Image preview - the first page of the document



>> Download Panel_Mitsubishi_AA170EB01_1_[DS] documenatation <<

Text preview - extract from the document

   Global LCD Panel Exchange Center            www.panelook.com

                            Melco Display Technology, Inc.                                                         MCTLMEG 170EB01 090806


                        Brief Spec. : 17.0-inch SXGA (AA170EB01)
                                                   TYPE NAME                                                AA170EB01
                                                   Schedule                                                 MP 09/09
                                                   Screen Size / Resolution                              17.0-inch SXGA
                                                   Active Screen Area Size [mm]                     337.920(H) 270.336(V)
                                                   Pixel Number                                         1280(H) x 1024(V)
                                                   Pixel Pitch [mm]                                    0.264(H) x 0.264(V)
         KEY FEATURES                              Contrast Ratio                                              800 :1
   Natural Color Matrix                            Brightness [cd/m2]                                            550
   High Color Saturation 72%                       Viewing Angle (CR>10) [ o]                       -80 ~ 80(H), -60 ~ 80(V)
                                                   Optimum Viewing Angle Max. CR                              6 o'clock
   4-tubes, edge-light
                                                   Colors                                       262K(6 bit/color)/16.7M (8bit /color)
   Long lamp Life 50,000hr                         Color Saturation (vs. NTSC) [%]                                72
   Replaceable backlight lamp unit                 Natural Color Matrix                                          Yes
   Reverse scan function                           Backlight                                     CCFL, U/D 4Lamps(Replaceable)
   RoHS compliance                                 Lamp Life [h]                                               50,000
                                                   Interface                                                 2ch LVDS
                                                   Power Consumption [mW]                                        18.7
                                                   Power Supply [V]                                            3.3/5.0
                                                   Reverse Scan                                                 YES
                                                   Module Outline                 W                             358.5
                                                   Dimensions                     H                             296.5
                                                                      [mm]        D                              16.9
                                                   Module Mass [g]                                              1840
                                                   Operation Temperature Range [oC]                           -20 ~ 70
                                                   Storage Temperature Range[oC]                              -20 ~ 80
                                                   Surface Treatment                              Anti-glare and hard-coating 3H
  Confidential                                                                                                                          1
                                                   www.MitsubishiElectric.co.jp/service/tft_tech/
