Image preview - the first page of the document
![Panel_AUO_B133XW04_V2_CELL_0_[DS]](/pics/5c36ad30eb474.gif)
>> Download Panel_AUO_B133XW04_V2_CELL_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
( V ) Preliminary Specifications
( ) Final Specifications
Module 13.3"(13.25") HD 16:9 Color TFT-LCD Open Cell
Model Name B133XW04 V2 (H/W: 0A)
Customer Date Approved by Date
Checked &
Date Prepared by
Approved by
Kay CY Wang 10/29/2010
Note: This Specification is subject to change NBBU Marketing Division
without notice. AU Optronics corporation
B133XW04 V2 Document Version : 0.1 1 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Contents
+DQGOLQJ 3UHFDXWLRQV
*HQHUDO 'HVFULSWLRQ
2.1 General Specification.......................................................................................................................... 5
)XQFWLRQDO %ORFN 'LDJUDP
$EVROXWH 0D[LPXP 5DWLQJV
4.1 Absolute Ratings of TFT LCD............................................................................................................ 7
(OHFWULFDO &KDUDFWHULVWLFV
5.1 TFT LCD ............................................................................................................................................ 8
6LJQDO ,QWHUIDFH &KDUDFWHULVWLF
6.1 Pixel Format Image........................................................................................................................... 10
6.2 The Input Data Format...................................................................................................................... 11
6.3 Integration Interface Requirement .................................................................................................... 12
6.4 Interface Timing................................................................................................................................ 14
0HFKDQLFDO &KDUDFWHULVWLFV
7.1 LCD Outline Dimension................................................................................................................... 16
7.3 Shipping Package of Palletizing Sequence....................................................................................... 18
$SSHQGL[ (',' 'HVFULSWLRQ
B133XW04 V2 Document Version : 0.1 2 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2010/10/29 All First Edition for Customer
B133XW04 V2 Document Version : 0.1 3 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or
spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard
surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human
earth when handling.
7) Do not open nor modify the product.
8) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor
tilt the Interface Connector of the TFT LCD.
9) After installation of the TFT Module into an enclosure (Notebook PC Bezel, for
example), do not twist nor bend the TFT Module even momentary. At designing the
enclosure, it should be taken into consideration that no bending/twisting forces are
applied to the TFT Module from outside. Otherwise the TFT Module may be damaged.
10) Small amount of materials having no flammability grade is used in the LCD module.
The LCD module should be supplied by power complied with requirements of Limited
Power Source (IEC60950 or UL1950), or be applied exemption.
11) Disconnecting power supply before handling LCD modules, it can prevent electric shock, DO NOT TOUCH the electrode parts,
cables, connectors and LED circuit part of TFT module that a LED light bar build in as a light source of back light unit. It can prevent
electrostic breakdown.
B133XW04 V2 Document Version : 0.1 4 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
2. General Description
B133XW01 V4 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD panel, a
driver circuit, and LED backlight system. The screen format is intended to support the 16:9 HD,
1366(H) x768(V) screen and 262k colors (RGB 6-bits data driver) with LED backlight driving
circuit. All input signals are LVDS interface compatible.
B133XW01 V4 is designed for a display unit of notebook style personal computer and industrial
machine.
2.1 General Specification
The following items are characteristics summary on the table at 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 13.3W"(13.25)
Active Area [mm] 293.42 x 164.97
Pixels H x V 1366 x 3(RGB) x 768
Pixel Pitch [mm] 0.2148 x 0.2148
Pixel Format R.G.B. Vertical Stripe
Display Mode Normally White
Response Time [ms] 8 typ / 16 Max
Nominal Input Voltage VDD [Volt] +3.3 typ.
Weight [Grams] 175 max.
Physical Size Min. Typ. Max.
