Image preview - the first page of the document
![Panel_AUO_G150XG03_V1_0_[DS]](/pics/5c36abfe61575.gif)
>> Download Panel_AUO_G150XG03_V1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
G150XG03 V1
( ) Preliminary Specifications
(V ) Final Specifications
Module 15 Inch Color TFT-LCD
Model Name G150XG03 V1
Customer Date Approved by Date
Peter ML Lee 2006/11/23
Checked &
Prepared by
Approved by
Daniel Chi 2006/11/23
Note: This Specification is subject to change General Display Business Division /
without notice. AU Optronics corporation
G150XG03 V1 rev. 0.5
1/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG03 V1
Contents
1. Operating Precautions......................................................................................... 4
2. General Description ............................................................................................. 5
2.1 Display Characteristics ......................................................................................................5
2.2 Optical Characteristics .......................................................................................................6
3. Functional Block Diagram................................................................................... 9
4. Absolute Maximum Ratings .............................................................................. 10
4.1 Absolute Ratings of TFT LCD Module..............................................................................10
4.2 Absolute Ratings of Environment .....................................................................................10
5. Electrical Characteristics .................................................................................. 11
5.1 TFT LCD Module.............................................................................................................. 11
5.2 Backlight Unit ...................................................................................................................13
6. Signal Characteristic ......................................................................................... 14
6.1 Pixel Format Image ..........................................................................................................14
6.2 Signal Description ............................................................................................................15
6.3 The Input Data Format .....................................................................................................16
6.4 Interface Timing................................................................................................................17
6.5 Power ON/OFF Sequence ...............................................................................................18
7. Connector & Pin Assignment ........................................................................... 19
7.1 TFT LCD Module: LVDS Connector .................................................................................19
7.2 Backlight Unit: Lamp Connector.......................................................................................21
7.3 Lamp Connector Pin Assignment .....................................................................................21
8. Reliability Test Criteria ...................................................................................... 22
9. Mechanical Characteristics............................................................................... 23
9.1 LCM Front View and Rear View .......................................................................................23
9.2 LCM Outline Dimension (Front View)...............................................................................24
9.3 LCM Outline Dimension (Rear View) ...............................................................................25
10. Label and Packaging........................................................................................ 26
10.1 Shipping Label (on the rear side of TFT-LCD display)...................................................26
10.2 Carton Package .............................................................................................................26
11 Safety.................................................................................................................. 27
11.1 Sharp Edge Requirements .............................................................................................27
11.2 Materials.........................................................................................................................27
11.3 Capacitors ......................................................................................................................27
11.4 National Test Lab Requirement ......................................................................................27
G150XG03 V1 rev. 0.5
2/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG03 V1
Record of Revision
Version and Date Page Old description New Description
0.0 2006/06/30 All First Edition
0.1 2006/07/04 28, 29, Old plot New plot
30
0.2 2006/08/04 26 Shipping Label Revised shipping label
0.3 2006/08/18 26 Carton Package Modify Carton Package
28, Mechanical Characteristics Update clear plots
29,
30
0.4 2006/08/30 6 Power consumption: 10.7 W 11.4 W
15 VCFL: 590 V VCFL: 650 V
Lamp power: 7.1W Lamp power: 7.8W
0.5 2006/11/23 9 Update functional diagram
12 Re-plot LVDS Signal Waveform
13 IRCFL Max: 7 IRCFL Max: 6
13 Lamp life Typ: 60,000 Lamp life Typ: 50,000
16 Add signal description table
17 Re-plot Timing diagram
21 Lamp connector pin assignment :
Add cable color.
G150XG03 V1 rev. 0.5
3/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG03 V1
1. Operating Precautions
1) Since front polarizer is easily damaged, please be cautious and not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or
spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or soft cloth.
5) Since the panel is made of glass, it may be broken or cracked if dropped or bumped on
hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human
earth when handling.
7) Do not open nor modify the module assembly.
8) Do not press the reflector sheet at the back of the module to any direction.
9) In case if a module has to be put back into the packing container slot after it was taken
out from the container, do not press the center of the CCFL Reflector edge. Instead,
press at the far ends of the CFL Reflector edge softly. Otherwise the TFT Module may
be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor
tilt the Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure (Notebook PC Bezel, for
example), do not twist nor bend the TFT Module even momentary. At designing the
enclosure, it should be taken into consideration that no bending/twisting forces are
applied to the TFT Module from outside. Otherwise the TFT Module may be damaged.
