     Global LCD Panel Exchange Center                         www.panelook.com

                             Melco Display Technology, Inc.                                                               MCTLMEG - 150XT01 - 090708


                    Target Spec. : 15.0" XGA standard model (LED)
                                                 Type Name                                                        AA150XT01
                                                 Schedule                                                         MP : '09/07
               Features                          Screen Size/ Resolution                                   31cm (15.0-inch)/ XGA
                                                 Active Screen Area [mm]                                     304.1 (H) x 228.1 (V)
                                                 Number of Pixels                                             1024 (H) x 768 (V)