Length --- --- 302.927
[mm]
Width --- --- 216.866
Thickness --- --- 1.4
Electrical Interface 1 channel LVDS
Glass Thickness [mm] 0.5
Surface Treatment Glare, Hardness 3H
Support Color 262K colors ( RGB 6-bit )
RoHS Compliance RoHS Compliance
B133XW04 V2 Document Version : 0.1 5 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
3. Functional Block Diagram
The following diagram shows the functional block of the 13.3 inches wide Color TFT/LCD 40 Pin one channel
Module
B133XW04 V2 Document Version : 0.1 6 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
4. Absolute Maximum Ratings
An absolute maximum rating of the module is as following:
4.1 Absolute Ratings of TFT LCD
Item Symbol Min Max Unit Conditions
Logic/LCD Drive Voltage Vin -0.3 +4.0 [Volt] Note 1,2
Note 1: At Ta (25 )
Note 2: Permanent damage to the device may occur if exceed maximum values
B133XW04 V2 Document Version : 0.1 7 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
5. Electrical Characteristics
5.1 TFT LCD
5.1.1 Power Specification
Input power specifications are as follows;
The power specification are measured under 25 and frame frenquency under 60Hz
Symble Parameter Min Typ Max Units Note
VDD Logic/LCD Drive [Volt]
3.0 3.3 3.6
Voltage
PDD VDD Power - - 1.0 [Watt] Note 1
IDD IDD Current - - 300 [mA] Note 1
IRush Inrush Current - - 2000 [mA] Note 2
VDDrp Allowable [mV]
Logic/LCD Drive - - 100 p-p
Ripple Voltage
Note 1 : Maximum Measurement Condition Black Pattern at 3.3V driving voltage. (Pmax=V3.3 x Iblack)
Note 2 Measure Condition
90% 3.3V
10%
0V
0.5ms
Vin rising time
B133XW04 V2 Document Version : 0.1 8 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
5.1.2 Signal Electrical Characteristics
Input signals shall be low or High-impedance state when VDD is off.
Signal electrical characteristics are as follows;
Parameter Condition Min Max Unit
VTH Differential Input High
Threshold (Vcm=+1.2V) --- 100 [mV]
VTL Differential Input Low
Threshold (Vcm=+1.2V) -100 --- [mV]
|VID| Differential Input
Voltage 100 600 [mV]
Differential Input
VCM Common Mode Voltage
1.125 1.375 [V]
Note: LVDS Signal Wavefor
B133XW04 V2 Document Version : 0.1 9 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
6. Signal Interface Characteristic
6.1 Pixel Format Image
Following figure shows the relationship of the input signals and LCD pixel format.
B133XW01 V4 Document Version : 0.1 10 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
6.2 The Input Data Format
Signal Name Description
R5 Red Data 5 (MSB) Red-pixel Data
R4 Red Data 4 Each red pixel's brightness data consists of
R3 Red Data 3 these 6 bits pixel data.
R2 Red Data 2
R1 Red Data 1
R0 Red Data 0 (LSB)
Red-pixel Data
G5 Green Data 5 (MSB) Green-pixel Data
G4 Green Data 4 Each green pixel's brightness data consists of
G3 Green Data 3 these 6 bits pixel data.
G2 Green Data 2
G1 Green Data 1
G0 Green Data 0 (LSB)
Green-pixel Data
B5 Blue Data 5 (MSB) Blue-pixel Data
B4 Blue Data 4 Each blue pixel's brightness data consists of
B3 Blue Data 3 these 6 bits pixel data.
B2 Blue Data 2
B1 Blue Data 1
B0 Blue Data 0 (LSB)
Blue-pixel Data
RxCLKIN Data Clock The signal is used to strobe the pixel data and
DE signals. All pixel data shall be valid at the
falling edge when the DE signal is high.
DE Display Timing This signal is strobed at the falling edge of
RxCLKIN. When the signal is high, the pixel
data shall be valid to be displayed.
VS Vertical Sync The signal is synchronized to RxCLKIN .
HS Horizontal Sync The signal is synchronized to RxCLKIN .
Note: Output signals from any system shall be low or High-impedance state when VDD is off.
B133XW01 V4 Document Version : 0.1 11 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
6.3 Integration Interface Requirement
6.3.1 Connector Description
Physical interface is described as for the connector on module.
These connectors are capable of accommodating the following signals and will be following
components.
Connector Name / Designation For Signal Connector
Manufacturer IPEX or Compatible
Type / Part Number IPEX 20455-040E-12R or Compatible
Mating Housing/Part Number IPEX 20453-040T-01 or Compatible
6.3.2 Pin Assignment
LVDS is a differential signal technology for LCD interface and high speed data transfer device.