12) Cold cathode fluorescent lamp in LCD contains a small amount of mercury. Please follow
local ordinances or regulations for disposal.
13) Small amount of materials having no flammability grade is used in the LCD module. The
LCD module should be supplied by power complied with requirements of Limited Power
Source (IEC60950 or UL1950), or be applied exemption.
14) The LCD module is designed so that the CFL in it is supplied by Limited Current Circuit
(IEC60950 or UL1950). Do not connect the CFL in Hazardous Voltage Circuit.
15) Severe temperature condition may result in different luminance, response time and lamp
ignition voltage.
16) Continuous operating TFT-LCD display under low temperature environment may accelerate
lamp exhaustion and reduce luminance dramatically.
17) The data on this specification sheet is applicable when LCD module is placed in landscape
position.
18) Continuous displaying fixed pattern may induce image sticking. It 's recommended to use
screen saver or shuffle content periodically if fixed pattern is displayed on the screen.
G150XG03 V1 rev. 0.5
4/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG03 V1
2. General Description
G150XG03 V1 is a Color Active Matrix Liquid Crystal Display composed of a TFT-LCD display, a
driver circuit, and a backlight system. The screen format is intended to support XGA (1024(H) x
768(V)) screen and 16.2M (RGB 8-bits) or 262k colors (RGB 6-bits). All input signals are LVDS
interface compatible. Inverter card of backlight is not included. All design rules of this
module can correspond to PSWG standard.
G150XG03 V1 is designed for industrial display applications.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
Items Unit Specifications
Screen Diagonal [inch] 15
Active Area [mm] 304.128(H) x 228.096(V)
Pixels H x V 1024x3(RGB) x 768
Pixel Pitch [mm] 0.297 x 0.297
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode TN, Normally White
Nominal Input Voltage VDD [Volt] 3.3 typ.
Typical Power Consumption [Watt] 11.4W (Typ.) @ 6.0mA (Gray Bar Pattern)
Weight [Grams] 1150g (typ.)
Physical Size [mm] 326.5(H)x 253.5(V) x 12.0(D) (typ.)
Electrical Interface 1 channel LVDS
Surface Treatment Anti-glare, Hardness 3H
Support Color 16.2M / 262K colors
Temperature Range
o
Operating [ C] 0 to +50
o
Storage (Non-Operating) [ C] -20 to +60
RoHS Compliance RoHS Compliance
G150XG03 V1 rev. 0.5
5/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG03 V1
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
[cd/m2] IRCFL= 6.0mA
White Luminance 200 250 - 1
(center point)
%
Uniformity 9 Points 75 80 - 1, 2, 3
Contrast Ratio 400 500 - 4
Cross talk %
- 1.2 1.5 5
[msec] Rising 8.5 11
-
Response Time [msec] Falling - 3.5 5 6
[msec] Raising + Falling - 12
[degree] Horizontal (Right) 60 70 -
[degree] CR = 10 (Left)
60 70 -
Viewing Angle 7
[degree] Vertical (Upper) 55 65 -
[degree] CR = 10 (Lower)
45 55 -
Red x 0.612 0.642 0.672
Red y 0.307 0.337 0.367
Green x 0.276 0.306 0.336
Color / Chromaticity Green y 0.551 0.611
0.581
Coordinates
(CIE 1931) Blue x 0.114 0.144 0.174
Blue y 0.071 0.101 0.131
White x 0.283 0.313 0.343
White y 0.299 0.329 0.359
Color Gamut % 65 -
Note 1: Measurement method
Equipment Pattern Generator, Power Supply, Digital Voltmeter, Luminance meter (SR_3 or equivalent)
Aperture 1 with 50cm viewing distance
Test Point Center
Environment < 1 lux
LCD Module
SR_3 or
equivalent
Measuring distance
Module Driving Equipment
G150XG03 V1 rev. 0.5
6/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG03 V1
Note 2: Definition of 9 points position (Display active area : 304.128(H) x 228.096(V))
90 % 50 % 10 %
10 %
50 %
90 %
Note 3: The luminance uniformity of 9 points is defined by dividing the minimum luminance values by the maximum
test point luminance
Minimum Brightness of nine points
W9 =
Maximum Brightness of nine points
Note 4 Definition of contrast ratio (CR):
Brightness on the "White" state
Contrast ratio (CR)=
Brightness on the "Black" state
Note 5 Definition of cross talk (CT)
