03_0_[DS] documenatation <<

Text preview - extract from the document

   Global LCD Panel Exchange Center            www.panelook.com

                            Melco Display Technology, Inc.                                                        MCTLMEG 121XH03 090311


                           Brief Spec. : 12.1 " XGA Standard model
                                                 TYPE NAME                                                AA121XH03
                                                 Screen Size / Resolution                                12.1-inch XGA
                                                 LCD Type                                              Transmissive, TN
                                                 Active Screen Area Size [mm]                         245.8(H) X 184.3(V)
                                                 Pixel Number                                           1024(H) x 768(V)
         Features                                Pixel Pitch [mm]                                     0.240(H) x 0.240(V)
                                                 Contrast Ratio                                               550 :1
   Natural Color Matrix                          Brightness [cd/m2]                                      320(IL=6.0mA)
   Long lamp Life 50,000hr                       Viewing Angle (CR>10) [ o]                         -65 ~ 65(H), -75 ~ 45(V)
   and easy replaceable lamp unit                Optimum Viewing Angle Max. CR                              6 o'clock
   Wide View angle                               Colors                                        262K(6 bit/color)/16.7M (8bit /color)
                                                 Color Saturation (vs. NTSC) [%]                                40
   65/65 (R/L), 45/75 (U/D)
                                                 Natural Color Matrix                                          Yes
   Wide Operation Temperature                    Backlight                                        CCFL, 2Lamps(Replaceable)
     Range (-20 ~ 70oC)                          Lamp Life [h]                                                50,000
                                                 Interface                                                    LVDS
                                                 Power Consumption [mW]                                         7.5
                                                 Power Supply [V]                                               3.3
                                                 Reverse Scan                                                  YES
                                                 Module Outline Dimensions       W                            280.0
                                                                     [mm]        H                            210.0
                                                                                 D                             12.0
                                                 Module Mass [g]                                               720
                                                 Operation Temperature Range [oC]                            -20 ~ 70
                                                 Storage Temperature Range[oC]                               -20 ~ 80
                                                 Surface Treatment                                 Anti-glare, hard-coating 3H
  Confidential                                                                                                                          1
                                                   www.MitsubishiElectric.co.jp/service/tft_tech/
