Image preview - the first page of the document
![Panel_OPTREX_T-55699D190J-LW-A-AAN_0_[DS]](/pics/5eaffe4799f3a.gif)
>> Download Panel_OPTREX_T-55699D190J-LW-A-AAN_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
TENTATIVE
All information in this technical data sheet is tentative
and subject to change without notice.
Preliminary
19.0"SXGA
TECHNICAL SPECIFICATION
T-55699D190J-LW-A-AAN
OPTREX CORPORATION
Date: Aug.3,'11
OPTREX Confidential (1/27) T-55699D190J-LW-A-AAN
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
CONTENTS
No. Item Page
-- COVER 1
-- CONTENTS 2
1 APPLICATION 3
2 OVERVIEW 4
3 ABSOLUTE MAXIMUM RATINGS 5
4 ELECTRICAL CHARACTERISTICS 5, 6, 7
5 INTERFACE PIN CONNECTION 8, 9, 10, 11
6 INTERFACE TIMING 12, 13, 14, 15, 16
7 BLOCK DIAGRAM 17
8 MECHANICAL SPECIFICATION 18, 19
9 OPTICAL CHARACTERISTICS 20, 21, 22
10 RELIABILITY TEST CONDITION 23
11 OTHER FEATURE 24
12 HANDLING PRECAUTIONS FOR TFT-LCD MODULE 25, 26, 27
OPTREX Confidential (2/27) T-55699D190J-LW-A-AAN
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
1. APPLICATION
This specification applies to color TFT-LCD module, T-55699D190J-LW-A-AAN.
These specification papers are the proprietary product of OPTREX CORPORATION ("OPTREX ) and
include materials protected under copyright of OPTREX . No part of this document may be
reproduced in any form or by any means without the express written permission of OPTREX .
OPTREX does not assume any liability for infringement of patents, copyrights or other intellectual
property rights of third parties by or arising from use of a product specified in this document. No
license, express, implied or otherwise, is granted under any patents, copyrights or other intellectual
property rights of OPTREX or of others.
OPTREX classifies the usage of the TFT-LCD module as follows. Please confirm the usage before
using the product.
(1) Standard Usage
Computers, office equipment, factory automation equipment, test and measurement
equipment, communications, transportation equipment(automobiles, ships, trains, etc.),
provided, however, that operation is not influenced by TFT-LCD directly.
(2) Special Usage
Medical equipment, safety equipment, transportation equipment, provided, however, that
TFT-LCD is necessary to its operation.
(3) Specific Usage
Cockpit Equipment, military systems, aerospace equipment, nuclear reactor control systems,
life support systems and any other equipment. OPTREX should make a contract that
stipulate apportionment of responsibilities between OPTREX and our customer.
The product specified in this document is designed for "Standard Usage" unless otherwise specified
in this document. If customers intend to use the product for applications other than those specified
for "Standard Usage", they should first contact OPTREX sales representative for it's intended use
in writing.
OPTREX has been making continuous effort to improve the reliability of its products. Customers
should implement sufficient reliability design of their application equipments such as redundant
system design, fail-safe functions, anti-failure features.
OPTREX assumes no responsibility for any damage resulting from the use of the product that does
not comply with the instructions and the precautions specified in this document.
Please contact and consult a OPTREX sales representative for any questions regarding this product.
OPTREX Confidential (3/27) T-55699D190J-LW-A-AAN
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
2. OVERVIEW
T-55699D190J-LW-A-AAN is 19.0" color TFT-LCD (Thin Film Transistor Liquid Crystal Display)
modules composed of LCD panel, driver ICs, control circuit, and backlight unit.
By applying 6 bit or 8 bit digital data, 1280 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
