Image preview - the first page of the document
![Panel_AUO_G150XG01_V1_2_[DS]](/pics/5c36ac34630d9.gif)
>> Download Panel_AUO_G150XG01_V1_2_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V1
( ) Preliminary Specifications
(V ) Final Specifications
Module 15 Inch Color TFT-LCD
Model Name G150XG01 V1
Customer Date Approved by Date
Debbie Chiu 2010/06/17
Checked &
Prepared by
Approved by
Hsiao Chun Lin 2010/06/17
Note: This Specification is subject to change General Display Business Division /
without notice. AU Optronics corporation
G150XG01 V1 rev. 1.5
1/28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V1
Contents
1. Operating Precautions.....................................................................................4
2. General Description .........................................................................................5
2.1 Display Characteristics...........................................................................................................5
2.2 Optical Characteristics ...........................................................................................................6
3. Functional Block Diagram ...............................................................................9
4. Absolute Maximum Ratings ..........................................................................10
4.1 Absolute Ratings of TFT LCD Module .................................................................................10
4.2 Absolute Ratings of Environment ........................................................................................10
5. Electrical Characteristics ..............................................................................11
5.1 TFT LCD Module .................................................................................................................. 11
5.2 Backlight Unit........................................................................................................................13
6. Signal Characteristic .....................................................................................15
6.1 Pixel Format Image ..............................................................................................................15
6.2 Scanning Direction ...............................................................................................................15
6.3 Signal Description ................................................................................................................16
6.4 The Input Data Format .........................................................................................................17
6.5 Interface Timing ....................................................................................................................18
6.6 Power ON/OFF Sequence ...................................................................................................19
7. Connector & Pin Assignment ........................................................................20
7.1 TFT LCD Module: LVDS Connector.....................................................................................20
7.2 Backlight Unit: Lamp Connector ..........................................................................................22
7.3 Lamp Connector Pin Assignment ........................................................................................22
8. Reliability Test Criteria ..................................................................................23
9. Mechanical Characteristics ...........................................................................24
9.1 LCM Front View and Rear View...........................................................................................24
9.2 LCM Outline Dimension (Front View) ..................................................................................25
9.3 LCM Outline Dimension (Rear View)...................................................................................26
10. Label and Packaging....................................................................................27
10.1 Shipping Label (on the rear side of TFT-LCD display) ......................................................27
10.2 Carton Package .................................................................................................................27
11 Safety.............................................................................................................28
11.1 Sharp Edge Requirements.................................................................................................28
11.2 Materials .............................................................................................................................28
11.3 Capacitors...........................................................................................................................28
11.4 National Test Lab Requirement..........................................................................................28
G150XG01 V1 rev. 1.5
2/28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V1
Record of Revision
Version and Date Page Old description New Description
0.0 2007/05/15 All First Edition
0.1 2007/08/17 All Final Version
0.2 2007/10/01 23 Hot Storage: 60 Hot Storage: 65
0.3 2008/05/13 26 Outline Dimension ( T60: N/A) Outline Dimension ( T60: 15mm)
Heat Shrink Tube: 90mm Heat Shrink Tube: 110mm
0.4 2008/06/25 27 15pcs * 1 layers 12pcs * 1 layers
1.0 2008/06/25 All Final Version
1.1 2008/10/29 5 Weight & Physical Size: (typ.) Weight & Physical Size: (max.)
10 LCD Drive Voltage: Min: 0.3 (V) LCD Drive Voltage: Min: - 0.3 (V)
Min: 3.6 (V) Max: 4.0 (V)
10 TOP: 65 C TOP: 65 C (panel surface temperature)
21 Removed connector illustration
22 Mating Model Number: SM02 Mating Model Number: SM03
24 Update with more detail labeling
25 Update with more detail labeling
26 Update with more detail labeling
1.2 2009/01/09 6 Viewing Angle: 70/70/65/60(R/L/T/B) Viewing Angle: 80/80/70/60(R/L/T/B)
18 Note on frame rate is removed N/A
1.3 2009/09/02 27 Add China RoHs mark on shipping label
1.4 2010/03/04 4 Temperature Range Operating: -30 to +85
Operating: 0 to +65 (+65 oC as panel Storage (Non-Operating): -30 to +85
surface temperature)
Storage (Non-Operating): -20 to +65
10 Absolute Ratings of Environment Absolute Ratings of Environment
Operating Temperature Operating Temperature Min -30; Max
Storage Temperature +85
Storage Temperature Min -30; Max +85
Modify drawing
23 Reliability Test Criteria High Temperature Operation: 85 ,300
High Temperature Operation: 60 ,300 hours
hours Low Temperature Operation: -30 ,300
Low Temperature Operation: 0 ,300 hours
hours Hot Storage: 85 ,300 hours
Hot Storage: 65 ,300 hours Cold Storage: -30 ,300 hours
Cold Storage: -20 ,300 hours
1.5 2010/04/08 13 Add ViCFL (-30oC) reference Max. 1780
16 Add Note 2.
22 7.3 Lamp Connector Pin Assignment 7.3 Lamp Connector Pin Assignment
Lamp High Voltage Cable color Pink Lamp High Voltage Cable color Red
G150XG01 V1 rev. 1.5
3/28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V1
1. Operating Precautions
1) Since front polarizer is easily damaged, please be cautious and not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or
spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or soft cloth.
5) Since the panel is made of glass, it may be broken or cracked if dropped or bumped on
hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human
earth when handling.
7) Do not open nor modify the module assembly.
8) Do not press the reflector sheet at the back of the module to any direction.
9) In case if a module has to be put back into the packing container slot after it was taken
out from the container, do not press the center of the CCFL Reflector edge. Instead,
press at the far ends of the CFL Reflector edge softly. Otherwise the TFT Module may
be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor
tilt the Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure (Notebook PC Bezel, for
example), do not twist nor bend the TFT Module even momentary. At designing the
enclosure, it should be taken into consideration that no bending/twisting forces are
applied to the TFT Module from outside. Otherwise the TFT Module may be damaged.
12) Cold cathode fluorescent lamp in LCD contains a small amount of mercury. Please follow
local ordinances or regulations for disposal.
13) Small amount of materials having no flammability grade is used in the LCD module. The LCD
module should be supplied by power complied with requirements of Limited Power Source
(IEC60950 or UL1950), or be applied exemption.
14) The LCD module is designed so that the CFL in it is supplied by Limited Current Circuit
(IEC60950 or UL1950). Do not connect the CFL in Hazardous Voltage Circuit.
15) Severe temperature condition may result in different luminance, response time and lamp
ignition voltage.
16) Continuous operating TFT-LCD display under low temperature environment may accelerate
lamp exhaustion and reduce luminance dramatically.
17) The data on this specification sheet is applicable when LCD module is placed in landscape
position.
18) Continuous displaying fixed pattern may induce image sticking. It's recommended to use
screen saver or shuffle content periodically if fixed pattern is displayed on the screen.
G150XG01 V1 rev. 1.5
4/28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V1
2. General Description
G150XG01 V1 is a Color Active Matrix Liquid Crystal Display composed of a TFT-LCD display, a
driver circuit, and a backlight system. The screen format is intended to support XGA (1024(H) x
768(V)) screen and 16.2M (RGB 8-bits) or 262k colors (RGB 6-bits). All input signals are LVDS
interface compatible. Inverter card of backlight is not included. All design rules of this module
can correspond to PSWG standard.
G150XG01 V1 is designed for industrial display applications.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