PIN# Signal Name Description
1 NC No Connection (Reserve)
2 VDD Power Supply +3.3V
3 VDD Power Supply +3.3V
4 VEDID EDID +3.3V Power
5 NC No Connect (Reserve)
6 CLK_EDID EDID Clock Input
7 DAT_EDID EDID Data Input
8 RxOIN0- -LVDS Differential Data INPUT(Odd R0-R5,G0)
9 RxOIN0+ +LVDS Differential Data INPUT(Odd R0-R5,G0)
10 VSS Ground
11 RxOIN1- -LVDS Differential Data INPUT(Odd G1-G5,B0-B1)
12 RxOIN1+ +LVDS Differential Data INPUT(Odd G1-G5,B0-B1)
13 VSS Ground
14 RxOIN2- -LVDS Differential Data INPUT(Odd B2-B5,HS,VS,DE)
15 RxOIN2+ +LVDS Differential Data INPUT(Odd B2-B5,HS,VS,DE)
16 VSS Ground
17 RxOCKIN- -LVDS Odd Differential Clock INPUT
18 RxOCKIN+ -LVDS Odd Differential Clock INPUT
19 IMG_EN Color Management Input Level
20 NC No connection
21 NC No connection
22 NC No connection
B133XW01 V4 Document Version : 0.1 12 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
23 NC No connection
24 NC No connection
25 NC No connection
26 NC No connection
27 NC No connection
28 NC No connection
29 NC No connection
30 NC No connection
31 VLED_GND LED Ground
32 VLED_GND LED Ground
33 VLED_GND LED Ground
34 NC No Connection (Reserve)
35 VPWM_EN PWM logic input level
36 VLED_EN LED enable input level
37 DCR_EN Dynamic Contrast Ratio Input Level
38 VLED LED Power Supply 6V-21V
39 VLED LED Power Supply 6V-21V
40 VLED LED Power Supply 6V-21V
Connector
Pin 40 Pin 1
VLED
NC
Note1: Input signals shall be low or High-impedance state when VDD is off.
B133XW01 V4 Document Version : 0.1 13 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Note1: Input signals shall be low or High-impedance state when VDD is off.
6.4 Interface Timing
6.4.1 Timing Characteristics
Basically, interface timings should match the 1366x768 /60Hz manufacturing guide line timing.
Parameter Symbol Min. Typ. Max. Unit
Frame Rate - --- 60 --- Hz
Clock frequency 1/ TClock 65 69.3 80 MHz
Period TV 776 793 1000
Vertical
Active TVD 768 TLine
Section
Blanking TVB 8 25 232
Period TH 1426 1456 2000
Horizontal
Active THD 1366 TClock
Section
Blanking THB 60 90 634
Note : DE mode only
6.4.2 Timing diagram
TCLOCK Input Timing Definition ( DE Mode)
DOTCLK
Input Invaild Pixel Pixel Pixel Pixel Pixel Invaild Pixel
Data Data 1 2 3 N-1 N Data 1
DE
THB THD
TH
DE
TVB
TVD
TV
B133XW01 V4 Document Version : 0.1 14 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
6.5 Power ON/OFF Sequence
Power on/off sequence is as follows. Interface signals and LED on/off sequence are also shown
in the chart. Signals from any system shall be Hi-Z state or low level when VDD is off
Power Sequence Timing
Value
Parameter Min. Max. Units
T1 0.5 10
T2 0 50
T3 200 -
T4 200 -
T5 0 50
T6 0 10
ms
T7 500 -
T8 10 -
T9 10 180
T10 10 180
T11 10 -
T12 0.5 10
B133XW01 V4 Document Version : 0.1 15 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
7. Mechanical Characteristics
7.1 LCD Outline Dimension
7.1.1 Standard Front View
B133XW01 V4 Document Version : 0.1 16 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
7.1.2 Standard Rear View
B133XW01 V4 Document Version : 0.1 17 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
7.2 Carton Package
7.3 Shipping Package of Palletizing Sequence
B133XW01 V4 Document Version : 0.1 18 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
8. Appendix: EDID Description
Address FUNCTION Value Value Value Note
HEX HEX BIN DEC
00 Header 00 00000000 0
01 FF 11111111 255
02 FF 11111111 255
03 FF 11111111 255
04 FF 11111111 255
05 FF 11111111 255
06 FF 11111111 255
07 00 00000000 0
08 EISA Manuf. Code LSB 06 00000110 6
09 Compressed ASCII AF 10101111 175
0A 2C 00101100 44
0B 42 01000010 66
0C 32-bit ser # 00 00000000 0
0D 00 00000000 0
0E 00 00000000 0
0F 00 00000000 0
10 Week of manufacture 00 00000000 0
11 Year of manufacture 14 00010100 20
12 EDID Structure Ver. 01 00000001 1
13 EDID revision # 03 00000011 3
