Image preview - the first page of the document
![Panel_Mitsubishi_AA192AA01_1_[DS]](/pics/5eaff5c02f04a.gif)
>> Download Panel_Mitsubishi_AA192AA01_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
TENTATIVE
All information in this technical data sheet is tentative
and subject to change without notice.
Preliminary
19.2" 1920u360
TECHNICAL SPECIFICATION
AA192AA01
MITSUBISHI ELECTRIC Corp.
Date: Jan.8,'10
MITSUBISHI Confidential (1/24) AA192AA01_02_00
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
CONTENTS
No. Item Page
-- COVER 1
-- CONTENTS 2
1 APPLICATION 3
2 OVERVIEW 4
3 ABSOLUTE MAXIMUM RATINGS 5
4 ELECTRICAL CHARACTERISTICS 5, 6
5 INTERFACE PIN CONNECTION 7, 8
6 INTERFACE TIMING 9, 10, 11, 12, 13
7 BLOCK DIAGRAM 14
8 MECHANICAL SPECIFICATION 15, 16
9 OPTICAL CHARACTERISTICS 17, 18, 19
10 RELIABILITY TEST CONDITION 20
11 OTHER FEATURE 21
12 HANDLING PRECAUTIONS FOR TFT-LCD MODULE 22, 23, 24
MITSUBISHI Confidential (2/24) AA192AA01_02_00
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
1. APPLICATION
This specification applies to color TFT-LCD module, AA192AA01.
These specification papers are the proprietary product of Mitsubishi Electric Corporation
("MITSUBISHI) and include materials protected under copyright of MITSUBISHI. No part of this
document may be reproduced in any form or by any means without the express written permission
of MITSUBISHI.
MITSUBISHI does not assume any liability for infringement of patents, copyrights or other
intellectual property rights of third parties by or arising from use of a product specified in this
document. No license, express, implied or otherwise, is granted under any patents, copyrights or
other intellectual property rights of MITSUBISHI or of others.
MITSUBISHI classifies the usage of the TFT-LCD module as follows. Please confirm the usage
before using the product.
(1) Standard Usage
Computers, office equipment, factory automation equipment, test and measurement
equipment, communications, transportation equipment(automobiles, ships, trains, etc.),
provided, however, that operation is not influenced by TFT-LCD directly.
(2) Special Usage
Medical equipment, safety equipment, transportation equipment, provided, however, that
TFT-LCD is necessary to its operation.
(3) Specific Usage
Cockpit Equipment, military systems, aerospace equipment, nuclear reactor control
systems, life support systems and any other equipment. MITSUBISHI should make a
contract that stipulate apportionment of responsibilities between MITSUBISHI and our
customer.
The product specified in this document is designed for "Standard Usage" unless otherwise specified
in this document. If customers intend to use the product for applications other than those specified
for "Standard Usage", they should first contact MITSUBISHI sales representative for it's intended
use in writing.
MITSUBISHI has been making continuous effort to improve the reliability of its products.
Customers should implement sufficient reliability design of their application equipments such as
redundant system design, fail-safe functions, anti-failure features.
MITSUBISHI assumes no responsibility for any damage resulting from the use of the product that
does not comply with the instructions and the precautions specified in this document.
Please contact and consult a MITSUBISHI sales representative for any questions regarding this
product.
MITSUBISHI Confidential (3/24) AA192AA01_02_00
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
2. OVERVIEW
AA192AA01 is 19.2" color TFT-LCD (Thin Film Transistor Liquid Crystal Display) module
composed of LCD panel, driver ICs, control circuit, and backlight unit.
By applying 6 bit or 8 bit digital data, 1920 u 360, 262k-color or 16.7M-color images are displayed
on the 19.2" diagonal screen. Input power voltage is single 3.3 V for LCD driving.
The type of data and control signals are digital and transmitted via LVDS interface per Typ. 60
MHz clock cycle.
Driver circuit for LED backlight is not included in this module. General specifications are
summarized in the following table:
ITEM SPECIFICATION
478.08(H) u 89.64(V)
Display Area (mm)
(19.2-inch diagonal)
Number of Dots 1920 u 3 (H) u 360 (V)
Pixel Pitch (mm) 0.249 (H) u 0.249 (V)
Color Pixel Arrangement RGB vertical stripe
Display Mode Normally white TN
Number of Color 262k(6 bit/color), 16.7M(8 bit/color)
Luminance (cd/m2) 500
Wide Viewing Angle Technology Optical Compensation Film
Viewing Angle (CR t 10) 80~80◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
