Image preview - the first page of the document
![Panel_AUO_B160HW02_V0_1_[DS]](/pics/5c36aba0e8989.gif)
>> Download Panel_AUO_B160HW02_V0_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
( ) Preliminary Specifications
( V ) Final Specifications
Module 16" FHD 16:9 Color TFT-LCD
with LED Backlight design
Model Name B160HW02 V0 (HW Code: 1A)
Customer Date Approved by Date
Kuei Sheng Tseng 2010/6/30
Checked &
Date Prepared by Date
Approved by
Michael WJ Sun 2010/6/30
Note: This Specification is subject to change NBBU Marketing Division
without notice. AU Optronics corporation
B160HW02 V0 Document Version : 1.2 1 of 41
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Contents
1. Handling Precautions............................................................... 5
2. General Description ................................................................. 6
2.1 General Specification ......................................................................................................................6
2.2 Optical Characteristics ....................................................................................................................7
3. Functional Block Diagram ...................................................... 12
4. Absolute Maximum Ratings.................................................... 13
4.1 Absolute Ratings of TFT LCD Module..........................................................................................13
4.2 Absolute Ratings of Environment ..................................................................................................13
5. Electrical Characteristics........................................................ 14
5.1 TFT LCD Module.........................................................................................................................14
5.2 Backlight Unit...............................................................................................................................17
6. Signal Interface Characteristic .............................................. 19
6.1 Pixel Format Image.......................................................................................................................19
6.2 Integration Interface Requirement .................................................................................................21
6.3 Interface Timing............................................................................................................................23
6.4 Power ON/OFF Sequence.............................................................................................................27
7. Panel Reliability Test ............................................................. 29
7.1 Vibration Test ...............................................................................................................................29
7.2 Shock Test ....................................................................................................................................29
7.3 Reliability Test ..............................................................................................................................29
8. Mechanical Characteristics..................................................... 30
8.1 LCM Outline Dimension ...............................................................................................................30
9. Shipping and Package............................................................ 32
9.1 Shipping Label Format ..................................................................................................................33
9.2 Carton Package.............................................................................................................................34
9.3 Shipping Package of Palletizing Sequence .....................................................................................35
10. Appendix ............................................................................. 36
10.1 EDID Description .......................................................................................................................36
B160HW02 V0 Document Version : 1.2 2 of 41
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2010/09/07 All First Edition for Customer
2
0.2 2010/11/01 5 White Luminance 2D animation/3D : 224 cd/m typ
2
230 cd/m typ
Luminance Uniformity 2D 50% typ
animation/3D : 65% typ
Power Consumption : 18.8 / 24.9 Please refer to 5.1.1 and 5.2.1
Watt max (Include Logic and BLU
power)
Module thickness : 8.5mm Module thickness : 8.95mm
Weight : 632g typ 638g typ
6 Surface Treatment : Glare Surface Treatment : Anti-Glare
Revise 2.2 Optical Characteristics Please refer to revised version
11 Update absolute ratings of TFT LCD VDD5 : -0.3~+6.5V
module Vin : -0.3~(VDD33+0.3)V
VDD5, Vin, VLED , I LED VLED : -0.3~22V
I LED : 0~30mA
Update absolute ratings of
environment: Operating Temperature : Operating Temperature : 0~50
0~50
12 Update power specification of IDD33, Please refer to p12
IDD5 and delete inrush current and
VDD ripple
15,16 Update LED characteristics and Please refer to p15~p16
backlight input signal characteristics
24,25 Update 6.5 Power ON/OFF Please refer to p24~25
Sequence
27,28 Update module appearance Please refer to p27~p28
33 Update EDID description Please refer to p33~p38
1.0 2011/1/17 All Final the spec
8 none
Note 2: Luminance measure point
9 Note 7: Definition of response time Please refer to p9
13 Update current of the Input power Please refer to p13
15 VHPD :2.25(min); 3.6(max) VHPD :1.9(min); 2.7(max)
21~2 Timing Characteristics Please refer to p21~p23
3
B160HW02 V0 Document Version : 1.2 3 of 41
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
27 Vibration: 10~500Hz Vibration: 5~500Hz
Shock: 220G, 2ms Shock: 210G, 3ms
30 Update pictures Please refer to p30
1.1 2011/2/17 7 Add light distribution Please refer to p7
16 Update the description of the Note1 Please refer to p16
and Note2
23 Update 3D timing Please refer to p23
27 Add the test and condition of the Please refer to p27
High Temperature and High Humidity
Storage
1.2 2011/6/29 6 Weight : 638g typ 648g typ ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