14 Video input def. (digital I/P, non-TMDS, CRGB) 80 10000000 128
15 Max H image size (rounded to cm) 1D 00011101 29
16 Max V image size (rounded to cm) 10 00010000 16
17 Display Gamma (=(gamma*100)-100) 78 01111000 120
Feature support (no DPMS, Active OFF, RGB,
18 tmg Blk#1) 0A 00001010 10
19 Red/green low bits (Lower 2:2:2:2 bits) 13 00010011 19
1A Blue/white low bits (Lower 2:2:2:2 bits) 15 00010101 21
1B Red x (Upper 8 bits) A0 10100000 160
1C Red y/ highER 8 bits 58 01011000 88
1D Green x 52 01010010 82
1E Green y 90 10010000 144
1F Blue x 25 00100101 37
20 Blue y 0F 00001111 15
21 White x 50 01010000 80
22 White y 54 01010100 84
23 Established timing 1 00 00000000 0
24 Established timing 2 00 00000000 0
25 Established timing 3 00 00000000 0
B133XW01 V4 Document Version : 0.1 19 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
26 Standard timing #1 01 00000001 1
27 01 00000001 1
28 Standard timing #2 01 00000001 1
29 01 00000001 1
2A Standard timing #3 01 00000001 1
2B 01 00000001 1
2C Standard timing #4 01 00000001 1
2D 01 00000001 1
2E Standard timing #5 01 00000001 1
2F 01 00000001 1
30 Standard timing #6 01 00000001 1
31 01 00000001 1
32 Standard timing #7 01 00000001 1
33 01 00000001 1
34 Standard timing #8 01 00000001 1
35 01 00000001 1
36 Pixel Clock/10000 LSB 12 00010010 18
37 Pixel Clock/10000 USB 1B 00011011 27
38 Horz active Lower 8bits 56 01010110 86
39 Horz blanking Lower 8bits 5A 01011010 90
3A HorzAct:HorzBlnk Upper 4:4 bits 50 01010000 80
3B Vertical Active Lower 8bits 00 00000000 0
3C Vertical Blanking Lower 8bits 19 00011001 25
3D Vert Act : Vertical Blanking (upper 4:4 bit) 30 00110000 48
3E HorzSync. Offset 30 00110000 48
3F HorzSync.Width 20 00100000 32
40 VertSync.Offset : VertSync.Width 36 00110110 54
41 Horz&Vert Sync Offset/Width Upper 2bits 00 00000000 0
42 Horizontal Image Size Lower 8bits 25 00100101 37
43 Vertical Image Size Lower 8bits A4 10100100 164
44 Horizontal & Vertical Image Size (upper 4:4 bits) 10 00010000 16
45 Horizontal Border (zero for internal LCD) 00 00000000 0
46 Vertical Border (zero for internal LCD) 00 00000000 0
47 Signal (non-intr, norm, no stero, sep sync, neg pol) 18 00011000 24
48 Detailed timing/monitor 00 00000000 0
49 descriptor #2 00 00000000 0
4A 00 00000000 0
4B 0F 00001111 15
4C 00 00000000 0
4D 00 00000000 0
4E 00 00000000 0
4F 00 00000000 0
50 00 00000000 0
B133XW01 V4 Document Version : 0.1 20 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
51 00 00000000 0
52 00 00000000 0
53 00 00000000 0
54 00 00000000 0
55 00 00000000 0
56 00 00000000 0
57 00 00000000 0
58 00 00000000 0
59 20 00100000 32
5A Detailed timing/monitor 00 00000000 0
5B descriptor #3 00 00000000 0
5C 00 00000000 0
5D FE 11111110 254
5E 00 00000000 0
5F Manufacture 41 01000001 65 A
60 Manufacture 55 01010101 85 U
61 Manufacture 4F 01001111 79 O
62 0A 00001010 10
63 20 00100000 32
64 20 00100000 32
65 20 00100000 32
66 20 00100000 32
67 20 00100000 32
68 20 00100000 32
69 20 00100000 32
6A 20 00100000 32
6B 20 00100000 32
6C Detailed timing/monitor 00 00000000 0
6D descriptor #4 00 00000000 0
6E 00 00000000 0
6F FE 11111110 254
70 00 00000000 0
71 Manufacture P/N 42 01000010 66 B
72 Manufacture P/N 31 00110001 49 1
73 Manufacture P/N 33 00110011 51 3
74 Manufacture P/N 33 00110011 51 3
75 Manufacture P/N 58 01011000 88 X
76 Manufacture P/N 57 01010111 87 W
77 Manufacture P/N 30 00110000 48 0
78 Manufacture P/N 34 00110100 52 4
79 Manufacture P/N 20 00100000 32
7A Manufacture P/N 56 01010110 86 V
7B Manufacture P/N 32 00110010 50 2
B133XW01 V4 Document Version : 0.1 21 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
7C 20 00100000 32
7D 0A 00001010 10
7E Extension Flag 00 00000000 0
7F Checksum CD 11001101 205
B133XW01 V4 Document Version : 0.1 22 of 22
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
