Image preview - the first page of the document
![Panel_Mitsubishi_AA150XN08_0_[DS]](/pics/5eaff26da241a.gif)
>> Download Panel_Mitsubishi_AA150XN08_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
TENTATIVE
All information in this technical data sheet is tentative
and subject to change without notice.
15.0"XGA
TECHNICAL SPECIFICATION
AA150XN08
MITSUBISHI ELECTRIC Corp.
Date: Jul.1,'08
MITSUBISHI Confidential (1/26) AA150XN08_02_00
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
CONTENTS
No. Item Page
-- COVER 1
-- CONTENTS 2
1 APPLICATION 3
2 OVERVIEW 4
3 ABSOLUTE MAXIMUM RATINGS 5
4 ELECTRICAL CHARACTERISTICS 5, 6, 7
5 INTERFACE PIN CONNECTION 8, 9, 10
6 INTERFACE TIMING 11, 12, 13, 14, 15
7 BLOCK DIAGRAM 16
8 MECHANICAL SPECIFICATION 17, 18
9 OPTICAL CHARACTERISTICS 19, 20, 21
10 RELIABILITY TEST CONDITION 22
11 OTHER FEATURE 23
12 HANDLING PRECAUTIONS FOR TFT-LCD MODULE 24, 25, 26
MITSUBISHI Confidential (2/26) AA150XN08_02_00
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
1. APPLICATION
This specification applies to color TFT-LCD module, AA150XN08.
These specification papers are the proprietary product of Mitsubishi Electric Corporation
("MITSUBISHI) and include materials protected under copyright of MITSUBISHI. No part of this
document may be reproduced in any form or by any means without the express written permission
of MITSUBISHI.
MITSUBISHI does not assume any liability for infringement of patents, copyrights or other
intellectual property rights of third parties by or arising from use of a product specified in this
document. No license, express, implied or otherwise, is granted under any patents, copyrights or
other intellectual property rights of MITSUBISHI or of others.
MITSUBISHI classifies the usage of the TFT-LCD module as follows. Please confirm the usage
before using the product.
(1) Standard Usage
Computers, office equipment, factory automation equipment, test and measurement
equipment, communications, transportation equipment(automobiles, ships, trains, etc.),
provided, however, that operation is not influenced by TFT-LCD directly.
(2) Special Usage
Medical equipment, safety equipment, transportation equipment, provided, however, that
TFT-LCD is necessary to its operation.
(3) Specific Usage
Cockpit Equipment, military systems, aerospace equipment, nuclear reactor control systems,
life support systems and any other equipment. MITSUBISHI should make a contract that
stipulate apportionment of responsibilities between MITSUBISHI and our customer.
The product specified in this document is designed for "Standard Usage" unless otherwise specified
in this document. If customers intend to use the product for applications other than those specified
for "Standard Usage", they should first contact MITSUBISHI sales representative for it's intended
use in writing.
MITSUBISHI has been making continuous effort to improve the reliability of its products.
Customers should implement sufficient reliability design of their application equipments such as
redundant system design, fail-safe functions, anti-failure features.
MITSUBISHI assumes no responsibility for any damage resulting from the use of the product that
does not comply with the instructions and the precautions specified in this document.
Please contact and consult a MITSUBISHI sales representative for any questions regarding this
product.
MITSUBISHI Confidential (3/26) AA150XN08_02_00
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
2. OVERVIEW
AA150XN08 is 15.0" color TFT-LCD (Thin Film Transistor Liquid Crystal Display) modules
composed of LCD panel, driver ICs, control circuit, and backlight unit.
By applying 6 bit or 8 bit digital data, 1024 u 768, 262k-color or 16.7M-color images are displayed
on the 15.0" diagonal screen. Input power voltage is 3.3 V for LCD driving.
The type of data and control signals are digital and transmitted via LVDS interface per Typ. 65
MHz clock cycle.
Inverter for backlight is not included in this module. General specifications are summarized in the
following table:
ITEM SPECIFICATION
304.1 (H) u 228.1 (V)
Display Area (mm)
(15.0-inch diagonal)
Number of Dots 1024 u 3 (H) u 768 (V)
Pixel Pitch (mm) 0.297 (H) u 0.297 (V)
Color Pixel Arrangement RGB vertical stripe
Display Mode Normally white TN
Number of Color 262k(6 bit/color) 16.7M(8 bit/color)
Luminance (cd/m2) 800
Wide Viewing Angle Technology Optical Compensation Film
Viewing Angle (CR t 10) 75~75◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
