Image preview - the first page of the document
![Panel_AUO_G150XG01_V2_0_[DS]](/pics/5c36ac3893255.gif)
>> Download Panel_AUO_G150XG01_V2_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V2
( ) Preliminary Specifications
(V) Final Specifications
Module 15 Inch Color TFT-LCD
Model Name G150XG01 V2
Customer Date Approved by Date
Debbie Chiu 2008/04/24
Checked &
Prepared by
Approved by
Danny Wang 2008/04/24
Note: This Specification is subject to change General Display Business Division /
without notice. AU Optronics corporation
G150XG01 V2 rev 0.0
1/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V2
Contents
1. Operating Precautions ..................................................................................... 4
2. General Description ......................................................................................... 5
2.1 Display Characteristics ...................................................................................................... 5
2.2 Optical Characteristics ....................................................................................................... 6
3. Functional Block Diagram ............................................................................... 9
4. Absolute Maximum Ratings........................................................................... 10
4.1 Absolute Ratings of TFT LCD Module.............................................................................. 10
4.2 Absolute Ratings of Environment..................................................................................... 10
5. Electrical Characteristics............................................................................... 11
5.1 TFT LCD Module ............................................................................................................. 11
5.2 Backlight Unit ................................................................................................................... 13
6. Signal Characteristic...................................................................................... 14
6.1 Pixel Format Image.......................................................................................................... 14
6.2 Scanning Direction........................................................................................................... 14
6.3 Signal Description ............................................................................................................ 15
6.4 The Input Data Format..................................................................................................... 16
6.5 Interface Timing ............................................................................................................... 17
6.6 Power ON/OFF Sequence ............................................................................................... 18
7. Connector & Pin Assignment ........................................................................ 19
7.1 TFT LCD Module: LVDS Connector................................................................................. 19
7.2 Backlight Unit: LED Connector ........................................................................................ 21
7.3 LED Connector Pin Assignment....................................................................................... 21
8. Reliability Test Criteria................................................................................... 22
9. Mechanical Characteristics ........................................................................... 23
9.1 LCM Front View and Rear View ....................................................................................... 23
9.2 LCM Outline Dimension (Front View)............................................................................... 24
9.3 LCM Outline Dimension (Rear View) ............................................................................... 25
10. Label and Packaging.................................................................................... 26
10.1 Shipping Label (on the rear side of TFT-LCD display) ................................................... 26
10.2 Carton Package ............................................................................................................. 26
11 Safety.............................................................................................................. 27
11.1 Sharp Edge Requirements ............................................................................................. 27
11.2 Materials......................................................................................................................... 27
11.3 Capacitors ...................................................................................................................... 27
11.4 National Test Lab Requirement ...................................................................................... 27
G150XG01 V2 rev 0.0
2/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V2
Record of Revision
Version and Date Page Old description New Description
0.0 2009/04/24 All First Edition
G150XG01 V2 rev 0.0
3/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V2
1. Operating Precautions
1) Since front polarizer is easily damaged, please be cautious and not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or
spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or soft cloth.
5) Since the panel is made of glass, it may be broken or cracked if dropped or bumped on
hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human
earth when handling.
7) Do not open nor modify the module assembly.
8) Do not press the reflector sheet at the back of the module to any direction.
9) In case if a module has to be put back into the packing container slot after it was taken
out from the container, do not press the center of the LED Reflector edge. Instead,
press at the far ends of the LED Reflector edge softly. Otherwise the TFT Module may
be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor
tilt the Interface Connector of the TFT Module.
11) TFT-LCD Module is not allowed to be twisted & bent even force is added on module in a very
short time. Please design your display product well to avoid external force applying to module
by end-user directly.
12) Small amount of materials without flammability grade are used in the TFT-LCD module. The
TFT-LCD module should be supplied by power complied with requirements of Limited Power
Source (IEC60950 or UL1950), or be applied exemption.
13) Severe temperature condition may result in different luminance, response time.
14) Continuous operating TFT-LCD Module under high temperature environment may accelerate
LED light bar exhaustion and reduce luminance dramatically.
15) The data on this specification sheet is applicable when TFT-LCD module is placed in
landscape position.
16) Continuous displaying fixed pattern may induce image sticking. It's recommended to use
screen saver or moving content periodically if fixed pattern is displayed on the screen.
G150XG01 V2 rev 0.0
4/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V2
2. General Description
G150XG01 V2 is a Color Active Matrix Liquid Crystal Display composed of a TFT-LCD display, a
driver circuit, and a backlight system. The screen format is intended to support XGA (1024(H) x
768(V)) screen and 16.2M (RGB 8-bits) or 262k colors (RGB 6-bits). All input signals are LVDS
interface compatible. All design rules of this module can correspond to PSWG standard.
G150XG01 V2 is designed for industrial display applications.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
Items Unit Specifications
Screen Diagonal [inch] 15
Active Area [mm] 304.128(H) x 228.096(V)
Pixels H x V 1024x3(RGB) x 768
Pixel Pitch [mm] 0.297 x 0.297
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode TN, Normally White
Nominal Input Voltage VDD [Volt] 3.3 typ.
Typical Power Consumption [Watt] 8.8 ( 64 Gray Bar Pattern , exclude inverter)
Weight [Grams] 1100g (max.)
Physical Size [mm] 326.5(H)x 253.5(V) x 12.0(D) (max.)
Electrical Interface 1 channel LVDS
Surface Treatment Anti-glare, Hardness 3H
Support Color 16.2M / 262K colors
Temperature Range
o o
Operating [ C] 0 to +65 (+65 C as panel surface temperature)
o
Storage (Non-Operating) [ C] -20 to +65
RoHS Compliance RoHS Compliance
G150XG01 V2 rev 0.0
5/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V2
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
[cd/m2] IF= 80mA
White Luminance 300 350 - 1
(center point)
%
Uniformity 9 Points 75 80 - 1, 2, 3
Contrast Ratio 400 700 - 4
Cross talk %
- 1.2 1.5 5
[msec] Rising 5.7
-
Response Time [msec] Falling - 2.3 6
[msec] Raising + Falling - 8
[degree] Horizontal (Right) 70 80 -
[degree] CR = 10 (Left)
70 80 -
Viewing Angle 7
[degree] Vertical (Upper) 70 80 -
[degree] CR = 10 (Lower)
50 60 -
Red x 0.584 0.634 0.684
Red y 0.297 0.347 0.397
Green x 0.277 0.327 0.377
Color / Chromaticity Green y 0.560 0.610 0.660
Coordinates
(CIE 1931) Blue x 0.102 0.152 0.202
Blue y 0.022 0.072 0.122
White x 0.263 0.313 0.363
White y 0.279 0.329 0.379
Color Gamut % 65 -
Note 1: Measurement method
Equipment Pattern Generator, Power Supply, Digital Voltmeter, Luminance meter (SR_3 or equivalent)
Aperture 1 with 50cm viewing distance
Test Point Center
Environment < 1 lux
LCD Module
SR_3 or
equivalent
Measuring distance
Module Driving Equipment
G150XG01 V2 rev 0.0
6/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V2
Note 2: Definition of 9 points position (Display active area : 304.128(H) x 228.096(V))
90 % 50 % 10 %
10 %
50 %
90 %
Note 3: The luminance uniformity of 9 points is defined by dividing the minimum luminance values by the
maximum test point luminance
Minimum Brightness of nine points
W9 =
Maximum Brightness of nine points
Note 4 Definition of contrast ratio (CR):
Brightness on the "White" state
Contrast ratio (CR)=
Brightness on the "Black" state
Note 5 Definition of cross talk (CT)
